- Product Details
- {{item.text}}
Quick Details
-
Material:
-
Silicone rubber
-
Application:
-
insulation tube
-
Rated Voltage:
-
600
-
Tensile Strength:
-
27.6Mpa
-
Color:
-
grey
-
Product name:
-
1.7:1 Silicone rubber heat shrinkable tubing
-
Size:
-
1.0mm~150mm
-
Shrink ratio:
-
1.7:1 / 2:1
-
MOQ:
-
100 Meters
-
Thickness:
-
0.5mm~2.5mm
-
Working temperature:
-
-50C~200C
-
Temperature resistance:
-
Good
-
Brand:
-
Sunbow
-
Port:
-
Shenzhen
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Sunbow
-
Model Number:
-
SBS-SRHST
-
Material:
-
Silicone rubber
-
Application:
-
insulation tube
-
Rated Voltage:
-
600
-
Tensile Strength:
-
27.6Mpa
-
Color:
-
grey
-
Product name:
-
1.7:1 Silicone rubber heat shrinkable tubing
-
Size:
-
1.0mm~150mm
-
Shrink ratio:
-
1.7:1 / 2:1
-
MOQ:
-
100 Meters
-
Thickness:
-
0.5mm~2.5mm
-
Working temperature:
-
-50C~200C
-
Temperature resistance:
-
Good
-
Brand:
-
Sunbow
-
Port:
-
Shenzhen
Product Description
It is widely used in electrical protection,resistor,capacitor,aerospace,medical instrument etc.
|
Product Name
|
Silicone Rubber Heat Shrinkable Tubing.
|
Style
|
Soft
|
|
Brand
|
Sunbow..
|
Colour
|
Grey
|
|
Texture
|
Smooth..
|
Place of Product
|
Guangdong Province,China
|
|
Fabric
|
Silicone rubber..
|
Modes of packing
|
Packed in cartons
|
|
Size
|
Sleeving:0.5mm~150mm
|
After sale service
|
Yes
|
Specification
|
Performance
|
Flame retardant
|
Normal type
|
|
Tensile strength MPa(Kg/cm2)
|
4.2
|
4.5
|
|
Elongation at break %
|
300
|
300
|
|
Volume resistivity Ω·m(Ω·cm)
|
2×1012(2×1014)
|
2×1012(2×1014)
|
|
Dielectric strength KV/mm
|
18
|
18
|
|
Use temperature rangeºC
|
-50～+200
|
-50～+200
|
|
Axial shrinkage%
|
40%
|
40%
|
|
Shrink temperature ºC
|
> 120
|
> 120
|
|
Concentricity %
|
≥65
|
≥65
|
|
Flammability (Oxygen Index)
|
≥28
|
≥28
|
The material object
Detailed Images
Product superiority:
It owns the general silicone tube itself excellent performance,high temperature,high pressure,flame retardant,soft and flexible.
Product superiority
It has extra functions,such as a thermal shrinkage performance,and good resistance to thorn damage mechanical properties,
Certificate
Recommend Products
Packing&Shipping
Warehouse&Packing&Shipping
Company Introduction
Shenzhen Sunbow Insulation Materials MFG. Co., Ltd. was established in 2003, mainly engaged in research & development, manufacture and sales of various insulation sleeves. We has leading R&D team, had a batch of industry-leading production equipment and advanced testing equipment. After more than 15 years of steady development, with the joint efforts of all employees, now we has more than 40 patents, and successively gained the "Shenzhen High-tech Enterprise" in June 2015 and the honorary title of "National High-tech Enterprise" in December 2016, and the 2nd time successfully passed the "National High-tech Enterprise" review in December 2022. In June 2022, it was awarded the title of "Boutique New" small and medium-sized enterprise in Shenzhen, and it was awarded the "Technology-based" enterprise in Guangming District in 2022.
Our Services & Strength
Our main products include fiberglass sleeving, PTFE tube, silicone rubber tube (especially platinum vulcanized silicone reinforced mesh tube), PVC tube, corrugated pipe, expandable sleeve, PE heat shrinkable tube, polyimide film tube and so on in R&D, production and sales. All of our fiberglass sleeving have been obtained the UL and CSA safety certificates (E333178--UZIQ2, VW-1 for flame retardant requirements; E333177--UZFT2/8,200C, 600V for temperature resistance level requirements); Our Heat shrinkable tube, PTFE tube, Silicone rubber tube and PVC tube have been obtained UL certificates (Cert. No.YDPU2/8: E360625); Our expandable sleeve also successfully obtained UL certificates in 2017 (Cert. No.UZIQ2: E333178). So far, our company is currently one of the few professional manufacturers of fiberglass sleeves in mainland China that have both UL and CSA certifications, and we are also the only one manufacture which can provide UL certificates that has obtained all colors and maximum size range (our certified specification range is 24AWG (0.55mm) ~ 1 inch (25.4mm)) in safety certification and certification specifications. (The same occupation only apply for the color certification of the primary color (white) and the certification size range is generally only 24AWG (0.55mm) ~ 3/8 inch (9.5mm) safety certification). At the same time, all products are in conformance with EU RoHS 2.0 and REACH test report that does not contain 235 high-risk substances.
FAQ
Q1. What is your terms of delivery? A: EXW, FOB, CFR, CIF, DDU.
Q2. How about your delivery time? A: Generally, it will take 20 to 60 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q3. Can you produce according to the samples? A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q4. What is your sample policy? A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q5. Do you test all your goods before delivery? A: Yes, we have 100% test before delivery
Q6: How do you make our business long-term and good relationship? A:1. We keep good quality and competitive price to ensure our customers benefit ; 2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
