Quick Details
-
Product name:
-
stadium chair back seats
-
Usage:
-
Stadium / Arena / Bleacher
-
Material:
-
PP
-
Color:
-
Optional
-
Colop Fading Warranty:
-
5 Years
-
Size:
-
430 x 450 x 390mm
-
Type:
-
Tread Fixed
-
UV resisted:
-
Yes
-
Suitable places:
-
Outdoor Location
-
Product Type:
-
Sport Equipment
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Stunity
-
Model Number:
-
ST3077
-
Product name:
-
stadium chair back seats
-
Usage:
-
Stadium / Arena / Bleacher
-
Material:
-
PP
-
Color:
-
Optional
-
Colop Fading Warranty:
-
5 Years
-
Size:
-
430 x 450 x 390mm
-
Type:
-
Tread Fixed
-
UV resisted:
-
Yes
-
Suitable places:
-
Outdoor Location
-
Product Type:
-
Sport Equipment
Stunity ® wholesale arena base stadium seats pad stadium outdoor foldable cushion cover attached to flooring for stadium
O ur Stunity wholesale arena base stadium seats pad stadium outdoor foldable cushion cover attached to flooring for stadium are widely recognized and trusted by users and can meet continuously changing economic and social needs.
! Attention : We only posted a part of our products on Alibaba web. Pls, contact us to show you more amazing products.
The specification of the Stunity wholesale arena base stadium seats pad stadium outdoor foldable cushion cover attached to flooring for stadium
| Model | Name | Application | Description | Assembly |
|
ST3077 ROCKY |
Stunity wholesale arena base stadium seats pad stadium outdoor foldable cushion cover attached to flooring for stadium | Stadium / Arena / Bleacher |
PP ( polypropylene ) Injection Stadium seat Plastic shells will be UV resisted for outdoor use Tread Fixed. |
W: 43 D: 42 H: 40 |
* The dimensions of the Stunity wholesale arena base stadium seats pad stadium outdoor foldable cushion cover attached to flooring for stadium are measured in the unit of "centimeter" (cm)
| Test Report No. | Organization | Type | Date & Time | Test Performed | Test requested |
| AJD201205462 | SGS | Stadium seating | 2013 | SELECTED TEST(S) AS REQUESTED BY APPLICANT | EN 12727:2000 FURNITURE-RANKED SEATING -TEST METHODS AND REQUIREMENTS FOR STRENGTH AND DURABILITY (FOR SEVERE USE) |
| Test Item | Test Method | Test Principles & Requirements | Test result |
| Seat and Back Static Load Test |
DIN EN 12727:2000
Clause 6.3 |
There shall be no fracture on the sample when applying load of 2000N at seat and applying back load of 760N at back for 10 times, maintaining the load for 10 seconds each cycle. | PASS |
|
Horizontal Forward Static
Load to Back |
DIN EN 12727:2000
Clause 6.4 |
There shall be no fracture on the sample when applying a horizontal forward static load of 760N at back for 10 times,
maintaining the load for 10 seconds each cycle. |
PASS |
| Vertical Static Test on Back |
DIN EN 12727:2000
Clause 6.5 |
There shall be no fracture on the sample when applying downwards force of 900N to the top of the back for 10 times, maintaining the load for 10 seconds each cycle. | PASS |
| Arm Downwards Static Load Test |
DIN EN 12727:2000
Clause 6.7 |
There shall be no fracture on the sample when applying downwards vertical force of 1000N to the arm for 10 times,
maintaining the load for 10 seconds each cycle. |
PASS |
| Combined Seat and Back Durability Test |
DIN EN 12727:2000
Clause 6.8 |
There shall be no fracture on the sample when applying load of 950N at seat and applying load of 330N at back for 200000 cycles. | PASS |
| Seat Front Edge Durability Test |
DIN EN 12727:2000
Clause 6.9 |
There shall be no fracture on the sample when applyingertical load of 950N alternately on two points each 80 mm from the front edge and side of the seat with number of 200000cycles. | PASS |
| Seat Impact Test |
DIN EN 12727:2000
Clause 6.11 |
There shall be no fracture on the sample when an impactor falls freely from the height of 300 mm onto seat for 10 times. | PASS |
| Back Impact Test |
DIN EN 12727:2000
Clause 6.12 |
There shall be no fracture on the sample when an impact hammer drops freely from the height of 620mm to back top for 10 times. | PASS |
STUNITY® KINDLY REMINDER ALL OUR CERTIFICATIONS ARE REAL ONE. NOT FAKE, NOT FAKE, NOT FAKE!!! PLEASE CONTACT US TO SHOW YOU!!
C ase A in 2017
Our fantastic Stunity wholesale arena base stadium seats pad stadium outdoor foldable cushion cover attached to flooring for stadium and retractable stands are used in Carrara indoor stadium, Gold coast sports and leisure center, Australia in 2017.
C ase B in 2011
Our fantastic Stunity wholesale arena base stadium seats pad stadium outdoor foldable cushion cover attached to flooring for stadium are used for in Zahur Ahmed Chowdhury Stadium, Chittagong, Bangladesh in 2011.
C ase C in 2017
Our fantastic Stunity wholesale arena base stadium seats pad stadium outdoor foldable cushion cover attached to flooring for stadium and retractable stands are used in the indoor stadium of John Curtin College of the Arts, Australia in 2017.
C ase D in 2017
Our fantastic Stunity wholesale arena base stadium seats pad stadium outdoor foldable cushion cover attached to flooring for stadium and retractable stands are used in Mitchell, Australia in 2017.
Blowing plastic product Operation
A. Preparing HDPE
B. Filling HDPE
C . Blowing
D. Finish product
E. Stamping line
F. Welding line
G . Powder coating line
H. Packing
I. Shipping
I nner Packing
of our Stunity wholesale arena base stadium seats pad stadium outdoor foldable cushion cover attached to flooring for stadium.
O uter Packing
of our Stunity wholesale arena base stadium seats pad stadium outdoor foldable cushion cover attached to flooring for stadium.
W arehouse
for stocking the Stunity wholesale arena base stadium seats pad stadium outdoor foldable cushion cover attached to flooring for stadium package. And then waiting for loading.
L oading & shipping
for our Stunity wholesale arena base stadium seats pad stadium outdoor foldable cushion cover attached to flooring for stadium order.
