Quick Details
-
Place of Origin:
-
Shandong, China
-
Bearing type:
-
pillow block bearing
-
Bore size:
-
1 inch
-
Housing NO.:
-
P205
-
Housing Material:
-
cast iron housing
-
Insert bearing:
-
UC205-16
-
Bearing Material:
-
Gct15 steel bearing
-
Precision rate:
-
grade p4 p5 p6 p0
-
Bearing locking type:
-
set screw locking
-
Bearing housing type:
-
2-bolt flange
-
Application:
-
AGRICLUTRAL MACHINERY
Quick Details
-
Applicable Industries:
-
Manufacturing Plant, Machinery Repair Shops, Retail
-
Brand Name:
-
BHR, OEM
-
Model Number:
-
UCP205
-
Place of Origin:
-
Shandong, China
-
Bearing type:
-
pillow block bearing
-
Bore size:
-
1 inch
-
Housing NO.:
-
P205
-
Housing Material:
-
cast iron housing
-
Insert bearing:
-
UC205-16
-
Bearing Material:
-
Gct15 steel bearing
-
Precision rate:
-
grade p4 p5 p6 p0
-
Bearing locking type:
-
set screw locking
-
Bearing housing type:
-
2-bolt flange
-
Application:
-
AGRICLUTRAL MACHINERY
chumaceras 1" UCP205-16 UCP 205 bearing 205-16 iron cast housing pillow block bearing UCP205
Plummer block housing units : Cast iron housing, with long base, radial insert ball bearing with grub screws in inner ring, RSR seals.
The castings are made from high-quality cast iron, and finished on all unmachined surfaces with an electrostatic air drying paint.
|
Specifications: UCP 205 bearing 1 inch pillow block bearing UCP205-16 |
|
|
Bearing type |
pillow block bearing |
|
Bearing housing type |
Two-Bolt Base |
|
Bore diameter |
1 inch |
|
Overall length |
140mm |
|
Overall height |
70mm |
|
Housing material |
Cast Iron Housing |
|
Locking device |
Set Screw Locking |
|
Lubrication type |
Lubrication Fitting |
|
Seal type |
Contact Seal with Flinger |
|
Bore type |
Round |
|
Duty type |
Standard Duty |
|
Housing |
P205 |
|
Insert Bearing |
UC205-16 |
|
Application |
farm machine |
UCP series pillow block bearing:
| Model NO. | Length(mm) | Width(mm) | Thickness(mm) | Weight(kg) |
| UCP201 | 127 | 38 | 60.7 | 0.76 |
| UCP202 | 127 | 38 | 60.7 | 0.74 |
| UCP203 | 127 | 38 | 60.7 | 0.72 |
| UCP204 | 127 | 38 | 64 | 0.7 |
| UCP205 | 140 | 38 | 69.5 | 0.76 |
| UCP206 | 160 | 44 | 82 | 1.25 |
| UCP207 | 167 | 48 | 92 | 1.55 |
| UCP208 | 180 | 52 | 98 | 1.9 |
| UCP209 | 189 | 54 | 106 | 2.2 |
| UCP210 | 204 | 57 | 112 | 2.75 |
| UCP211 | 217 | 60 | 125 | 3.3 |
| UCP212 | 238 | 66 | 137 | 4.7 |
| UCP213 | 262 | 70 | 149 | 5.6 |
| UCP214 | 266 | 72 | 155 | 6.6 |
