Quick Details
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
2040x1480x3300
-
Motor Power (kW):
-
15
-
Model Number:
-
JF21-160T
-
Weight (T):
-
13200
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
After Warranty Service:
-
Field maintenance and repair service
-
Color:
-
Can be free to choose
-
Machine type:
-
pneumatic friction clutch high-performance
-
Casting:
-
Resin sand casting
-
The machine body:
-
Steel plate welded and seamless
-
Function:
-
Punching ang press
-
Structure:
-
Higher strength and stiffness
-
Feature:
-
Simple structure,excellent versatility
-
Clutch:
-
Rigid turn clutch
Quick Details
-
Slide Stroke (mm):
-
180
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
WEILI HEAVY INDUSTRY
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
2040x1480x3300
-
Motor Power (kW):
-
15
-
Model Number:
-
JF21-160T
-
Weight (T):
-
13200
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
After Warranty Service:
-
Field maintenance and repair service
-
Color:
-
Can be free to choose
-
Machine type:
-
pneumatic friction clutch high-performance
-
Casting:
-
Resin sand casting
-
The machine body:
-
Steel plate welded and seamless
-
Function:
-
Punching ang press
-
Structure:
-
Higher strength and stiffness
-
Feature:
-
Simple structure,excellent versatility
-
Clutch:
-
Rigid turn clutch
1. Suitable for blanking, punching, forming, bending,stretching and other achieve shallow cold stamping process.
2. Widely used in electrical appliances, vehicles, tractors, agricultural machinery, mining machinery, hardware tools, machinery manufacturing and other industrial fields.
1. Welded steel fuselage, good stiffness, more stable accuracy.
2. Crankshaft longitudinal discharge, compact structure, beautiful appearance.
3. Die height realize electrically adjustable, digital display to adjust the height.
4. Slider rectangular hexahedron longer rails, with bronze liner, high guiding precision.
5. Combined pneumatic friction clutch brake, smooth engagement, sensitive action.
6. Press down type safety device, ensure the machine overload safety.
7. The slide block is provided with lifting balance cylinder, to achieve the balance block linkage.
8. Using electronic fuel pump, reliable lubrication, digital clarity.
9. The slide block can jog, stop motion emergency, operation more safety.
10. Gas circuit adopts double valve control, sensitive action, press the safety standard.
| Item/model | Units | JF21-160T |
| Nominal pressure | KN | 1600 |
| Nominal pressure stroke | mm | 6 |
| Slide stroke | mm | 180 |
| Slide stroke times | times/min | 45 |
| Max. die. Height | mm | 400 |
| Die height adjustment | mm | 110 |
| Distance between center of slide and frame | mm | 390 |
| Work table size | mm | 760x1200 |
| Hole dimensions in bed | mm | Φ180 |
| The thickness of the working bedplate | mm | 150 |
| Bottom size of slide | mm | 580x700 |
| Size of the handle hole | mm | Φ70x100 |
| The column spacing | mm | 660 |
| Motor power | kw | 6/15 |
| Machine size | mm | 2040x1480x3300 |
| Total weight | kg | 13200 |
