Quick Details
-
Brand Name:
-
DSIC
-
Place of Origin:
-
Shandong, China
-
Pressure:
-
customizable
-
Structure:
-
customizable
-
Weight:
-
130
-
Power:
-
customizable
-
Dimension(L*W*H):
-
customizable
-
Rod Diameter:
-
customizable
-
Outer Tube Diameter:
-
customizable
-
Material:
-
Steel
-
Scope of application:
-
Hydraulic Machinery
-
Work pressure:
-
7-35Mpa
-
Body Material:
-
BRASS PLASTIC
-
Surface Coating:
-
Ceramic
-
Supply Condition:
-
Chromium
-
Rate pressure:
-
10MPa~37.5MPa
-
Mounting Style:
-
Foot Mounting
-
Shaft Diameter:
-
130
-
Seal kits:
-
Hallite UK Brand
Quick Details
-
Warranty:
-
1 Year
-
Maximum Stroke:
-
customizable
-
Inner Tube Diameter:
-
customizable
-
Brand Name:
-
DSIC
-
Place of Origin:
-
Shandong, China
-
Pressure:
-
customizable
-
Structure:
-
customizable
-
Weight:
-
130
-
Power:
-
customizable
-
Dimension(L*W*H):
-
customizable
-
Rod Diameter:
-
customizable
-
Outer Tube Diameter:
-
customizable
-
Material:
-
Steel
-
Scope of application:
-
Hydraulic Machinery
-
Work pressure:
-
7-35Mpa
-
Body Material:
-
BRASS PLASTIC
-
Surface Coating:
-
Ceramic
-
Supply Condition:
-
Chromium
-
Rate pressure:
-
10MPa~37.5MPa
-
Mounting Style:
-
Foot Mounting
-
Shaft Diameter:
-
130
-
Seal kits:
-
Hallite UK Brand
Product description
|
Model number
|
Maximum stroke
|
Rated Pressure
|
L1
|
L2
|
L4
|
Shaft Diameter
|
M1
|
|||||||
|
3TG-E130*3200
|
3200
|
16
|
325
|
340
|
215
|
60
|
G1
|
|||||||
|
3TG-E130*3600
|
3600
|
16
|
325
|
340
|
215
|
60
|
G1
|
|||||||
|
3TG-E150*3000
|
3000
|
16
|
325
|
340
|
245
|
60
|
G1
|
|||||||
|
3TG-E150*3830
|
3830
|
16
|
625
|
640
|
245
|
60
|
G1
|
|||||||
|
3TG-E150*4280
|
4280
|
16
|
325
|
340/360
|
201
|
60/65
|
G1
|
|||||||
|
4TG-E160*3360
|
3360
|
16
|
325
|
340/360
|
245
|
60/65
|
G1
|
|||||||
|
4TG-E160*3800
|
3800
|
16
|
325
|
340/360
|
245
|
60/65
|
G1
|
|||||||
|
4TG-E160*4280
|
4280
|
16
|
325
|
340/360
|
245
|
60/65
|
G1
|
|||||||
|
4TG-E160*4650
|
4650
|
16
|
325
|
340/360
|
245
|
60/65
|
G1
|
|||||||
|
5TG-E160*4280
|
4280
|
16
|
325
|
340/360
|
245
|
60/65
|
G1
|
|||||||
|
5TG-E160*4650
|
4650
|
16
|
325
|
340/360
|
245
|
60/65
|
G1
|
|||||||
|
4TG-E180*4280
|
4280
|
16
|
325
|
340/360
|
245
|
60/65
|
G1
|
|||||||
|
4TG-E180*4650
|
4650
|
16
|
325
|
340/360
|
245
|
60/65
|
G1
|
|||||||
|
4TG-E180*5180
|
5180
|
16
|
325
|
340/360
|
245
|
60/65
|
G1
|
|||||||
|
4TG-E180*5390
|
5390
|
16
|
325
|
340/360
|
245
|
60/65
|
G1
|
|||||||
|
4TG-E180*5700
|
5700
|
16
|
325
|
340/360
|
245
|
60/65
|
G1
|
|||||||
|
4TG-E180*6180
|
6180
|
16
|
325
|
340/360
|
245
|
60/65
|
G1
|
|||||||
|
5TG-E180*4280
|
4280
|
16
|
325
|
340/360
|
245
|
60/65
|
G1
|
|||||||
|
5TG-E180*4650
|
4650
|
16
|
325
|
340/360
|
245
|
60/65
|
G1
|
|||||||
|
pls refer to actual product Pls contact us for further discussion and details.
|
|
|
|
|
|
|
|
|||||||
