Quick Details
-
Brand Name:
-
XW-ETLINK
-
Model Number:
-
XW-rj45 coupler series
-
Current Rating:
-
1.5 amps
-
Voltage Rating:
-
125vac
-
Insulation Resistance:
-
500 MΩmin
-
Contact Resistance:
-
30 MΩmax
-
Withstanding Voltage:
-
AC 1000V RMS 50Hz or 60Hz 1 min
-
Durability:
-
750 mating cycles min
-
Retention Strength:
-
7.7KG.F min between jack and plug
-
Operating Temperature:
-
-40℃ to 85℃
-
OEM/ODM:
-
YES
Quick Details
-
Type:
-
RJ45
-
Application:
-
Audio & Video
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
XW-ETLINK
-
Model Number:
-
XW-rj45 coupler series
-
Current Rating:
-
1.5 amps
-
Voltage Rating:
-
125vac
-
Insulation Resistance:
-
500 MΩmin
-
Contact Resistance:
-
30 MΩmax
-
Withstanding Voltage:
-
AC 1000V RMS 50Hz or 60Hz 1 min
-
Durability:
-
750 mating cycles min
-
Retention Strength:
-
7.7KG.F min between jack and plug
-
Operating Temperature:
-
-40℃ to 85℃
-
OEM/ODM:
-
YES
Note: All certificates are authentic and valid. If you need the certificate details, please contact customer service to provide
Specification
|
DESCRIPTION
|
|
|
|
|
||||
|
RJ45 With internal Magnetics Connector
|
|
|
|
|
||||
|
DONGGUAN XUNWANG ELECTRONIC CO.,LTD.Our surface mount, low profile RJ45 connectors with integrated magnetics are designed and
manufactured to comply with IEEE802.3 and ANSI X3.263 standards. They are widely used in PC card / Notebook applications, wireles |
|
|
|
|
||||
|
Electrical
|
|
|
|
|
||||
|
Internal magnetics are 100% electrically tested for functionality per IEEE802.3 requirement
|
|
|
|
|
||||
|
High performance for maximum EMI suppression
|
|
|
|
|
||||
|
350uH minmum OCL with 8mA bias current
|
|
|
|
|
||||
|
Instertion Loss
|
-1.0dB Maximum @100KHz-60MHz
|
|
|
|
||||
|
|
-18dB Minimum @1MHz-30MHz
|
|
|
|
||||
|
|
-14dB Minimum @30MHz-60MHz
|
|
|
|
||||
|
|
-12dB Minimum @60MHz-80MHz
|
|
|
|
||||
|
|
-10dB Minimum @80MHz-100MHz
|
|
|
|
||||
|
Common Mode Rejection
|
-30dB Minimum @1MHz-100MHz
|
|
|
|
||||
|
Cross Talk
|
-30dB Minimum @1MHz-100MHz
|
|
|
|
||||
|
Mechanical
|
|
|
|
|
||||
|
Retention Strength
|
7.7KG.F min between jack and plug
|
|
|
|
||||
|
Durability
|
800 mating cycles min
|
|
|
|
||||
|
Material
|
|
|
|
|
||||
|
1.Housing
|
PBT(UL94V-0) PA46(UL94V-0) LCP(UL94V-0)
|
|
|
|
||||
|
2.Contact Wire
|
PHOSPHOR BRONZE T=0.35, GOLD PLATING OVER NIKEL
|
|
|
|
||||
|
3.Shield
|
0.20~0.25mm thickness brass with tin plated
|
|
|
|
||||
|
4.Gold Plating
|
6u" 15u" 30u" 50u" .
|
|
|
|
||||
|
|
Standard LED Color
|
LED Wavelength
|
Forward (V MAX)
|
Typical (V TYP)
|
||||
|
|
Green
|
560-580 nm
|
2.5V
|
2.1-2.2V
|
||||
|
|
Yellow
|
580-610 nm
|
2.5V
|
2.1-2.2V
|
||||
|
|
1. LED intensity/wavelength measured with Photo Research PR-650 Colormeter
2. With a forward current of 20 mA,Absolute Maximum Ratings (Ta=25℃) |
|
|
|
||||
|
6.RoHS peak wave solder
|
RoHS peak wave solder temperature rating 260℃±5℃
|
|
|
|
||||
|
Operating and Storage Temperature
|
|
|
|
|
||||
|
Operating Temperature
|
-40℃ to 85℃
|
|
|
|
||||
|
Storage Temperature
|
-40℃ to 85℃
|
|
|
|
||||
|
APPLICATION
|
|
|
|
|
||||
|
NETWORKING PRODUCTS: NIC, HUB, SWITCH, ROUTER, BRIDGE,WORK,
|
|
|
|
|
||||
|
STATION: PC/SYSTEM, PRINTER,SERVER,NB,IACABLE MODEN,XDSL APPLICATION, SET-TOP-BOX.
|
|
|
|
|
||||
