Quick Details
-
Model Number:
-
6IK120RGN(RA)
-
Frequency:
-
50/60Hz
-
Motor type:
-
AC Speed Control Motor
-
Case Diameter:
-
104mm
-
Motor Weight:
-
4.9kg
-
Gearhead Weight:
-
2.1kg
-
Speed Control Range:
-
90~1700 r/min
-
Current:
-
1.55~3.65A
-
Starting Torque:
-
520/530mN.m
-
Rated Torque:
-
330~750mN.m
-
Motor Length:
-
185mm
-
Gearhead Length:
-
72mm
Quick Details
-
AC Voltage:
-
100~230v
-
Place of Origin:
-
Sichuan, China
-
Brand Name:
-
Lunyee
-
Model Number:
-
6IK120RGN(RA)
-
Frequency:
-
50/60Hz
-
Motor type:
-
AC Speed Control Motor
-
Case Diameter:
-
104mm
-
Motor Weight:
-
4.9kg
-
Gearhead Weight:
-
2.1kg
-
Speed Control Range:
-
90~1700 r/min
-
Current:
-
1.55~3.65A
-
Starting Torque:
-
520/530mN.m
-
Rated Torque:
-
330~750mN.m
-
Motor Length:
-
185mm
-
Gearhead Length:
-
72mm
120w 120V 220V AC Speed Control Motor Speed Controller
Note:
Motor voltage, power and speed will be customized according to your request under the allowed circumstance of adoptable dimension. The below data are for reference only, we also have various other items, if you need other power and voltage or you have any questions, please feel free to contact me. Thank you!
The main specifications of 120w 104mm low rpm small ac speed control motor:
|
Motor Type
Lead Wire Type |
Output power
W |
Voltage
V |
Frequency
Hz |
Speed Control Range r/min | Rated Torque |
Starting Torque
mN.m |
Current
A |
Capacitor
μF |
||
|
120r/min
mN.m |
120r/min
mN.m |
|||||||||
| Pinion Shaft | Round Shaft | |||||||||
| 6IK120RGU-AF | 6IK120RA-AF | 120 | 1ph100 | 50 | 90-1400 | 750 | 360 | 530 | 3.65 | 30 |
| 60 | 90-1700 | 750 | 360 | |||||||
| 6IK120RGU-EF | 6IK120RA-EF | 120 | 1ph110 | 60 | 90-1700 | 750 | 360 | 520 | 3.3 | 20 |
| 1ph120 | ||||||||||
| 6IK120RGU-CF | 6IK120RA-CF | 120 | 1ph220 | 50 | 90-1400 | 750 | 330 | 530 | 1.55 | 8 |
| 1ph230 | ||||||||||
| 6IK120RGU-HF | 6IK120RA-HF | 120 | 1ph220 | 60 | 90-1700 | 750 | 360 | 530 | 1.65 | |
| 1ph230 | ||||||||||
The allowance torque of 120w 104mm low rpm small ac speed control motor with reduction gear:
|
Type
Motor/Gearhead |
Gear Ratio | 3 | 3.6 | 5 | 6 | 7.5 | 9 | 12.5 | 15 | 18 | 25 | 30 | 36 | 50 | 60 | 75 | 90 | 100 | 120 | 150 | 180 | 200 | |
|
Speed
r/min |
50Hz | 500 | 417 | 300 | 250 | 200 | 166 | 120 | 100 | 83 | 60 | 50 | 41 | 30 | 25 | 20 | 16 | 15 | 12.5 | 10 | 8.3 | 7.5 | |
| 60Hz | 600 | 500 | 360 | 300 | 240 | 200 | 144 | 120 | 100 | 72 | 60 | 50 | 36 | 30 | 24 | 20 | 18 | 15 | 12 | 10 | 9 | ||
|
6IK120RGU-AF
6IK120RGU-EF 6IK120RGU-CF 6IK120RGU-HF |
6GU K | 50Hz | 2.3 | 2.7 | 3.8 | 4.5 | 5.6 | 6.8 | 8.5 | 10.2 | 12.2 | 15.3 | 18.4 | 22.1 | 30.7 | 36.8 | 40 | 40 | 40 | 40 | 40 | 40 | 40 |
| 23.4 | 27.5 | 38.7 | 45.9 | 57.1 | 69.3 | 86.7 | 104 | 124 | 156 | 187 | 225 | 313 | 375 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | |||
| 60Hz | 1.8 | 2.2 | 3 | 3.6 | 4.6 | 5.5 | 6.8 | 8.2 | 9.8 | 12.4 | 14.9 | 17.8 | 24.8 | 29.7 | 37.1 | 40 | 40 | 40 | 40 | 40 | 40 | ||
| 18.3 | 22.4 | 30.6 | 36.7 | 46.9 | 56.1 | 69.5 | 83.6 | 100 | 126 | 152 | 181 | 253 | 303 | 378 | 400 | 400 | 400 | 400 | 400 | 400 | |||
This is the detail image of 120w 120V 220V AC Speed Control Motor Speed Controller :
The two types speed controller for 120w 120V 220V AC Speed Control Motor
The normal type
This type can work up to 140°
Q: How long can I get my producation after payment?
A: We would delivery within 7~10 days after payment confirmation.
Q: How we select models and specifications?
A: You can email us the series code as well as requirement details, such as motor power, output speed or ratio, service factory or your application... as much dats as possible. If you can supply some picture or drawings, it is much better.
Q: What is your before-sales and after-sales services?
A: 1. before-sales:
Technical support for installation; Strict quality control system; Customize production
2. after-sales:
We would supply the free maintenance within 12 months guarantee.
We would supply the professional solutions during using.
Q: How much is the freight and what is the mode of transportation?
A: 1.The freight is based on the weight of order and the distance of shipment.
2. The mode of transportation we can supply is EMS, DHL, FedEx, TNT and so on.
