Quick Details
-
Application:
-
Other
-
Design Style:
-
Modern
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Zhongcan
-
Product name:
-
Home Lift Home Elevator
-
Certification:
-
ISO9001/CE
-
Type:
-
hydraulic home elevator lift
-
Color:
-
Customized Color
-
Style:
-
full-closed cabin elevator
-
Brand:
-
Zhongcan
-
Load capacity:
-
300-1000kg
-
Drive System:
-
Hydraulic Driven
-
Lift Speed:
-
0.1-0.15m/s
-
Feature:
-
Easy Operation Safety Convenience
Quick Details
-
Warranty:
-
1 Year
-
After-sale Service:
-
Online technical support, Free spare parts
-
Project Solution Capability:
-
graphic design, 3D model design, total solution for projects, Cross Categories Consolidation
-
Application:
-
Other
-
Design Style:
-
Modern
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Zhongcan
-
Product name:
-
Home Lift Home Elevator
-
Certification:
-
ISO9001/CE
-
Type:
-
hydraulic home elevator lift
-
Color:
-
Customized Color
-
Style:
-
full-closed cabin elevator
-
Brand:
-
Zhongcan
-
Load capacity:
-
300-1000kg
-
Drive System:
-
Hydraulic Driven
-
Lift Speed:
-
0.1-0.15m/s
-
Feature:
-
Easy Operation Safety Convenience
ZHONGCAN ELEVATOR
Zhongcan Home Lifts include the cabin ,the accessories,and the spare parts. Customers do not need to take extra fee.We have modern style cabin, european luxury style or the neo-chinese style,the glass type cabin or the stainless steel type cabin.
Hydraulic Elevator With No Shaft
Hydraulic Elevator With Aluminum Enclosed Shaft
Traction Elevator
Product Description
We offer a unique range of Home Elevators. This range requires minimum space and does not require a head room or pit. Moreover, these lifts consume power only while going up and can even work in single phase if required. In case of power failure once can easily come down manually. Owing to the innovative design of the range, the significant cost on pillars and sidewalls can be completely saved.
Technical Parameters
|
Drive System
|
Hydraulic drive/ Traction drive
|
|
|
Capacity (kg)
|
250，320，400
|
|
|
Elevator Type
|
Aluminum enclosed shaft elevator/ Shaftless elevator
|
|
|
Cabin Material
|
Aluminium alloy frame and tempered glass/ Stainless steel
|
|
|
Door Styles
|
Swing landing door/ Double auto sliding door/ Fully automatic double door
|
|
|
Flooring
|
PVC/ Marble/ Granite
|
|
|
Ceiling
|
Acrylic lighting plate, LED light
|
|
|
The
lifting height, Load, cabin size,voltage and anything like details
, can be
customized
according to your needs!
|
|
|
3D Drawings
Product Accessories
Product Details
High strength steel wire rope
Duo-Security,
ensure the lift is safe for using
Hydraulic cylinder and power unit
Smooth working performance and no leaks.Great working pressure.
UPS Power supply
Platform can be descent down slowly in case of power failure
Limit Switch
One set of travel switch is installed at the highest point as insurance.
Door safety sensor
＆
Bottom anti-touch
The lift won’t work when the door is opened. It will be stopped at once if it touches any obstacles when falling
Solenoid valves
Quick valves,Slow speed valves,Pressure retaining valves and Manual drop valve
Product Installation Process
The above is the shaftless elevator installation process diagram.We have professional technical team and installation guide service.If you would like to know more detailed installation steps, please feel free to contact us!
Packaging And Shipping
All elevator parts will be packed into standard export wooden box. Some parts will be wrapped by the film so that guarantee the machinery part not be destroyed after long time transportation.
