- Product Details
- {{item.text}}
Quick Details
-
name:
-
refrigerator truck
-
color:
-
red,blue, white,etc.
-
drive system:
-
left hand or right hand(LHD &RHD)
-
refrigerator truck chassis brand:
-
Dongfeng,Foton,Jmc,Howo,etc.
-
horsepower:
-
95hp,120hp,170hp,190hp,220hp,266hp,360hp,etc.
-
loading capacity:
-
5ton,3ton,8ton,10ton,15ton,20ton,30ton
-
suit for cargo:
-
meat,fish, vegatable and south africa
-
type:
-
freezer
-
warranty:
-
18months
-
refrigerator truck manufacturer:
-
Chengli Special Automobile Co.,Ltd
Quick Details
-
Condition:
-
New
-
Emission Standard:
-
Euro 3
-
Gross Vehicle Weight:
-
6495
-
name:
-
refrigerator truck
-
color:
-
red,blue, white,etc.
-
drive system:
-
left hand or right hand(LHD &RHD)
-
refrigerator truck chassis brand:
-
Dongfeng,Foton,Jmc,Howo,etc.
-
horsepower:
-
95hp,120hp,170hp,190hp,220hp,266hp,360hp,etc.
-
loading capacity:
-
5ton,3ton,8ton,10ton,15ton,20ton,30ton
-
suit for cargo:
-
meat,fish, vegatable and south africa
-
type:
-
freezer
-
warranty:
-
18months
-
refrigerator truck manufacturer:
-
Chengli Special Automobile Co.,Ltd
5tons Live Fish Transport Trucks Refrigerator Cars Diesel Engine For Sale
| Item | Parameter |
| Production name | Cargo van freezer truck |
| vehicle model | CLW |
| Engine | Engine model: LJ465Q-2AE |
| Engine manufacturer: liuzhou wuling liuji power co. , ltd | |
| Exhaust: 1051ml | |
| Power: 45kw | |
| Chassis model | BJ1020V3JV2-X |
| Tire | Tire specification: 165/70R13LT |
| Number of tire: 6 | |
| Axle | Number of axles: 2 |
| Axle-load: 754/1130 | |
| Wheel base(mm): 2370 | |
| Traction system | 4*2 |
| Fact cubage(m3) | 5/6 |
| GVW(kg) | 1884 |
| Curb weight(kg) | 1256 |
| Overall dimensions(mm) | 4460×1670×2400 |
| Upper box body size(mm) | 2600×1460×1470 |
| F / R track base(mm) | 1260/1260 |
| F/R overhang(mm) | 895/1195 |
| Approach / departure angle(°) | 24/28 |
| Max speed(Km/h) | 90 |
| Equipment and Function | Equipment: chassis, the heat preservation box body with back open doorand refrigeration unit; |
| Function: transport frozen foods (ice truck), dairy (milk truck) fruits and vegetables (fresh transporter) vaccine and drug transporter (vaccine truck), etc | |
| Product cycle | 25-30 days |
| Warranty | 12months, from the date of supply |
1.The small refrigerator truck details specification:
(1)The mini refrigerator truck performance and features:
1.The mini Refrigerator truck(or insulation van ) is made of the insulated truck box, the chassis, the refrigeration unit and the vehicle accessories. 2.There are Beautiful appearance, high strength and the good heat preservation (the refrigeration units of the refrigerated truck body cooling speed fast , and the heat preservation time is long) for the refrigerated truck.
(2)the mini refrigerator truck body heat preservation performance and features:
1.the mini refrigerator truck box body is composed of the former board,roof,the both sides plate and double back door
(options one door). each plate heat preservation thermal insulation layer of the refrigerated truck box body is rigid
polyurethane foam. the refrigerated truck body plate produced by "sandwich" bonding technology , the polyurethane
of the plates insulation layer density is 42 ~ 50 (kg/m3) (the floor is 50 - 55 kg/m3).
2. The inner and outer skin of Each minirefrigerated truck body plate are all food grade white glass plates
(strength and corrosion resistance are better).
3.The mini Refrigerator truck body plate assembly structure of a twocomponent polyurethane adhesive joint and the bolt
support link method, the integrated intensity of the box body solid and reliable. Compartments in vitro edge installation
of high strength aluminum and stainless steel gradient Angle and tail.
Dongfeng 3-5Ton refrigerator truck with diesel engine show:
5tons Live Fish Transport Trucks Refrigerator Cars Diesel Engine For Sale: naked, waxing
By bulk, ro-ro or container ship
