Quick Details
-
Dimension:
-
2100*1140*1270mm
-
Place of Origin:
-
ZHE JIANG
-
Engine:
-
LINHAI YAMAHA
-
Transmission:
-
Automatic CVT
-
Starting system:
-
CDI Electric Start
-
Product Name:
-
4 Wheeler ATV
Quick Details
-
Displacement:
-
250cc
-
Brand Name:
-
LINHAI YAMAHA
-
Tire Size:
-
Front: AT24*8*12 Rear: AT24*11*10
-
Dimension:
-
2100*1140*1270mm
-
Place of Origin:
-
ZHE JIANG
-
Engine:
-
LINHAI YAMAHA
-
Transmission:
-
Automatic CVT
-
Starting system:
-
CDI Electric Start
-
Product Name:
-
4 Wheeler ATV
Product Specifications
|
Size: L×W×H
|
2100×1140×1270 mm
|
|
Seat Height
|
865 mm
|
|
Wheelbase
|
1215 mm
|
|
Ground Clearance
|
170 mm
|
|
Dry Weight
|
310 kg
|
|
Loading Capacity
|
129 kg
|
|
Fuel Tank Capacity
|
14 L
|
|
Max Speed
|
>60 km/h
|
|
Tire Specification
|
Front: AT 24×8-12
Rear: AT 24×11-10
|
|
Brake Control Model
|
Front: Hand brake, Foot brake
Rear: Hand brake, Foot brake
|
|
Brake System Model
|
Front: Disk brake
Rear: Disk brake
|
|
Suspension Type
|
Front: McPherson independent
suspension
Rear: Swing arm
|
|
Engine Type
|
LH173MN
|
|
Engine Model
|
Single cylinder, 4 stroke, water cooled
|
|
Cylinder Dimension
|
275 cc
|
|
Bore and Stroke
|
72.5 × 66.8 mm
|
|
Rated Power
|
16/6500-7000 (kw/r/min)
|
|
Max Torque
|
23/5500 (Nm/r/min)
|
|
Compression Ratio
|
9.5:1
|
|
Fuel System
|
CARB
|
|
Start Type
|
Electric starting
|
|
Transmission
|
Automatic L-H-N-R
|
Details Images
Factory Photos
Product Application
Application Scenario:Water Recreation
Application Scenario:Off Road
Application Scenario: Parent-child Interaction
Product Packaging
|
Length
|
2160 mm
|
|
Width
|
1180 mm
|
|
Height
|
855 mm
|
|
G.W.
|
340 kg
|
|
N.W.
|
295 kg
|
|
Vol.
|
2.18 m³
|
|
40'HQ
|
30 pcs
|
FAQ
1. Q: Can I get some samples?
A: We are honored to sell samples to you for quality check.
2. Q: Do you have the products in stock?
A: According to the actual inventory.
3. Q: What’s the delivery time?
A: It usually takes about 60 working days to produce an order. But
A: We are honored to sell samples to you for quality check.
2. Q: Do you have the products in stock?
A: According to the actual inventory.
3. Q: What’s the delivery time?
A: It usually takes about 60 working days to produce an order. But
the exact delivery time depends on different situation.
4. Q: Can I mix different models in one container?
A: Yes, different models can be mixed in one container.
5. Q: What's your warranty terms?
A: We offer 1 year warranty. Please contact with us for details.
4. Q: Can I mix different models in one container?
A: Yes, different models can be mixed in one container.
5. Q: What's your warranty terms?
A: We offer 1 year warranty. Please contact with us for details.
