Quick Details
-
Brand Name:
-
Customization
-
ENGINE TYPE:
-
150CC; 200CC; 250CC; 400CC
-
Displacement:
-
149.4ml; 196ml; 223ml; 367ml
-
Cooling System:
-
Air Cooled; water cooled
-
Max Power( Kw/rpm):
-
8.5/8000; 9.8/7000; 12/7500; 18.6/8300
-
Max Torque(N.M/rpm):
-
10/7500; 15.5/5000; 18/5500; 25.5/6200
-
Ignition:
-
CDI
-
Starting System:
-
Electric+kick Start
-
Front Brakes:
-
double Disc brake
-
Rear Brake:
-
single Disc brake
Quick Details
-
Color:
-
Customization
-
Place of Origin:
-
Jiangsu, China
-
Model Number:
-
R1
-
Brand Name:
-
Customization
-
ENGINE TYPE:
-
150CC; 200CC; 250CC; 400CC
-
Displacement:
-
149.4ml; 196ml; 223ml; 367ml
-
Cooling System:
-
Air Cooled; water cooled
-
Max Power( Kw/rpm):
-
8.5/8000; 9.8/7000; 12/7500; 18.6/8300
-
Max Torque(N.M/rpm):
-
10/7500; 15.5/5000; 18/5500; 25.5/6200
-
Ignition:
-
CDI
-
Starting System:
-
Electric+kick Start
-
Front Brakes:
-
double Disc brake
-
Rear Brake:
-
single Disc brake
Product Description
|
Specifications/Features: |
||||
| ENGINE TYPE | 150CGB | 200CC CBB | 250CC CBB | 400CC WATER COOLING |
| Displacement | 149.4ml | 196ml | 223ml | 367ml |
| Engine | 1 Cylinder,4 stroke | 1 Cylinder,4 stroke | 1 Cylinder,4 stroke | Double Cylinder,6 speed |
| Bore & Stroke | 62×49.5mm | 63.5*62.2 | 65.5*66.2 | 63.5mm×53mm |
| Cooling System | Air Cooled | Air Cooled | Air Cooled | water cooled |
| Compression Ratio | 9.2:1 | 9.0:1 | 9.25:1 | 9.2:1 |
| Fuel feed | 90# | 90# | 90# | 92# |
| Max Power( Kw/rpm) | 8.5/8000 | 9.8/7000 | 12/7500 | 18.6/8300 |
| Max Torque(N.M/rpm) | 10/7500 | 15.5/5000 | 18/5500 | 25.5/6200 |
| Max Speed | 100km/h | 105km/h | 125 km/h | 150-160km/h |
| Ground clearance | 210mm | 210mm | 210mm | 210mm |
| Fuel consumption | 2.2L/100KM | 2.3L/100KM | 2.4L/100KM | 2.6L/100KM |
| Ignition | CDI | CDI | CDI | CDI |
| Fuel tank capacity | 18L | 18L | 18L | 18L |
| Starting System | Electric+kick start | Electric+kick start | Electric+kick start | Electric start |
| Front Brakes | double Disc brake | double Disc brake | double Disc brake | double Disc brake |
| Rear Brake | single Disc brake | single Disc brake | single Disc brake | single Disc brake |
| Front suspension | Hydraulic Suspension | Hydraulic Suspension | Hydraulic Suspension | Hydraulic Suspension |
| Rear suspension | Hydraulic Suspension | Hydraulic Suspension | Hydraulic Suspension | Hydraulic Suspension |
| Front tires | 110/70-17 | 110/70-17 | 110/70-17 | 110/70-17 |
| Rear tires | 150/70-17 | 150/70-17 | 150/70-17 | 150/70-17 |
| Wheel Base | 1320 mm | 1320 mm | 1320 mm | 1320 mm |
| Payload | 150kg | 150kg | 150kg | 150kg |
| Net Weight | 136kg | 140kg | 140kg | 140kg |
| Gross Weight | 161kg | 165kg | 165kg | 165kg |
| Packing type | Steel + Carton | Steel + Carton | Steel + Carton | Steel + Carton |
| L*W*H | 2090*700*1235 mm | 2090*700*1235 mm | 2090*700*1235 mm | 2090*700*1235 mm |
| Packing size | 1950*570*860 mm | 1950*570*860 mm | 1950*570*860 mm | 1950*570*860 mm |
| 20' container(SKD) | 24 units | 24 units | 24 units | 24 units |
| 40' HQ container(SKD) | 72units | 72units | 72units | 72units |
| 20' container(CKD) | 44 units | 44 units | 44 units | 44 units |
| 40' HQ container(CKD) | 105 units | 105 units | 105 units | 105 units |
