Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Kelai
-
Year:
-
2020
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
3100mm*1350mm*4000mm
-
Weight (T):
-
16.2 T
-
Model Number:
-
HPFS-H-250T
-
Motor Power (kw):
-
30 kw
-
Keyword:
-
Hydryalic Press
-
Advantage:
-
High Efficiceny
-
Motor:
-
11KW
-
Package:
-
Steel tray case
-
Color:
-
Customized
-
Nominal Force (kN):
-
2500kN
-
Power Source:
-
Heat Hydraulic Press Machine
-
Function:
-
Deep Drawing
-
Product name:
-
Four Column Hydraulic Press
-
Application:
-
Metal Sheet Stamping
Quick Details
-
Machine Type:
-
Four-column Three-beam Hydraulic Press
-
Slide Stroke (mm):
-
710
-
Return Force (kN):
-
320 kN
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Kelai
-
Year:
-
2020
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
3100mm*1350mm*4000mm
-
Weight (T):
-
16.2 T
-
Model Number:
-
HPFS-H-250T
-
Motor Power (kw):
-
30 kw
-
Keyword:
-
Hydryalic Press
-
Advantage:
-
High Efficiceny
-
Motor:
-
11KW
-
Package:
-
Steel tray case
-
Color:
-
Customized
-
Nominal Force (kN):
-
2500kN
-
Power Source:
-
Heat Hydraulic Press Machine
-
Function:
-
Deep Drawing
-
Product name:
-
Four Column Hydraulic Press
-
Application:
-
Metal Sheet Stamping
PRODUCT INTRODUCTION
1. A new generation of numerical control hydraulic press, four-column guide body steel plate welding. Applicable process, SMC,DMC, BMC plastic products molding.
2. It is applicable to medium-sized parts in automobile, yacht, hardware, aviation, electronics, electrical appliances and other industries.
3. The servo motor and high-precision oil pump drive the pressure, speed and exhaust in sections.
4. PLC programming, touch screen display, control.
5. Precision control of displacement, speed and pressure sensors can be adjusted on the industrial touch screen.
6. Provide remote network service, and the machine will automatically alarm for fault and maintenance.
2. It is applicable to medium-sized parts in automobile, yacht, hardware, aviation, electronics, electrical appliances and other industries.
3. The servo motor and high-precision oil pump drive the pressure, speed and exhaust in sections.
4. PLC programming, touch screen display, control.
5. Precision control of displacement, speed and pressure sensors can be adjusted on the industrial touch screen.
6. Provide remote network service, and the machine will automatically alarm for fault and maintenance.
PRODUCT FEATURES
1. High efficiency and energy saving. The power consumption is 30% - 50% less than that of ordinary motors.
2. Low noise, noise can be controlled at about 60 dB.
3. The working position, speed and pressure can be adjusted infinitely.
4. Fast response, high pressure and position repetition accuracy.
5. High efficiency, multiple internal protection and extremely low failure rate.
6. 12 hours of continuous operation does not require cooling oil temperature.
7. The pipes and joints shall adopt SEA international standards to prevent pipeline oil leakage.
8. The button centralized control, (constant travel/constant pressure) two control modes and (adjustment/automatic) two operation modes are adopted.
9. European CE standard hydraulic system and electrical safety IP54 level.
2. Low noise, noise can be controlled at about 60 dB.
3. The working position, speed and pressure can be adjusted infinitely.
4. Fast response, high pressure and position repetition accuracy.
5. High efficiency, multiple internal protection and extremely low failure rate.
6. 12 hours of continuous operation does not require cooling oil temperature.
7. The pipes and joints shall adopt SEA international standards to prevent pipeline oil leakage.
8. The button centralized control, (constant travel/constant pressure) two control modes and (adjustment/automatic) two operation modes are adopted.
9. European CE standard hydraulic system and electrical safety IP54 level.
TECHNICAL PARAMETER
Advantages
1. CE, ISO Certification.
2. We can supply KLT brand or OEM for clients.
3. We can supply product line solution according to clients' requirements.
4. The pressure, stroke, and time of pressure maintaining can be regulated.
5. High quality and performance with good price.
6. Safe and stable operation.
7. Support 7*24 remote service or locate service.
8. Supply maintenance service all life.
2. We can supply KLT brand or OEM for clients.
3. We can supply product line solution according to clients' requirements.
4. The pressure, stroke, and time of pressure maintaining can be regulated.
5. High quality and performance with good price.
6. Safe and stable operation.
7. Support 7*24 remote service or locate service.
8. Supply maintenance service all life.
FAQ
Q1: How can I get a quotation?
A1: Pls tell us the machine you need, including quantity, raw materials and other requirements.
Q2: After I buy the machine, what will you do if I don't know some of the function?
A2: We will show you how to use the machine perfectly. Technical support and the video is available.
Q3: What can I do if the machine troubled after I buy it?
A3: We provide completely after sales service, and our engineers are available to service machinery overseas.
Q4: Will you show me how to install the machine?
A4: Certainly, we will enclose the production specification with the machine, and we could provide the video online to you, and our engineers are available to service machinery overseas
A1: Pls tell us the machine you need, including quantity, raw materials and other requirements.
Q2: After I buy the machine, what will you do if I don't know some of the function?
A2: We will show you how to use the machine perfectly. Technical support and the video is available.
Q3: What can I do if the machine troubled after I buy it?
A3: We provide completely after sales service, and our engineers are available to service machinery overseas.
Q4: Will you show me how to install the machine?
A4: Certainly, we will enclose the production specification with the machine, and we could provide the video online to you, and our engineers are available to service machinery overseas
