Quick Details
-
Drilling Speed:
-
0.1mm/s
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
CTMACH
-
Model Number:
-
CTZX25
-
Voltage:
-
110/220/380V, 220/380v
-
Dimension(L*W*H):
-
770*880*1160mm
-
Power (kW):
-
0.75
-
Weight (KG):
-
132 KG
-
Marketing Type:
-
New Product 2024
-
Wattage:
-
750w
-
MOQ:
-
1set
-
Size:
-
770*880*1160mm
-
Net Weight:
-
132kg
-
Power(W):
-
750
-
After-sales Service Provided:
-
Video technical support
-
After Warranty Service:
-
Online support
-
Certification:
-
CE ISO
Quick Details
-
type:
-
Drilling & Milling Machine
-
Max. Drilling Dia. (mm):
-
25 mm
-
Range of Spindle Speed(r.p.m):
-
95 - 1420 r.p.m
-
Drilling Speed:
-
0.1mm/s
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
CTMACH
-
Model Number:
-
CTZX25
-
Voltage:
-
110/220/380V, 220/380v
-
Dimension(L*W*H):
-
770*880*1160mm
-
Power (kW):
-
0.75
-
Weight (KG):
-
132 KG
-
Marketing Type:
-
New Product 2024
-
Wattage:
-
750w
-
MOQ:
-
1set
-
Size:
-
770*880*1160mm
-
Net Weight:
-
132kg
-
Power(W):
-
750
-
After-sales Service Provided:
-
Video technical support
-
After Warranty Service:
-
Online support
-
Certification:
-
CE ISO
| Maximum drilling diameter | 25mm |
| Maximum face milling capacity | 52mm |
| Maximum vertical milling capacity | 16mm |
| Workbench size | 520×160mm |
| T-slot size | 16mm |
| X-axis travel | 290mm |
| Y-axis travel | 140mm |
| Spindle taper | MT3 |
| Spindle stroke | 85mm |
| Distance spindle axis to column guide | 203mm |
| Spindle end to table distance | 445mm |
| Headstock swirl angle around | ±45° |
| Spindle speed/Grade | 95-1420rpm/variable |
| Motor | 750w |
| N.W./G.W. | 132/150kg |
| Machine size | 680×680×1030mm |
