Quick Details
-
Brand Name:
-
LITHTECH
-
Model Number:
-
TE12100
-
Battery Size:
-
Lifepo4/lithium ion
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
8kg
-
The charging ratio:
-
0.5C-1C
-
The discharge rate:
-
1C
-
Electric Energy:
-
1280 Wh
-
Nominal Voltage:
-
12.8V/25.6V
-
Charge Voltage:
-
14.6±0.2V
-
Discharge current:
-
20A recommended, Max.50A
-
Cell & Method:
-
LFP-32700-6Ah 4S17P
-
Cycle life:
-
>6000 Cycles
-
OEM/ODM:
-
Customized OEM ODM Battery Pack
-
Product name:
-
LifePO4 Lithium Battery Pack
-
Color:
-
Customized Color
-
BMS:
-
Smart BMS
Quick Details
-
Storage Type:
-
Discharging:-20℃~60℃
-
Anode Material:
-
LFP
-
Application:
-
Home Appliances, BOATS, Golf Carts, electric vehicles, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies, Electric Forklifts, Solar Wind
-
Brand Name:
-
LITHTECH
-
Model Number:
-
TE12100
-
Battery Size:
-
Lifepo4/lithium ion
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
8kg
-
The charging ratio:
-
0.5C-1C
-
The discharge rate:
-
1C
-
Electric Energy:
-
1280 Wh
-
Nominal Voltage:
-
12.8V/25.6V
-
Charge Voltage:
-
14.6±0.2V
-
Discharge current:
-
20A recommended, Max.50A
-
Cell & Method:
-
LFP-32700-6Ah 4S17P
-
Cycle life:
-
>6000 Cycles
-
OEM/ODM:
-
Customized OEM ODM Battery Pack
-
Product name:
-
LifePO4 Lithium Battery Pack
-
Color:
-
Customized Color
-
BMS:
-
Smart BMS
Products Description
|
Model No
|
TE1250
|
TE12100
|
TE12200
|
TE24100
|
TE24200
|
||||
|
Voltage
|
12.8V
|
12.8V
|
12.8V
|
25.6V
|
25.6V
|
||||
|
Capacity
|
50Ah
|
100Ah
|
200Ah
|
100Ah
|
200Ah
|
||||
|
Energy
|
0.64 kWh
|
1.28 kWh
|
2.56 kWh
|
2.56 kWh
|
5.12 kWh
|
||||
|
Extendable function
|
Bluetooth Preheat USB CAN RS485
|
58.4 Vdc
|
58.4 Vdc
|
58.4 Vdc
|
58.4 Vdc
|
||||
|
Max.charging and discharging current
|
50A
|
100A
|
100A
|
100A
|
100A
|
||||
|
Max Power
|
0.64kw
|
1.28kw
|
1.28kw
|
1.28kw
|
1.28kw
|
||||
|
Life time(25°C)
|
5 years
|
|
|
|
|
||||
|
Life cycles(80% DOD, 25°C)
|
5000+ Cycles Times
|
|
|
|
|
||||
|
Storage time / temperature
|
5 months @ 25°C; 3 months @ 35°C; 1 month @ 45°C
|
|
|
|
|
||||
|
Operation temperature
|
-20°C to 60°C @60+/-25% Relative Humidity
|
|
|
|
|
||||
|
Storage temperature
|
0°C to 45°C @60+/-25% Relative Humidity
|
|
|
|
|
||||
|
Lithium Battery Standard
|
U.L1642, IEC62619, UN38.3, ROHS,CE-EMC
|
|
|
|
|
||||
|
Enclosure protection rating
|
IP65
|
|
|
|
|
||||
|
Dimensions(L×W×H)mm
|
260*168*209
|
406*170*236
|
483*170*240
|
483*170*240
|
522*240*218
|
||||
|
Weight
|
7KG
|
10KG
|
20KG
|
22KG
|
36KG
|
||||
Fast delivery and perfect warranty and after-sales service win the praise of customers
Our Warehouse
Contact us for more information about our warehouse and we will provide 2-3 days DDP delivery
Factory Show
Certifications
Package and Shipping
FAQ
1. Are the batteries GRADE-A,Brand NEW?
This item is 3.2v 272Ah item,the QR code is intact,Grade A,Brand new.
.
2.Are the batteries come with busbars+bolts?
The price come with Bus bars and Bolts，One Battery will come with one set bus bar and bolt（e.g.,If buy 4pcs battery,we will send 4pcs cells with 4pcs busbars and 8pcs bolts）If need more please contact us online.`
3.Can you test each battery PRIOR to shipping?
We will test all the battery Voltage and Internal resistance before shipping.
4.What kind of the package of the cells?
They will come with well package,each cell into thickness PE foam or bag,then into 5 layers strong carton.
5.How can I place the order?
Usually we accept alibaba trade assurance order online. For the RTS(ready for ship) product if there is clear shipping cost or free shipping to your country you can place order and pay directly after reading for all the details,or you can provide your shipping informtion to our sales they will creat online order for you.
6.How can I do if I need more help for the order?
You can chat our sales online or send inquiry email,we will respond you ASAP
