Quick Details
-
Warranty:
-
1 year
-
Place of Origin:
-
China
-
Brand Name:
-
Generic
-
Model Number:
-
DLH-60
-
Type:
-
LED Head Light with mounting clip and cable
-
Head Light Size:
-
19mm diameter; 21mm length
-
Head Light Weight:
-
approx. 11g (0.39 oz) (including mount)
-
Cable Length:
-
Max. 143cm (4.69 feet)
-
Illumination (lux):
-
approx. 50,000 Lux @ 250mm
-
Direction of Illumination:
-
adjustable to almost any direction
-
Operating Time:
-
approx. 4-5h with the included battery pack
-
LED Operating Life:
-
30,000hours (estimated life, depends on intensity used)
-
Light Source:
-
1W white LEDs
-
Surface Operating Temperature:
-
approx. 60°C (ambient temperature: 25°C)
Quick Details
-
Size:
-
19mm diameter; 21mm length
-
Material:
-
Other
-
Magnification:
-
none
-
Warranty:
-
1 year
-
Place of Origin:
-
China
-
Brand Name:
-
Generic
-
Model Number:
-
DLH-60
-
Type:
-
LED Head Light with mounting clip and cable
-
Head Light Size:
-
19mm diameter; 21mm length
-
Head Light Weight:
-
approx. 11g (0.39 oz) (including mount)
-
Cable Length:
-
Max. 143cm (4.69 feet)
-
Illumination (lux):
-
approx. 50,000 Lux @ 250mm
-
Direction of Illumination:
-
adjustable to almost any direction
-
Operating Time:
-
approx. 4-5h with the included battery pack
-
LED Operating Life:
-
30,000hours (estimated life, depends on intensity used)
-
Light Source:
-
1W white LEDs
-
Surface Operating Temperature:
-
approx. 60°C (ambient temperature: 25°C)
Product Description
This Dental LED Headlight is used for surgical operation and examination purposes. Compatible to all our dental/surgical loupes in our Store.
Featuring 50,000 Lux brightness and 6000K color temperature providing bright, white and shadow-free light allowing the doctor to see tissue characteristics without distortion.
The LED light casing is made by Aluminum, so it is durable and light weight. Also, the light casing has a special thermal management system with 143cm total headlight cable for convenient use. The battery pack has built-in Rechargeable Li-ion battery with power indication, fast and easy recharging of battery.
Features
- Small and Light Weight Design
- Advanced technology, 50,000 Lux Illumination Intensity, no lamp replacement of lamp
- Unobstructed Co-axial illumination
- Head light housing: Special thermal management system
- Headlight can be attached to loupes with supplied mount
- Compatible with most flip up style loupes
- Direction and angle of the LED beam is almost adjustable
- Maximum 143cm (4.69 feet) for headlight cable
- LED Operating Life up to 30,000 hours
- Adjustable Brightness Intensity (0-100%)
- Advanced Rechargeable Polymer Li-ion cells Battery
- Approx. 4 hours recharging time for battery
- Re-Charged battery operates approx. up to 4~5 hours
- Power Indication in Battery Pack
- Standards: UL / CUL / FCC / PSE / CE
Specifications
-
Head Light
- Size: 19mm diameter; 21mm length
- Weight: approx. 11g (0.39 oz) (including mount)
- Cable Length: Max. 143m (4.69 feet)
- Diameter of light spot at a distance of 420mm: approx. 80mm
- Illumination (lux): approx. 50,000 Lux @ 250mm
- Direction of Illumination: adjustable to almost any direction
- Operating Time: approx. 4-5h with the included battery pack
- Light Source: 1W white LEDs
- LED Operating Life: 30,000hours (estimated life, depends on intensity used)
- LED Color Temperature: 6,000K (CRT) purely white light
- Surface Operating Temperature: approx. 60°C (ambient temperature: 25°C)
-
Battery Pack
- Input: 12V DC, >1.0A
- Output: Variable, 0-4V DC / 0-0.6A
- Weight: approx. 110g (3.99 oz) including battery
- Dimention: approx. 75(L) x 52(W) x 21(H)mm (2.95 x 2.05 x 0.83 inch)
- Duration of use: approx. 4-5hours at full load
- Charging Time: approx. 4hours
- High Battery Output Efficiency: > 90%, ASIC
- Type: Advanced Rechargeable Polymer Li-ion cells
- Capacity: 7.4V, 1400mAh (approx.)
- Battery Life: approx. 500 charge/discharge cycles
- Battery Protection: Against over-charge and over-discharge
- Power Adapter (Input): 100~240V AC, 50~60Hz 0.3A (US / EU / UK / AU plug)
- Power Adapter (Output): 12V DC, >1.0A
- Output DC plug: Mini USB 5 pin
- Can be recharged to the USB port of the computer
Set Includes
- 1 x LED Head Light with mounting clip and cable
- 1 x Battery Pack
- 1 x Power Adapter (US / EU / UK / AU plug)
- 1 x Fixing Clamp
- 2 x Spiral Clip
- 2 x Garment Clip
- 1 x Hard Carrying Case
- 1 x English Instruction Manual
- Standard Factory Package
