TA-2222YQ Aerospace Taikong fuel pump dispenser mini fuel dispenser gasoline machine for filling station

Shenyang Aerospace Xinyang Mechanical and Electrical Co,, Ltd. is a high- tech enterprise mainly engaged in development and production of fuel dispenser with revenue function, service station equipment and technical service.

Xinyang was founded in 2005, but has been engaged in development and production of oiling machines with excellent quality and reliable performance since 1979, has won countless honors such as Customer Satisfaction Product, Quality Trustworthy Product, Top 10 Aerospace Civilian Products, Aerospace Famous-brand Products, National Key New Product, etc. Meanwhile, establishes long -term and friendly cooperative relationship with Petro China, Sinopec, etc, and exported to Europe, Africa, South -east Asia, etc. High quality, competitive price, we will be your best choice

Our fuel dispenser is welcomed by domestic and foreign customers, selling well in not only all cities of China, but also all over the world such as Philippines, Indonesia, Myanmar, Egypt, Kenya, Papua New Guinea, Cote d'Ivoire, Sudan, Nigeria.

★ Support multi-brand dispensers
★ Easy to install and operate
★ Real-time display of fueling information and card information
★ Provide professional reports to facilitate checking statistics
★ Support SMS function; business data of fuel station can be regularly sent daily
★ Automatically upload fueling data


Optional configuration

1. submersible pump
2. combination pump
3. IC card
4. oil and gas recovery function


Main Technical Parameters

Flow range 5L/min ～ 50L/min (±10%)
Large flow 10L/min ～ 100L/min (±10%)
Maximum flow with vapor recovery feature 45L/min (±10%)
Power Common: AC380V+10%, -15% (50Hz±1Hz)
Single-phase: AC220V+10%, -15% (50Hz±1Hz)
Vehicle-mounted: DC12/24V±10%
Motor rated power 750W (or 11000W )
Inlet oil pressure Submersible pump series≤0.3MPa
Max permissible error ±0.30%
Ambient temperature -25℃～＋55℃(low temperature area: -40℃～＋55℃)
Relative humidity ≤95%
Vapor recovery 95% ～ 105% (with vapor recovery feature)
Unit price setting range 1.00 ～ 99.99 yuan /L
Single measurement range Amount: 0.01 ～ 9999.99 yuan
Volume: 0.01 ～ 9999.99 L
Cumulative measurement range Amount: 0.01 ～ 99999999.99 yuan
Volume: 0.01 ～ 99999999.99 L
Display after power failure ≥15 minutes
Noise ≤80dB(A)
Explosion-proof Sign Ex d e ib mb IIA T3 Gb
Explosion-proof Certificate CJEx14.0905



Series Details:

The first digit: 1- Side indicator, front gun 2- Top indicator, front gun 3- Side indicator, side gun
The second digit: number of nozzle
The third digit: number of oil product
The fourth digit: number of flow meter

Taikong TA/TB-                    Pump             Nozzle          Product            Flow meter              Keyboard            Display

2211                                  1                        2                        1                        1                         2 2

2212                                  1                       2                        1                         2                          2                        4

2222                                  2                      2                         2                        2                          2                        4

2422                                   2                      4                         2                        2                         4                        4

2424                                   2                      4                         2                      4                          4                        4

2444                                   4                      4                         4                       4                          4                       4

3111                                   1                       1                         1                        1                          1                        2

3212                                   1                      2                         1                        2                         2                        4

3222                                    2                        2                        2                        2                          2                        4

FAQ

Q: Why you choose Xinyang Taikong?

Because we have been professional fuel dispensers manufacturer since 1979, we were national-owned military enterprise before 2005, so we have abundence experiences of making different kinds of fuel dispensers, have stable quality,competitive prices, reliable service... We will be your best choice.

Q: Can you print our logos on the fuel dispensers?

Yes.Customized logos can be print on the machines according to your requirements.

Q: Is that factory price?

Yes.We assure you all prices are based on factory and with high quality.

Q: When can I get the order?

When we received your payment, it will take about 5-7 days to your door by express,
it will take about 7-10 days to your local air port by air,
it will take about 7 to 60 days depends on your destination port by sea.

Q: What is your terms of delivery?

We accept EXW, FOB, CIF, etc. You can choose the one which is the most convenient or cost effective for you.

Q: How long is the warranty period?

Guarantee one year. During the warranty period(except wearable parts & seals). we shall repair or replace the damaged part accordingly because of any damage due to quality problem.(For wearable parts&seals, we provide small quantity free, if occur quality problems.)
