1. According to different temperature range, cold room can be divided into 0~+5 degree Celsius cold room, -18 degree Celsius freezing room and -35 degree Celsius quick freezing room.
2. We have pre-painted steel (color steel) PUF panel and stainless steel PUF panel for option.
3. Panel thick: 100mm thick for 0~+5 degree Celsius cold room, 150mm thick for -18 degree Celsius freezing room and -35 degreeCelsius quick freezing room.
4. It is customized. Please let us know your demand, so we can design a suitable project for you.
- Product Details
- {{item.text}}
Quick Details
-
Cooling Capacity:
-
50ton
-
Place of Origin:
-
Tianjin, China
-
Brand Name:
-
Sure
-
Voltage:
-
220v 380v customized
-
Power:
-
customized
-
Dimension(L*W*H):
-
customized
-
Weight:
-
1500 KG
-
Product name:
-
Walk In Refrigerator
-
Application:
-
Industrial freezer room
-
Refrigerant:
-
R-404A
-
Material:
-
Steel
-
Thickness of panel:
-
100mm 120mm 150mm
-
Expansion valve:
-
DANFOSS from Denmark
-
Evaporator:
-
DL105, 2 sets
-
Condenser:
-
air cooled mounted together with compressor
Quick Details
-
Temperature:
-
0~+5C / -18C / -35C
-
Compressor brand:
-
Bitzer, Frascold
-
Panel Thickness:
-
120mm
-
Cooling Capacity:
-
50ton
-
Place of Origin:
-
Tianjin, China
-
Brand Name:
-
Sure
-
Voltage:
-
220v 380v customized
-
Power:
-
customized
-
Dimension(L*W*H):
-
customized
-
Weight:
-
1500 KG
-
Product name:
-
Walk In Refrigerator
-
Application:
-
Industrial freezer room
-
Refrigerant:
-
R-404A
-
Material:
-
Steel
-
Thickness of panel:
-
100mm 120mm 150mm
-
Expansion valve:
-
DANFOSS from Denmark
-
Evaporator:
-
DL105, 2 sets
-
Condenser:
-
air cooled mounted together with compressor
Product Overview
|
Item
|
Cold Room
|
|
Panel of Cool Room
|
Insulation Material: 100 mm thickness or 150 mm thickness polyurethanePanel Protective Material: painted galvanized steel
Skidproof floor |
|
Type of Door
|
Hinged door or Sliding door
|
|
Cooling Evaporator
|
Air Cooler
|
|
Cooling Refrigerant
|
R404
|
|
Control System
|
Power control box
|
|
Accessories
|
Light, switch, expansion valve and other accessories
|
|
Packing
|
Carton Package,Wooden Package
|
|
Payment Term
|
35 days after receiving the deposit
|
|
Warranty Time
|
1 years
|
Details Images
Cold Room Panel
We use fluoride-free material, it is more environment-friendly. Our cold room panels can reach fireproof level B2.
Polyurethane panel is foamed by high pressure with density of 42 kg/m3. So the thermal insulation will be good.
Polyurethane panel is foamed by high pressure with density of 42 kg/m3. So the thermal insulation will be good.
Cold Room Door
We have different types of cold room door, such as hinged door, sliding door, free door and other types of doors according to your
requirement.
requirement.
Compressor Condensing Unit
We use the world famous compressor like German Bitzer, American Emerson, etc.
It is easy to operate the automatic high-precision digital controller with high efficiency.
It is easy to operate the automatic high-precision digital controller with high efficiency.
Air Cooler
DD series, DJ series, DL series.
DD series is suitable for medium temperature;
DJ series is suitable for low temperature;
DL series is suitable for high temperature.
DD series is suitable for medium temperature;
DJ series is suitable for low temperature;
DL series is suitable for high temperature.
Refrigeration Parts
(1)Temperature controller Famous brand: Italy Dixell with DELIXI or Korean LG, French Schneider
(2)Valve Parts Famous brand: Denmark Danfoss
(3)Copper pipe and connection
(4)Thermal insulation pipe, wire, PVC pipe, PVC door curtain for sliding door, LED light, switch, electrode, insulating tape,
belting, etc.
(2)Valve Parts Famous brand: Denmark Danfoss
(3)Copper pipe and connection
(4)Thermal insulation pipe, wire, PVC pipe, PVC door curtain for sliding door, LED light, switch, electrode, insulating tape,
belting, etc.
Product packaging
