Quick Details
-
Model Number:
-
AQT-15
-
Product Name:
-
Digital water coffee milk chemical flow meter for ammonia
-
Accuracy:
-
1.0%
-
Nominal Path:
-
DN15 ~DN300
-
Display:
-
LCD Digital
-
Signal output:
-
4 ~ 20 mA
-
Connection:
-
Flange connection
-
Repetitive:
-
0.3%
-
Power supply:
-
+12VDC ~ 36VDC, 3.6V Lithium battery
-
Communication mode:
-
RS485
-
Key words:
-
flow meter
Quick Details
-
Type:
-
Variable Area Water Flowmeters, Variable Area Air & Gas Flowmeters, Variable Area Oil Flowmeters
-
Place of Origin:
-
Shanghai
-
Brand Name:
-
Apure
-
Model Number:
-
AQT-15
-
Product Name:
-
Digital water coffee milk chemical flow meter for ammonia
-
Accuracy:
-
1.0%
-
Nominal Path:
-
DN15 ~DN300
-
Display:
-
LCD Digital
-
Signal output:
-
4 ~ 20 mA
-
Connection:
-
Flange connection
-
Repetitive:
-
0.3%
-
Power supply:
-
+12VDC ~ 36VDC, 3.6V Lithium battery
-
Communication mode:
-
RS485
-
Key words:
-
flow meter
Product Description
Product features
The detection element does not touch the medium under test, so the performance is stable and the reliability is high.
First no moving parts, simple and firm structure, long-term operation is reliable.
The measuring range is wide and the range ratio can reach 10:1.
The output signal or current signal is proportional to the actual flow of the current.
Small subloss (about 1/4-1/4 of orifice flowmeter), belongs to energy-saving products.
|
Nominal path(mm)
|
Flow range ( m³/h )
|
|
|
||
|
|
liquid
|
gas
|
steam
|
||
|
25
|
0.8~12
|
7.2~60
|
12~120
|
||
|
40
|
2~30
|
18~180
|
30~300
|
||
|
50
|
3~45
|
20~300
|
50~500
|
||
|
65
|
6.5~84
|
54~540
|
84~840
|
||
|
80
|
10~130
|
70~700
|
120~1200
|
||
|
100
|
20~200
|
12~1200
|
200·2000
|
||
|
125
|
32~320
|
200~2000
|
320~3200
|
||
|
150
|
45~450
|
240~2400
|
440~4400
|
||
|
200
|
90~900
|
480~4800
|
800~8000
|
||
|
250
|
12~1200
|
740~7400
|
1200~12000
|
||
|
300
|
15~1500
|
1000~10000
|
1780~17800
|
||
