High pressure flexible stainless braided gas hose pipe with pvc cover jacket Steel Wire Braid hydraulic hose
High pressure flexible stainless braided gas hose pipe with pvc cover jacket Steel Wire Braid hydraulic hose
High pressure flexible stainless braided gas hose pipe with pvc cover jacket Steel Wire Braid hydraulic hose
High pressure flexible stainless braided gas hose pipe with pvc cover jacket Steel Wire Braid hydraulic hose
High pressure flexible stainless braided gas hose pipe with pvc cover jacket Steel Wire Braid hydraulic hose
High pressure flexible stainless braided gas hose pipe with pvc cover jacket Steel Wire Braid hydraulic hose
High pressure flexible stainless braided gas hose pipe with pvc cover jacket Steel Wire Braid hydraulic hose
High pressure flexible stainless braided gas hose pipe with pvc cover jacket Steel Wire Braid hydraulic hose

High pressure flexible stainless braided gas hose pipe with pvc cover jacket Steel Wire Braid hydraulic hose

FOB Reference Price: Get Latest Price
≥1 Meters
US $0.7
Free Inquiry
Customized Request
  • Product Details
  • {{item.text}}

Quick Details

Model Number:
Hydraulic Hose R1 R2 R3 R6 4SP 4SH etc
Product name:
gas hose pipe with pvc cover jacket Steel Wire Braid hydraulic hose
Material:
Synthetic Rubber oil resistant, high tensile steel wire
Reinforcement:
High Tensile Steel Wire Braided or Spiral
Working pressure:
25-45Mpa
MOQ:
1 meter
OEM:
OEM Services Provided
Certification:
ISO9001, MSHA
Standard:
SAE100RAT, EN DIN
Application:
Machine, Mining, Agriculture, Engineering, Oil
Packing:
Customized Packing, normally woven bag tape wrapped coils

Quick Details

Processing Service:
Moulding, Cutting, assembly
Place of Origin:
Hebei, China
Brand Name:
Sinopulse
Model Number:
Hydraulic Hose R1 R2 R3 R6 4SP 4SH etc
Product name:
gas hose pipe with pvc cover jacket Steel Wire Braid hydraulic hose
Material:
Synthetic Rubber oil resistant, high tensile steel wire
Reinforcement:
High Tensile Steel Wire Braided or Spiral
Working pressure:
25-45Mpa
MOQ:
1 meter
OEM:
OEM Services Provided
Certification:
ISO9001, MSHA
Standard:
SAE100RAT, EN DIN
Application:
Machine, Mining, Agriculture, Engineering, Oil
Packing:
Customized Packing, normally woven bag tape wrapped coils
Product Description
Hydraulic Hose 1SN, 2SN, R3, R6, 4SP, 4SH, etc

Hydraulic Hose

The hydraulic hose is mainly composed of liquid resistant synthetic rubber inner rubber layer, middle rubber layer, multi-layer reinforcement layer and weather resistant synthetic rubber outer rubber layer.
The inner rubber layer can make the conveying medium bear pressure and protect the steel wire or wire fiber from erosion. The outer rubber layer protects the reinforcing layer from damage. The reinforcing layer is a skeleton material to ensure the service pressure of the rubber hose.

Hydraulic Hose is mainly used for mine hydraulic support and oilfield development.
It is suitable for transporting petroleum base with certain pressure and temperature (such as mineral oil, soluble oil, hydraulic oil, fuel oil and lubricating oil) in engineering construction, hoisting transportation, metallurgical forging, mining equipment, ships, injection molding machinery, agricultural machinery, various machine tools and mechanized and
automatic hydraulic systems of various industrial departments And water-based liquids (such as emulsion, oil-water emulsion, water) and liquid transmission.
Rubber and plastic hydraulic hose, also known as rubber and plastic hose, is a new type of hose with obvious corrosion resistance and energy saving effect.
Detailed Images
EN853 1SN
EN853 2SN
EN856 4SP
EN856 4SH
Application
SAE100 R1AT/ EN853 1SN
One Steel Wire Braided Hydraulic Hose
1. Inner rubber: Oil resistant synthetic rubber
2. Reinforcement: One braided of high tensile steel wire
3. Cover: Weather and oil resistant synthetic rubber
4. Temperature range: -40℃ to +100℃
5. Main application: Suitable for conveyor low/ medium pressure of oil/water based hydraulic fluids
Hose Type
Dash
I.D
Inch
I.D
mm
O.D
mm
W.P
Mpa
W.P
PSI
B.P
PSI
B.R
mm
W.T
kg/m
1SN-04
1/4"
6.4
13.2
22.5
3263
13050
100
0.25
1SN-05
5/16"
7.9
14.7
21.5
3118
12325
115
0.311
1SN-06
3/8"
9.5
17.1
18.0
2610
10440
130
0.36
1SN-08
1/2"
12.7
20.4
16.0
2320
9280
180
0.451
1SN-10
5/8"
15.9
23.7
13.0
1885
7540
205
0.519
1SN-12
3/4"
19.1
27.3
10.5
1523
6090
240
0.651
1SN-16
1"
25.4
36.0
8.7
1262
5075
300
0.909
1SN-20
1-1/4"
31.8
42.5
6.3
914
3654
420
1.3
1SN-24
1-1/2"
38.1
48.5
5.0
725
2900
500
1.69
1SN-32
2"
50.8
62.0
4.0
580
2320
630
1.891
SAE100 R2AT/ EN853 2SN
Two Steel Wire Braided Hydraulic Hose
1. Inner rubber: Oil resistant synthetic rubber
2. Reinforcement: Two braided of high tensile steel wire
3. Cover: Weather and oil resistant synthetic rubber
4. Temperature range: -40℃ to +100℃
5. Main application: Suitable for conveyor low/ medium pressure of oil/water based hydraulic fluids
Hose Type
Dash
I.D
Inch
O.D
mm
W.P
Mpa
W.P
PSI
B.P
PSI
B.R
mm
W.T
kg/m
2SN-04
1/4"
15.0
40.0
5800
23200
100
0.352
2SN-05
5/16"
16.5
35.0
5075
20300
115
0.443
2SN-06
3/8"
18.9
33.0
4785
19140
125
0.54
2SN-08
1/2"
22.2
27.5
3988
15950
180
0.68
2SN-10
5/8"
25.6
25.0
3625
14500
205
0.779
2SN-12
3/4"
29.3
21.5
3118
12470
240
0.941
2SN-16
1"
37.8
16.5
2393
9570
300
1.35
2SN-20
1-1/4"
44.3
12.5
1813
7250
420
2.1
2SN-24
1-1/2"
50.3
9.0
1305
5220
500
2.65
2SN-32
2"
63.8
8.0
1160
4640
630
3.4
EN 856 4SP
Four Steel Wire Spiral Hydraulic Hose
1. Inner rubber: Oil resistant synthetic rubber
2. Reinforcement: A braid of textile material over the inner tube and four spiral plies of heavy steel wire wrapped in alternating direction
3. Cover: Weather and oil resistant synthetic rubber
4. Temperature range: -40℃ to +100℃
5. Main application: Very high pressure applications used for petroleum based hydraulic fluids
Hose Type
Dash
I.D
Inch
O.D
mm
W.P
Mpa
W.P
PSI
B.P
PSI
B.R
mm
W.T
kg/m
4SP-04
1/4"
18.0
45
6525
26100
150
0.62
4SP-06
3/8"
20.8
44.5
6453
25810
180
0.73
4SP-08
1/2"
24.0
41.5
6018
24070
230
0.9
4SP-10
5/8"
27.6
35
5075
20300
250
1.13
4SP-12
3/4"
31.8
35
5075
21460
300
1.48
4SP-16
1"
39.7
28
4060
16240
340
1.98
4SP-20
1-1/4"
50.8
21
3045
12180
460
2.91
4SP-24
1-1/2"
57.2
18.5
2683
10730
560
3.43
4SP-32
2"
69.8
16.5
2393
9570
660
4.89
EN 856 4SH
Four Steel Wire Spiral Hydraulic Hose
1. Inner rubber: Oil resistant synthetic rubber
2. Reinforcement: A braid of textile material over the inner tube and four spiral
plies of heavy steel wire wrapped in alternating direction
3. Cover: Weather and oil resistant synthetic rubber
4. Temperature range: -40℃ to +100℃
5. Main application: Very high pressure applications used for petroleum based hydraulic fluids
Hose Type
Dash
I.D
Inch
O.D
mm
W.P
Mpa
W.P
PSI
B.P
PSI
B.R
mm
W.T
kg/m
4SH-12
3/4"
31.8
42.0
6090
24360
280
1.476
4SH-16
1"
38.7
38.0
5510
22040
340
1.984
4SH-20
1-1/4"
46.2
32.5
4713
18850
460
2.428
4SH-24
1-1/2"
53.5
29.0
4205
16820
560
2.871
4SH-32
2"
68.0
25.0
3625
14500
700
4.534
Why Choose Us
Package and Delivery

Package Details

1. Colorful nylon tape wrapped coils
2. Transparent PVC sea worthy tape wrapped coils
3. Plastic hose reels
4. Wooden hose reels
5. Pallets with hose coils
6. Wooden case with hose coils

Delivery Details

1. <1000 meters, delivery within 7 days
2. <5000 meters, delivery within 10 days
3. <10000 meters, will delivery within 15 days
4. One full container, delivery within 30 days
