Quick Details
-
Controller Type:
-
MPPT
-
Mounting Type:
-
Ground Mounting
-
Certificate:
-
CE UL
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
UNITED ENERGY
-
Output Voltage (V):
-
340-460V
-
Output Frequency:
-
50 60HZ
-
Work Time (h):
-
Depend On Sunshine Duration
-
Product name:
-
Commercial Hybrid Solar Power System
-
System Type:
-
Off-grid Hybrid Solar Photovoltaic System
-
Solar panel:
-
Mono Crystalline Perc Solar Panel
-
Inverter type:
-
Single Phase/Split Phase/3Phase
-
Battery:
-
Lead Acid/LiFePO4 Lithium Battery
-
Mounting Structure:
-
Customzied
-
Specification:
-
30KW 50KW 100KW 120KW 250KW 300KW 400KW
-
Usage:
-
Home Solar Energy Generation
-
Packing:
-
Wooden Box
-
Technical Support:
-
Complete Technical Support
Quick Details
-
Application:
-
Commercial
-
Solar Panel Type:
-
Monocrystalline Silicon
-
Battery Type:
-
Lead-Acid, Lithium Ion
-
Controller Type:
-
MPPT
-
Mounting Type:
-
Ground Mounting
-
Certificate:
-
CE UL
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
UNITED ENERGY
-
Output Voltage (V):
-
340-460V
-
Output Frequency:
-
50 60HZ
-
Work Time (h):
-
Depend On Sunshine Duration
-
Product name:
-
Commercial Hybrid Solar Power System
-
System Type:
-
Off-grid Hybrid Solar Photovoltaic System
-
Solar panel:
-
Mono Crystalline Perc Solar Panel
-
Inverter type:
-
Single Phase/Split Phase/3Phase
-
Battery:
-
Lead Acid/LiFePO4 Lithium Battery
-
Mounting Structure:
-
Customzied
-
Specification:
-
30KW 50KW 100KW 120KW 250KW 300KW 400KW
-
Usage:
-
Home Solar Energy Generation
-
Packing:
-
Wooden Box
-
Technical Support:
-
Complete Technical Support
Products Description
|
PRODUCT MODEL
|
UE50KW-HY
|
UE100KW-HY
|
||
|
Max PV System Size Nominal(kWp)
|
60
|
120
|
||
|
Battery System Size Nominal(kWh)
|
64/128/192/256/320/384
|
128/192/256/320/384
|
||
|
BESS SPECIFICATIONS
|
|
|
||
|
Battery Chemistry
|
Lithium Iron Phosphate(LFP)
|
|
||
|
Cell life Cycle
|
80% Retention with 5000 Cycles @ 1C 25℃
|
|
||
|
Rated Voltage
|
358.4V
|
|
||
|
Single Rack Rated Energy Capacity
|
64kWh
|
|
||
|
Rated AC Power
|
50kW
|
100kW
|
||
|
PRODUCT MODEL
|
UE250KW3-HY
|
UE500KW3-HY
|
||
|
Max PV System Size Nominal(kWp)
|
300
|
400
|
||
|
Battery System Size Nominal(kWh)
|
276/552/1104/1656
|
552/1104/1656
|
||
|
BESS SPECIFICATIONS
|
|
|
||
|
Battery Chemistry
|
Lithium Iron Phosphate(LFP)
|
|
||
|
Cell life Cycle
|
80% Retention with 5000 Cycles @ 1C 25℃
|
|
||
|
Rated Voltage
|
358.4V
|
|
||
|
Single Rack Rated Energy Capacity
|
64kWh
|
|
||
|
Rated AC Power
|
250kW
|
500kW
|
||
|
PV MODULE SPECIFICATIONS(Half Cell Mono)
|
|
|
||
|
Power(W)
|
550
|
|
||
|
Vmp(V)
|
41.96
|
|
||
|
Voc(V)
|
49.90
|
|
||
|
Dimensions(L x W x H)(mm)
|
2279*1134x35
|
|
||
|
PV Module weight(kg)
|
28.6
|
|
||
|
Certifications
|
CE / TUV (IEC 61215 & IEC 61730) / UL (UL1703)
|
|
||
|
Rated grid voltage
|
3phase,400V,50/60HZ
|
|
||
|
Grid voltage range
|
340-460V
|
|
||
|
Grid frequency range
|
49.5-50.5/59.5-60.5HZ
|
|
||
|
Operating temperature range
|
-20~40℃
|
|
||
|
Certifications
|
UL1973,UL9540A,IEC62619,CE,UN38.3
|
|
||
System Components
