Quick Details
-
Min. Operating Mass (kg):
-
4910
-
Wheel Track (F/R) (mm):
-
1672-2003/1662-2262
-
Gear Shift (F/R):
-
12/4
-
Speed Range (km/h) (F/R):
-
2.06-28.4/4.95-13.28
-
Lifting Force (Link Joint) (KN):
-
29
-
Displacement (L):
-
7.7
Quick Details
-
Place of Origin:
-
CHINA
-
Wheel Base (mm):
-
2688.5
-
Min. Ground Clearance (mm):
-
470
-
Min. Operating Mass (kg):
-
4910
-
Wheel Track (F/R) (mm):
-
1672-2003/1662-2262
-
Gear Shift (F/R):
-
12/4
-
Speed Range (km/h) (F/R):
-
2.06-28.4/4.95-13.28
-
Lifting Force (Link Joint) (KN):
-
29
-
Displacement (L):
-
7.7
Product Description
Technical Parameters
| Model | X1004 | X1104 | X1204 | X1254 | X1304 |
| Tractor | |||||
| Drive Type | 4×4 | ||||
| Dimensions(L×W×H)(mm) | 5010×2192×3060 | 5040×2255×3060 | 5040×2380×3100 | 5050×2370×2890 | |
| Wheel Base (mm) | 2688.5 | ||||
| Min. Ground Clearance (mm) | 450 | 470 | |||
| Min. Operating Mass (kg) | 4750 | 4820 | 4850 | 4910 | |
| Tyre Size (F/R) | 14.9-24/16.9-38 | 14.9-26/18.4-38 | |||
| Wheel Track (F/R) (mm) |
1672-2003/1600-
2200 |
1672-2003/1662-2262 |
1822-2153/1662-
2262 |
||
| Gear Shift (F/R) | 12/4 | ||||
| Speed Range (km/h) (F/R) | 2.06-28.4/4.95-13.28 | 2.19-29.63/4.72-13.83 | |||
| Lifting Force (KN) (610mm) | ≥25.5 | ≥25.9 | |||
| Lifting Force (Link Joint) (KN) | 28 | 29 | |||
| Diesel Engine | |||||
| Model | LR6A3-23 | LR6B3-23 | LR6B5-23 | LR6M5-23 | LR6M5-23 |
| Type | 6-cylinder, vertical, water cooled, four stroke direct injection diesel engine | ||||
| Displacement (L) | 6.49 | 6.87 | 7.43 | 7.7 | |
| Rated Power/Rotating Speed (kW/rpm) | 73.5/2300 | 81/2300 | 88.2/2300 | 92/2300 | 95.6/2300 |
