speed adjustable, simple control
- Product Details
- {{item.text}}
Quick Details
-
Dimension(L*W*H):
-
4200*800*1600 mm
-
Power (kW):
-
8.5
-
Weight (KG):
-
1300 kg
-
Panel Feed Speed(m/min):
-
12m/min
-
Overall dimensions:
-
200*800*1600mm
-
Sideband height:
-
12-60mm
-
Weight:
-
1200Kg
-
Edge band thickness:
-
0.4-3mm
-
Workpiece thickness::
-
10-55mm
-
Minimum length of workpiece:
-
80mm
-
Minimum width of workpiece:
-
50mm
-
Workpiece conveying speed:
-
12m/min
-
Total power:
-
Total power
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
LONGDEXIANG
-
Voltage:
-
380(can customize)
-
Dimension(L*W*H):
-
4200*800*1600 mm
-
Power (kW):
-
8.5
-
Weight (KG):
-
1300 kg
-
Panel Feed Speed(m/min):
-
12m/min
-
Overall dimensions:
-
200*800*1600mm
-
Sideband height:
-
12-60mm
-
Weight:
-
1200Kg
-
Edge band thickness:
-
0.4-3mm
-
Workpiece thickness::
-
10-55mm
-
Minimum length of workpiece:
-
80mm
-
Minimum width of workpiece:
-
50mm
-
Workpiece conveying speed:
-
12m/min
-
Total power:
-
Total power
Product Details
|
Overall dimensions:
|
4200*800*1600mm
|
|
Weight:
|
1200Kg
|
|
Sideband height:
|
12-60mm
|
|
Edge band thickness:
|
0.4-3mm
|
|
Workpiece thickness:
|
10-55mm
|
|
Minimum length of workpiece:
|
80mm
|
|
Minimum width of workpiece:
|
50mm
|
|
Workpiece conveying speed:
|
12m/min
|
|
Total power:
|
8.5KW
|
|
Air pressure:
|
0.6MPa-0.8Mpa
|
|
Rubber box heating power:
|
1.8Kw
|
|
Plate preheating power:
|
0.3Kw
|
|
Rubber box transmission power:
|
0.55Kw
|
|
Conveyor belt motor power
|
1.5Kw
|
|
Flush motor power:
|
0.37Kw*2 12000r/min.200Hz
|
|
Rough motor power:
|
0.75Kw*2 18000r/min.300Hz
|
|
Refined motor power:
|
0.75Kw*2 18000r/min.300Hz
|
|
Polishing motor power:
|
0.18Kw*2
|
speed adjustable, simple control
belt, pulley and steel body pressure sealing sideband and plank pressure, is more strong adhesive force, plank and have no glue
mark.
