Quick Details
-
Product name:
-
LuTong LT904B 150hp 4wd Multifuntion Tractor with Cabin 50hp
-
Model Number:
-
LT904B
-
Name:
-
Farmer Tractor
-
Color:
-
Red
-
Engine:
-
WEICHAI
-
Engine type:
-
Diesel Powered
-
Implements:
-
Plough Harrow Cultivator
-
Clutch:
-
Dual-stage
-
Options:
-
Hydraulic Valve
-
Horse power:
-
60-240hp
Quick Details
-
Brand Name:
-
LUTONG
-
Place of Origin:
-
China
-
Weight:
-
25000 KG
-
Product name:
-
LuTong LT904B 150hp 4wd Multifuntion Tractor with Cabin 50hp
-
Model Number:
-
LT904B
-
Name:
-
Farmer Tractor
-
Color:
-
Red
-
Engine:
-
WEICHAI
-
Engine type:
-
Diesel Powered
-
Implements:
-
Plough Harrow Cultivator
-
Clutch:
-
Dual-stage
-
Options:
-
Hydraulic Valve
-
Horse power:
-
60-240hp
LuTong LT904B 150hp 4wd Multifuntion Tractor with Cabin 50hp
Product Features
-
Matching Dongfanghong famous and high-quality engine, with good reliability, large torque reserve, low fuel consumption and high economic benefit:
-
Independent operation of double-acting clutch, high transmission capacity, reliable effect and more comfortable operation;
-
The gear position of the gearbox is 4×(4+2), that is, 16 forward gears and 8 reverse gears. Gear shifting is adopted with a meshing sleeve. The gears are matched reasonably and the work efficiency is high;
-
Adopt independent power output device, stable transmission and large bearing capacity;
-
Fully hydraulic steering control system with independent oil circuit, flexible, reliable and labor-saving operation;
-
Adopt hydrostatic disc brake, with large braking torque and good braking effect;
- Adopt strong pressure lifter, independent oil supply, and reliable performance of the lifting system.
-
Multiple sets of hydraulic output are optional:
-
The final drive adopts planetary reduction mechanism with compact structure and large reduction ratio;
- Brand new streamlined appearance, generous, modern and fashionable.
| Tractor Model |
LT904 |
|
| Drive Type |
4×4 |
|
| Overall Dimension L×W×H(mm) |
4396×2038×2810 |
|
| Wheel base(mm) |
2195 |
|
| Front wheel tread(mm) |
1610 |
|
| Rear wheel tread(mm) |
1620-2020 |
|
| Min. ground clearance(mm) |
379 |
|
| Min. steering radius | Unilateral brake(m) |
4.2±0.3 |
| Not unilateral brake(m) |
4.9±0.3 |
|
| Min. operating weight (KG) |
4090 |
|
| Gearbox gears number |
16F+8R |
|
| Speed | Forward(Kw/h) |
1.58-33.69 |
| Reverse(Kw/h) |
2.41-34.67 |
|
| Engine | Model |
LR4M5-23 |
| Rated power (Kw) |
66.2 |
|
| Rated speed (r/min) |
2300 |
|
| Tires spec. | Front tires |
11.2-24 |
| Rear tires |
16.9-34 |
|
| Steering Type |
Full hydraulic front wheels steering |
|
| Max. lifting force( KN ) |
15.9 |
|
| PTO | Type |
Rear-mounted, Independent type |
| Speed (r/min) |
760/1000 or 540/1000 or 540/760 or 760/850 |
|
| Power(Kw) |
56.3 |
|
| Control type of ploughing depth |
Height control & flotation control |
|
| Max. traction force (KN) |
15.9 |
|
| Front / rear Ballast (KG) |
270/470 |
|
Engine:
Xinchai 4K41ZT31/903 , 4 cylinder engine
Operating System:
operating lever is on right side, easy to operate.
PTO Operating Lever:
PTO operating lever is on left side,easy to control.
Power Switch:
Protect electrical source,avoiding leakage current.
It is on the side of the seat, easy to operate.
Combined Instrument
