Quick Details
-
Place of Origin:
-
TAIWAN
-
Brand Name:
-
HIWIN
-
Product name:
-
Ball Screw
-
Structure:
-
Screw+nut Cap +steel Ball Lead Screw
-
Service:
-
24 hours
-
Feature:
-
long life
-
Stock:
-
Rich
-
Packing:
-
Wooden Box Packing
-
MOQ:
-
1 SET
-
Delivery time:
-
WITHIN 3 DAYS
-
Sample:
-
Available
-
Minimum Quantity:
-
1 Pc
Quick Details
-
Weight (KG):
-
2
-
Material:
-
gcr15
-
Length:
-
0-100mm
-
Place of Origin:
-
TAIWAN
-
Brand Name:
-
HIWIN
-
Product name:
-
Ball Screw
-
Structure:
-
Screw+nut Cap +steel Ball Lead Screw
-
Service:
-
24 hours
-
Feature:
-
long life
-
Stock:
-
Rich
-
Packing:
-
Wooden Box Packing
-
MOQ:
-
1 SET
-
Delivery time:
-
WITHIN 3 DAYS
-
Sample:
-
Available
-
Minimum Quantity:
-
1 Pc
Taiwan HIWIN Ball Screw Grinding Running For Machine Tool R25-10FSC-K4
Product Description
| Type | Rolled Ballscrew |
| Nominal Size | 25 |
| Flange Diameter | 62 mm |
| Total Length | 64 mm |
| Flange Thickness | 10 mm |
| Nut Diameter | 40 mm |
| Bolt Circle Diameter | 51 mm |
| Oil Hole | M6x1 |
| Bolt Hole Head Diameter | 6.6 mm |
| Thread Lead | 10 mm |
| Dynamic Load Rating | 1660 kgf |
| Static Load Rating | 3680 kgf |
