Quick Details
-
Voltage:
-
220V/380V
-
Weight:
-
630 KG
-
Dimension(L*W*H):
-
2200*600*1300mm
-
Product name:
-
Low price briquetting charcoal making machine in American for sale
-
Name:
-
charcoal making machine
-
Raw material:
-
Low price briquetting charcoal making machine in American for sale
-
Capacity:
-
220V/380V
-
Keyword:
-
charcoal making machine
-
Color:
-
Customer Required
-
Application:
-
Industry
-
Function:
-
Make Stick Shape Briquette
-
Briquette Shape:
-
Square
-
Installation:
-
Engineers Guiding
Quick Details
-
Warranty:
-
1 Year
-
Place of Origin:
-
Henan,China
-
Brand Name:
-
YiBao
-
Voltage:
-
220V/380V
-
Weight:
-
630 KG
-
Dimension(L*W*H):
-
2200*600*1300mm
-
Product name:
-
Low price briquetting charcoal making machine in American for sale
-
Name:
-
charcoal making machine
-
Raw material:
-
Low price briquetting charcoal making machine in American for sale
-
Capacity:
-
220V/380V
-
Keyword:
-
charcoal making machine
-
Color:
-
Customer Required
-
Application:
-
Industry
-
Function:
-
Make Stick Shape Briquette
-
Briquette Shape:
-
Square
-
Installation:
-
Engineers Guiding
Product Description
*The charcoal machine has a wide range of raw materials and low cost. Mainly use carbonaceous wood materials such as corn, soybean, cotton, wheat, rice, straw, peanut shells, sawdust, weeds and dead branches.
*The wood charcoal briquette machine does not require any adhesives, and the biomass is extruded into a solid hollow bar through a high-temperature and high-pressure process.
pilot briquette press machine charcoal
Working principle rice straw charcoal briquette making machine
The wood charcoal making machine uses sawdust as the raw material. Under the action of the propeller and the heating ring, a high temperature and high pressure zone is formed, and the loose raw material is processed into a hollow rod. Generally, the outer diameter of the product is 50-80mm, the hole diameter is 15-20mm, and it is hollow four-corner or hexagonal column shape. It can also be made into spherical, granular and honeycomb shapes.
sawdust charcoal briquette extruder machine
Size information
|
Model
|
50A
|
50B
|
50C
|
||
|
Motor power(kw)
|
15
|
18.5
|
22
|
||
|
Max. feeding size(mm)
|
6
|
|
|
||
|
Humidity
|
8-12%
|
|
|
||
|
Forming shape
|
rectangle, hexagonal, six prismatic
|
|
|
||
|
Calorific value(kcal/kg)
|
6000-7500
|
|
|
||
|
Specific gravity(kg/m³)
|
1300-1900
|
|
|
||
|
Capacity(kg/h)
|
260-280
|
300-320
|
320-340
|
||
|
Length(mm)
|
20
|
30
|
50
|
||
|
Diameter(mm)
|
50, 60, 80
|
|
|
||
Finished product
