Item
|
Capacity
|
Size
|
Mouth diameter:mm
|
Color
|
Material
|
|
Bottom diameter*Height~Total height(m)
|
|||||
|
PT200
|
200L | 0.56*0.77~0.93 | 300 | White | LLDPE |
|
PT300
|
300L | 0.7*0.76~0.93 | 390 | White | LLDPE |
|
PT500
|
500L | 0.79*0.95~1.15 | 390 | White | LLDPE |
|
PT600
|
600L | 0.79*0.96~1.14 | 470 | White | LLDPE |
|
PT800
|
800L | 0.96*1.1~1.38 | 390 | White | LLDPE |
|
PT1000
|
1T | 1.08*1.11~1.42 | 390 | White | LLDPE |
|
PT1500
|
1.5T | 1.20*1.35~1.62 | 390 | White | LLDPE |
|
PT2000
|
2T | 1.26*1.45~1.7 | 390 | White | LLDPE |
|
PT3000
|
3T | 1.46*1.65~1.95 | 660 | White | LLDPE |
|
PT4000
|
4T | 1.74*1.73~2.05 | 660 | White | LLDPE |
|
PT5000
|
5T | 1.81*2.02~2.4 | 660 | White | LLDPE |
|
PT6000
|
6T | 1.96*2~2.35 | 660 | White | LLDPE |
|
PT8000
|
8T | 2.12*2.23~2.5 | 660 | White | LLDPE |
|
PT10000
|
10T | 2.24*2.48~2.88 | 660 | White | LLDPE |
|
PT15000
|
15T | 2.54*2.78~3.28 | 660 | White | LLDPE |
|
PT20000
|
20T | 2.74*3.4~3.98 | 660 | White | LLDPE |
|
PT30000
|
30T | 3.08*3.73~4.2 | 660 | White | LLDPE |
|
Flange
|
Diameter(mm)
|
Valve
|
Connecting Tube
|
Diameter(mm)
|
| DN20(3/4inch) | Φ25 | Φ25 | DN20(3/4inch) | 20 |
| DN25(1inch) | Φ32 | Φ32 | DN25(1inch) | 25 |
| DN32(1.2inch) | Φ40 | Φ40 | DN32(1.2inch) | 32 |
| DN40(1.5inch) | Φ50 | Φ50 | DN40(1.5inch) | 40 |
| DN50(2inch) | Φ63 | Φ63 | DN50(2inch) | 50 |
| DN65(2.5inch) | Φ75 | Φ75 | DN65(2.5inch) | 65 |
| DN80(3inch) | Φ90 | Φ90 | DN80(3inch) | 80 |
| DN15(1/2inch) | Φ20 | Φ20 | DN15(1/2inch) | 15 |
