Compact structure, stable performance and simple operation
Convenient maintenance
Long service life
- Product Details
- {{item.text}}
Quick Details
-
Power:
-
3-10KW
-
Weight:
-
1500 KG
-
Dimension(L*W*H):
-
2*1.5*1.8M/customization
-
Product name:
-
Small scale 500L/H juice milk pasteurization machine with homogenizer
-
Application:
-
Dairy production line
-
Function:
-
Sterilizing +cooling
-
Capacity:
-
500L-50000L/H
-
Processing:
-
Heating + Pasteurizing +cooling
-
Sterilization Temperature:
-
85~150
-
Sterilization Time:
-
3S 5S 10S 30S 300S
-
Heating way:
-
Steam Boiler
-
Control type:
-
PLC+Touch Screen
-
Control system:
-
Automatic Control System
Quick Details
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
JianYi
-
Voltage:
-
220v/380v/customized
-
Power:
-
3-10KW
-
Weight:
-
1500 KG
-
Dimension(L*W*H):
-
2*1.5*1.8M/customization
-
Product name:
-
Small scale 500L/H juice milk pasteurization machine with homogenizer
-
Application:
-
Dairy production line
-
Function:
-
Sterilizing +cooling
-
Capacity:
-
500L-50000L/H
-
Processing:
-
Heating + Pasteurizing +cooling
-
Sterilization Temperature:
-
85~150
-
Sterilization Time:
-
3S 5S 10S 30S 300S
-
Heating way:
-
Steam Boiler
-
Control type:
-
PLC+Touch Screen
-
Control system:
-
Automatic Control System
Product name
Small scale 500L/H juice milk pasteurization machine with homogenizer for mini dairy plant
Professional pasteurizer/sterilizer manufacturer
Over 15 years of pasteurizer/sterilizer design and manufacture experience
Top quality with reasonable price
Supports on-site installation and on-site or remote commissioning
7X24 hours after-sales and technical support
Video description
Products Description
Pasteurizer Types:
Plate type pasteurizer
Production capacity: 0.5~20 t/h
Sterilizing temperature: 85~95℃(Adjustable)
Holding time: 15~30 s (Adjustable)
Control method:
semi-automatic control(electrical control), full-automatic control (PLC control, touch screen display)
Tubular pasteurizer
Production capacity: 0.5~20 t/h
Sterilizing temperature: 85~135℃
(Adjustable)
Holding time: 15~30 s
(Adjustable)
Control method:
semi-automatic control(electrical control), full-automatic control (PLC control, touch screen display)
|
Main technical parameters
|
|
|
|
|
|
|
|
|||||||
|
Name
|
Vonfo-BR1
|
Vonfo-BR2
|
Vonfo-BR3
|
Vonfo-BR4
|
Vonfo-BR5
|
Vonfo-BR10
|
Vonfo-BR15
|
|||||||
|
Production capacity(t/h)
|
1
|
2
|
3
|
4
|
5
|
10
|
15
|
|||||||
|
Heat exchanging area (m²)
|
8-10
|
13-20
|
20-28
|
24-36
|
28-45
|
52-85
|
76-125
|
|||||||
|
Temperature of inlet(℃)
|
5-45
|
5-45
|
5-45
|
5-45
|
5-45
|
5-45
|
5-45
|
|||||||
|
Temperature of outlet (℃)
|
5-92
|
5-92
|
5-92
|
5-92
|
5-92
|
5-92
|
5-92
|
|||||||
|
Sterilizing temperature (℃)
|
85-125
|
85-125
|
85-125
|
85-125
|
85-125
|
85-125
|
85-125
|
|||||||
|
Heat preservation time (S)
|
15~30
|
15~30
|
15~30
|
15~30
|
15~30
|
15~30
|
15~30
|
|||||||
Excellent Function of Pasteurizer:
Compact structure, stable performance and simple operation
Convenient maintenance
Long service life
Application of pasteurizer:
Milk and dairy product
Plant protein beverage
Ice cream
Fruit juice beverage
Alcohol
Tea beverage
Coffee beverage
Beer
High viscosity liquid food: cream,Jam,ketchup,etc.
