Quick Details
-
Power:
-
2.2kw
-
Min. Lifting Height:
-
cherry picker
-
Table Size:
-
500mm
-
Overall Dimensions:
-
cherry picker
-
Weight:
-
500 kg
-
Product name:
-
Hydraulic Scissor Lift
-
Keywords:
-
Hydraulic Vehicle-mounted Elevating Platform
-
Type:
-
Articulated Hydraulic Lift
-
Usage:
-
Higher Level
-
Name:
-
Lifting Equipment Electric Scissor Lift
Quick Details
-
Warranty:
-
1 Year
-
Place of Origin:
-
Austria
-
Brand Name:
-
cherry picker
-
Power:
-
2.2kw
-
Min. Lifting Height:
-
cherry picker
-
Table Size:
-
500mm
-
Overall Dimensions:
-
cherry picker
-
Weight:
-
500 kg
-
Product name:
-
Hydraulic Scissor Lift
-
Keywords:
-
Hydraulic Vehicle-mounted Elevating Platform
-
Type:
-
Articulated Hydraulic Lift
-
Usage:
-
Higher Level
-
Name:
-
Lifting Equipment Electric Scissor Lift
Track Crawler Articulated Boom Lift
- OEM & ODM Service -
Track Crawler Articulated Boom Lift is one of the most ideal aerial lift platform for both indoors and outdoors maintenance work. It can rotate 360 degree in the air and platform height is from 10m to 20m. Articulated boom lift is driven by Diesel,Gas,AC electricity,DC Battery or Hybrid Power. It is widely used in neighborhood unit, road light maintenance, factories high place maintenance, construction site and so on.
|
Model Type |
TBL-10C Articulated |
TBL-12C Articulated |
TBL-14C Telescopic |
TBL-16C Telescopic |
TBL-20C Telescopic |
|
Lifting height |
10M |
12M |
14M |
16M |
20 M |
|
Working height |
12M |
14M |
16M |
18M |
22M |
|
Load capacity |
200KG |
||||
|
Platform size |
0.9*0.7M |
||||
|
Working radius |
5M |
6.5M |
10.5M |
11M | |
|
Net Weight |
1855KG |
2050KG |
2500KG |
2800KG |
2800KG |
|
Overall Size( L*W*H) |
6.65*1.7*2.1M |
7.75*1.7*2.1M |
6.55*1.66*2.2M |
6.7*1.65*2.2M |
5.8*1.9*2.3M |
|
Supporting Legs Stride Distance (Horizontal) |
3.0 M |
3.6 M |
3.6 M |
3.9 M |
3.9 M |
|
Supporting Legs Stride Distance (Vertical) |
4.7 M |
4.7 M |
4.7 M |
4.9 M |
4.9 M |
|
Wind Resistance Level |
5 |
||||
|
20’/40’ Container Loading Quantity |
20’/1set 40’/2sets |
20’/1set 40’/2sets |
20’/1set 40’/2sets |
20’/1set 40’/2sets |
20’/1set
40’ |
