Quick Details
-
Dimensions:
-
2270mm*610mm*100mm
-
Core:
-
EPS, cement, sand, fly ash, etc.
-
Face panel:
-
5mm fiber reinforced calcium silicate board, solid
-
Advantage:
-
Eco friendly, Scratch resistant, Lightweight, Fireproof, Soundproof
-
Usage:
-
Interior/exterior wall, roofing, ceiling, flooring
-
Applications:
-
Office buildings, Hospitals, depot, Hotels, Malls, Residences etc
-
Certificates:
-
CE, ISO9001
-
Capacity:
-
64KG, just one sixth of the brick building
-
Service Life:
-
at least 70 years
-
Fire-resistant limit:
-
4hours under 1000 degrees Celsius
Quick Details
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
OBON
-
Model Number:
-
QJFBT100L2270W610
-
Dimensions:
-
2270mm*610mm*100mm
-
Core:
-
EPS, cement, sand, fly ash, etc.
-
Face panel:
-
5mm fiber reinforced calcium silicate board, solid
-
Advantage:
-
Eco friendly, Scratch resistant, Lightweight, Fireproof, Soundproof
-
Usage:
-
Interior/exterior wall, roofing, ceiling, flooring
-
Applications:
-
Office buildings, Hospitals, depot, Hotels, Malls, Residences etc
-
Certificates:
-
CE, ISO9001
-
Capacity:
-
64KG, just one sixth of the brick building
-
Service Life:
-
at least 70 years
-
Fire-resistant limit:
-
4hours under 1000 degrees Celsius
Are
you still working in dirty and wet construction site, moving many heavy machines to the site? Are you still waiting for more than half a year before you can move inside to your new house? Are you still paying high salary to the workers and still unhappy about the final work? Are you still...?
You
are so lucky to be here and get to know the best substitute to traditional concrete wall, it is called eps cement sandwich panel. Comparison with other wall materials, this one is more stronger and longer life span with many advantages and wide usages.
| Firstly, let me tell you the what exactly is it and its structure. |
OBON
EPS (Expanded polystyrene board) wall Panel is composed of exterior panels and interior core filling, to form a non-load-bearing light-weight composite wall panel. The exterior panels on both sides are 5mm calcium silicate board, and the middle core is filled with polystyrene beads & cement or ceramsite, polystyrene beads & cement.
| Secondly, the following is the specifications of our eps cement sandwich panels. |
|
Length (mm) |
Width (mm) |
Thickness (mm) |
Applications | Appearance |
| 2270/2440 | 610 | 60 | 1.Exterior &Interior wall | 1. 5mm calcium silicate board as face panel |
| 75 | ||||
| 90 | ||||
| 100 | 2.Floor & Roofing | 2. EPS polystyrene & cement as core | ||
| 120 | ||||
| 150 | ||||
| 180 | 3.Well pipe,fire control and equipment room | 3. 100% no asbestors | ||
|
90 (half-ceramsite) |
||||
|
120 (half-ceramsite) |
4.Ultra-high wall and Unique walls | 4. Solid heart | ||
|
90 (with reinforcing bar) |
| Thirdly, it is very important for you to understand all the advantages of panels. |
| Forthly, i will show you the wide usages of our eps cement sandwich panels. |
| Fifthly, Now, you may curious on how to install it, what is the procedures? |
| After all this, if you are still not interested, It is OK as apart from the normal type, we accept OEM other types similar panels based on your requirements: |
OEM TYPE 1: Half Seramsite
OEM TYPE 2: Full Seramsite
OEM TYPE 3: With Steel Bar, we can use it for floor or exterior wall,
OEM TYPE 4: Wtih Steel Wire Mesh, this is specially for decking flooring as it can carry more than 500kg weight.
OEM TYPE 5: Surface Panel is 8mm or 10mm calcium silicate board. It is more stronger and it normally used for exterior wall.
OEM TYPE 6:Put pipe inside for special usage.
|
Sixthly, we are very experienced in manufacturing and installations, and we have done lots of projects domestic and overseas. |
