Quick Details
-
Item no.:
-
UTP CAT5e
-
Number of conductor:
-
8
-
Conductor:
-
24awg Bare Copper, 4 pairs Twisted Data Cables
-
Insulation:
-
PE
-
Jacket:
-
PVC ,LSOH
-
Max. Temperature:
-
70℃
-
Rating Voltage:
-
30V
-
color:
-
black/grey/customerized
Quick Details
-
Brand Name:
-
ELESUN
-
Model Number:
-
cat5e
-
Place of Origin:
-
Jiangsu, China
-
Item no.:
-
UTP CAT5e
-
Number of conductor:
-
8
-
Conductor:
-
24awg Bare Copper, 4 pairs Twisted Data Cables
-
Insulation:
-
PE
-
Jacket:
-
PVC ,LSOH
-
Max. Temperature:
-
70℃
-
Rating Voltage:
-
30V
-
color:
-
black/grey/customerized
24AWG 8 core 4pairs cat5 cat5e cat6 network cable with pvc/pe jacket for outdoor telephone
Conductor:24awg Bare Copper, 4 pairs
Insulation:PE,
Jacket:PVC ,LSOH
Max. T emperature:70℃
Extended Distance/Extended Frequency, 100Mbps
Application
Used mainly for data transmission, these cables offer extended transmission distances over frequency . LSZH, duct grade and SWA versions are also available .
Packing:
1000feet (305m) /carton box
Technical Parameter
|
|
Frequency(MHz) |
Parameter |
|
Resistance(Ω /100m) |
|
9.5 |
|
Impedance(Ω ) |
|
100± 15 |
|
Max.Capacitance(pF/100m) |
|
5.6 |
|
Rate |
|
0.65 |
|
Max Attenuation (db/100m) |
1 |
2.0 |
|
4 |
4.1 |
|
|
10 |
6.5 |
|
|
31.25 |
11.7 |
|
|
62.5 |
17.0 |
|
|
100 |
22.0 |
|
|
200 |
/ |
|
|
250 |
/ |
|
|
Min.Return Loss (db/100m) |
1 |
23 |
|
4 |
23 |
|
|
10 |
23 |
|
|
31.25 |
21.1 |
|
|
62.5 |
18.1 |
|
|
100 |
16 |
|
|
200 |
/ |
|
|
250 |
/ |
