Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
BAYKEE
-
Model Number:
-
TYN-M-200KVA
-
Input Voltage:
-
380V/220V
-
Output Voltage:
-
380V/220V
-
Output Current:
-
20A
-
Output Frequency:
-
50HZ/60HZ
-
Size:
-
600*800*2200mm
-
Certificate:
-
CE,IEC
-
Warranty:
-
2 year, 2 Years
-
Weight:
-
890kG
-
Product name:
-
Hybrid on and off grid Solar Power System
-
Solar panel:
-
Mono Crystalline
-
Inverter:
-
Hybrid Inverter
-
Battery:
-
Lead Acid Battery/Lithium lifePO4
-
System Type:
-
on and off grid solar system
-
Controller:
-
MPPT Solar Charge Controller
-
Color:
-
Balck
-
Load:
-
Commercial Application/house
Quick Details
-
Output Type:
-
Single, Triple, Multiple, Three Phase
-
Type:
-
DC/DC Converters, DC/AC Inverters, AC to AC
-
Inverter Efficiency:
-
More than 95%
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
BAYKEE
-
Model Number:
-
TYN-M-200KVA
-
Input Voltage:
-
380V/220V
-
Output Voltage:
-
380V/220V
-
Output Current:
-
20A
-
Output Frequency:
-
50HZ/60HZ
-
Size:
-
600*800*2200mm
-
Certificate:
-
CE,IEC
-
Warranty:
-
2 year, 2 Years
-
Weight:
-
890kG
-
Product name:
-
Hybrid on and off grid Solar Power System
-
Solar panel:
-
Mono Crystalline
-
Inverter:
-
Hybrid Inverter
-
Battery:
-
Lead Acid Battery/Lithium lifePO4
-
System Type:
-
on and off grid solar system
-
Controller:
-
MPPT Solar Charge Controller
-
Color:
-
Balck
-
Load:
-
Commercial Application/house
You may also like
Product Description
BK-TYN-M series multi-mode modular hybrid on and off grid solar inverter
TYN-M series modular multi-mode hybrid solar inverter is an intelligent multi-functional ower supply ,which is specially designed for new energy requirements by Aerospace Baykee(Guangdong)Technology Co.,ltd. It is internally composed of solar MPPT controller, charger, rectifier, inverter, static switch, main control circuit and display alarm circuit. According to different working modes, it can work in different application environments, such as grid-connected solar power generation, off-grid solar power supply, solar energy storage, off-peak energy storage, UPS power supply and backup.
Specification
|
Model
|
TYN-M-20K-M20
|
TYN-M-60K-M20
|
TYN-M-120K-M20
|
TYN-M-200K-M20
|
||||
|
Rated output capacity
|
20KW
|
60KW
|
120KW
|
200KW
|
||||
|
Working mode
|
solar，AC Hybrid storage inverter
|
|
|
|
||||
|
Working turn
|
Solar——Mains——Battery
|
|
|
|
||||
|
Isolation type
|
Non-isolated high frequency
|
|
|
|
||||
|
Power module model
|
TYN-M-20K-PM
|
|
|
|
||||
|
Number of power modules can be configured
|
1pcs
|
1~3pcs
|
1~6pcs
|
1~10pcs
|
||||
|
Solar
|
|
|
|
|
||||
|
Max input capacity
|
10KW×2
|
10KW×6
|
10KW×12
|
10KW×20
|
||||
|
Rated operating voltage
|
500V
|
|
|
|
||||
|
Max input voltage
|
800V
|
|
|
|
||||
|
MPPT range
|
400~800V
|
|
|
|
||||
|
Max input current
|
25A×2
|
|
|
|
||||
|
Input line
|
2
|
6
|
12
|
20
|
||||
|
gird(converter)
|
|
|
|
|
||||
|
Rated operating voltage
|
L-L:380/400/415 Vac,L-N:220/230/240 Vac 3Phase 4Wire(or single phase 2 wire) + PE
|
|
|
|
||||
|
Rated operating frequency
|
50/60Hz
|
|
|
|
||||
|
input voltage range
|
±25%,-40%(half load )
|
|
|
|
||||
|
input frequency range
|
±10%
|
|
|
|
||||
|
Input power factor
|
≥0.95(20~50% load )≥0.99(100%load)
|
|
|
|
||||
|
Current harmonic(2~39times )
|
≤5%(50%load)≤3%(100%load)
|
|
|
|
||||
|
Max input capacity
|
30KW
|
90KW
|
180KW
|
300KW
|
||||
|
Max output capacity
|
20KW
|
60KW
|
120KW
|
200KW
|
||||
|
Max input current
|
45A
|
135A
|
270A
|
450A
|
||||
|
Grid-connected DC component of current
|
≤0.5% current rated value
|
|
|
|
||||
|
Island protection time
|
2s
|
|
|
|
||||
|
Generator mode
|
Have
|
|
|
|
||||
|
Output(inverter )
|
|
|
|
|
||||
|
Rated working voltage
|
L-L:380/400/415 VAC,L-N:220/230/240 VAC 3Phase 4Wire(or single phase 2 wire) + PE
|
|
|
|
||||
|
Rated working frequency
|
50/60Hz±0.5Hz
|
|
|
|
||||
|
Output voltage stabilization accuracy
|
≤±1%
|
|
|
|
||||
|
Frequency tracking rate
|
0.2Hz/s~2Hz/s
|
|
|
|
||||
|
Waveform distortion
|
Sine wave, distortion:≤3%(liner load )≤5%(non-liner load)
|
|
|
|
||||
|
Output DC component
|
≤1%
|
|
|
|
||||
|
Three-phase voltage phase deviation
|
2º
|
|
|
|
||||
|
Dynamic transient characteristics
|
The dynamic transient range of inverter output is less than 10%, and the transient recovery time is <20mS
|
|
|
|
||||
|
Crest factor
|
3:1
|
|
|
|
||||
|
Overload capacity
|
105% overload delay 10 minutes protection, 125% overload delay 1 minute, more than 150% protection immediately
|
|
|
|
||||
|
Working system
|
Three in and three out, three in and three out, single in and single out, single in and three out(optional)
|
|
|
|
||||
|
Working mode
|
On and off grid,off grid(optional)
|
|
|
|
||||
|
Parallel machine no-load circulation
|
≤5%
|
|
|
|
||||
|
Parallel machine current imbalance
|
≤5%
|
|
|
|
||||
|
Self aging function
|
25%,50%,75%,100%(optional)
|
|
|
|
||||
|
Battery
|
|
|
|
|
||||
|
Rated voltage
|
240V(192V~288V Can be adjusted)
|
|
|
|
||||
|
Max current
|
120A
|
360A
|
720A
|
1200A
|
||||
|
Battery type
|
Lead-acid batteries, lithium batteries (or similar batteries)
|
|
|
|
||||
|
Battery capacity
|
configurable
|
|
|
|
||||
|
Charging mode
|
Temperature compensated constant current, constant pressure(Three-stage @ lead-acid battery)
|
|
|
|
||||
|
Float charging voltage
|
2.25V±1% /cell(@25℃,lead-acid battery)
|
|
|
|
||||
|
equal charging voltage
|
2.34V±1% /cell(@25℃,lead-acid battery)
|
|
|
|
||||
|
Temperature compensation
|
-3mV/℃/cell(@ lead-acid battery)
|
|
|
|
||||
|
Maximum charging capacity
|
≤50%(can be set ),Expandable external isolation charger
|
|
|
|
||||
|
System parameters
|
|
|
|
|
||||
|
Switching time
|
0ms
|
|
|
|
||||
|
Inverter efficiency
|
≥95%
|
|
|
|
||||
|
Protection function
|
Battery reverse connection protection, PV reverse connection protection, output short circuit, overload, over voltage, phase sequence, over temperature, fan fault, etc
|
|
|
|
||||
|
cooling way
|
Temperature controlled air cooling
|
|
|
|
||||
|
Protection grade
|
IP20
|
|
|
|
||||
|
Running environment
|
temperature-20~50℃
|
|
|
|
||||
|
Relative humidity
|
30%~95%(No condensation)
|
|
|
|
||||
|
Running height (maximum)
|
<1000 meters (1% drop in capacity per 100 meters, up to 4000 meters)
|
|
|
|
||||
|
Installation method
|
Based on customer’s requirements and the project site condition
|
|
|
|
||||
|
Size W*D*H(mm)
|
800*200*1000
|
600*800*1200
|
600*800*1800
|
600*800*2200
|
||||
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
