Quick Details
-
Brand Name:
-
Bamx
-
Place of Origin:
-
Chongqing, China
-
Model Number:
-
BX150T-2 BWSR
-
Engine:
-
150cc single cylinder,4-stroke.air-forced cooling
-
Brake/operation:
-
Front: Disc/Hand Rear: Drum/Hand
-
Fuel capacity:
-
5L
-
Muffler structural style:
-
Double accelerant
-
Max speed (km/h):
-
80
-
Starter:
-
Electric/Kick
Quick Details
-
Displacement:
-
100-200CC
-
Max. Speed:
-
40 - 60km/h
-
Motor:
-
Other
-
Brand Name:
-
Bamx
-
Place of Origin:
-
Chongqing, China
-
Model Number:
-
BX150T-2 BWSR
-
Engine:
-
150cc single cylinder,4-stroke.air-forced cooling
-
Brake/operation:
-
Front: Disc/Hand Rear: Drum/Hand
-
Fuel capacity:
-
5L
-
Muffler structural style:
-
Double accelerant
-
Max speed (km/h):
-
80
-
Starter:
-
Electric/Kick
Product Introduction
Specification
|
Specification
|
|
|
|
|
|
|
|
|
|
|||||||||
|
Overall dimensions(L×W×H)
|
|
|
1760×670×1050mm
|
|
Engine type
|
|
|
single cylinder,4-stroke.air-forced cooling
|
|
|||||||||
|
Wheelbase
|
|
|
1185mm
|
|
Engine model
|
|
|
JL1P57QMJ-B
|
|
|||||||||
|
Net weight
|
|
|
94kg
|
|
bore×stroke
|
|
|
57.4mm×57.8mm
|
|
|||||||||
|
Max weight
|
|
|
245kg
|
|
displacement
|
|
|
149.6ml
|
|
|||||||||
|
brake/operation
|
|
Fr
|
disc/hand
|
|
compression ratio
|
|
|
9.5:1
|
|
|||||||||
|
|
|
Rr
|
disc/hand
|
|
max power
|
|
|
5.9kW/7000r/min
|
|
|||||||||
|
tyre size/air pression
|
|
Fr
|
90/90-12/220±10kpa
|
|
max torque
|
|
|
9.2N.m/5500r/min
|
|
|||||||||
|
|
|
Rr
|
3.5-10/250±10kpa
|
|
minimum idle speed
|
|
|
1700±100r/min
|
|
|||||||||
|
Rim/size
|
|
Fr
|
aluminum/3.15×12
|
|
minimum fuel consumption
|
|
|
354g/(kW·h)
|
|
|||||||||
|
|
|
Rr
|
aluminum2.50×10
|
|
starter
|
|
|
electric and kick
|
|
|||||||||
|
muffler structural style
|
|
|
double accelerant
|
|
transmission type
|
|
|
V-belt,two stage reduction
|
|
|||||||||
|
lubricating oil
|
|
|
SF 10W/40
|
|
carburetor type
|
|
|
equal vacuum film
|
|
|||||||||
|
lubricating oil capacity(crankcase/gear case)
|
|
|
800/140
|
|
magneto type
|
|
|
touchless-flywheel-magneto
|
|
|||||||||
|
fuel consumption
|
|
|
≤2.1(L/100km)
|
|
starter motor type
|
|
|
DC-permanent magneto
|
|
|||||||||
|
max speed
|
|
|
80km/h
|
|
fuel capacity
|
|
|
5L
|
|
|||||||||
