tyre rollers new 30 tons static road roller XP303

tyre rollers new 30 tons static road roller XP303

FOB Reference Price: Get Latest Price

≥1 Pieces

US $42000

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Engine Brand:: weichai

Travel Speed:: 0-16km/h

Place of Origin:: Jiangsu, China

Brand Name:: newindu

Dimension(L*W*H):: 5060*2466*3464mm

Drum diameter:: 2355mm

Min. ground clearance:: 290mm

Tyre overlap amount:: 70mm

Compaction width:: 2365mm

Wheel base:: 3840mm

Rated speed:: 2000r/min

After Warranty Service:: Spare parts

Quick Details

Type:: Tire Roller

Power:: 132Kw

Weight:: 30ton

Engine Brand:: weichai

Travel Speed:: 0-16km/h

Place of Origin:: Jiangsu, China

Brand Name:: newindu

Dimension(L*W*H):: 5060*2466*3464mm

Drum diameter:: 2355mm

Min. ground clearance:: 290mm

Tyre overlap amount:: 70mm

Compaction width:: 2365mm

Wheel base:: 3840mm

Rated speed:: 2000r/min

After Warranty Service:: Spare parts

tyre rollers new 30 tons static road roller XP303

Contact way

Sales Manager

Alisa Wang

Newindu Construction Engineering (Shanghai) Co.,Ltd

Add: Suite 2801, Super Ocean Finance Center,2067 West Yan'an Road, Shanghai 200336, China
Tel: +86-21-62770109 Fax: +86-21-62120109
Mobile / Whatsapp/ Skype/ Wechat: +86-18616224775

Web: www.newindu.com

Product Description

Model	Unit	XP303
Min. working weight	kg	13900
Max. working weight	kg	30000
Axle load,wheels	kg	1100
Static linear load	kg	15000
Theoretical gradeability	%	20
Min. turning external radius	mm	9000
Min. ground clearance	mm	290
Tyre overlap amount	mm	70
Front wheel swing range	mm	±50
Compaction width	mm	2365
Ground pressure	kPa	250~480
Wheel base	mm	3840
Travel speed	km/h	0~8
	km/h	0~16
Tyre specification		13/80-20
Tyre tread		Smooth
Tyre amount		Front 4 rear 5
Engine model		SC8D180G2B1
Rated speed	r/min	2000
Rated power	kw	132
Engine oil consumption	g/kW•h	232
Water tank capacity	L	1100
Hydraulic oil tank capacity	L	100
Fuel tank capacity	L	180
