8520 permanent magnet Micro Vertical Wind Turbines, Small Motor Blades for DIY toy

8520 permanent magnet Micro Vertical Wind Turbines, Small Motor Blades for DIY toy

FOB Reference Price: Get Latest Price

≥100 Pieces

US $0.85

≥1000 Pieces

US $0.8

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Place of Origin:: Hubei, China

Brand Name:: OEM

Model Number:: JMM17005-K8520V37QF50000L150

Rated Voltage:: 3.7V DC

Operating Voltage:: 2.0 ~ 4.2V DC

Rotation Direction:: CW/CCW

Rated Speed:: 50000 ± 10% rpm

Stall Current:: 5.9A Max

Rated Load:: R2.5*L4.0 Counter -Weight

Starting Voltage:: 0.8V DC

Insulation Resistance:: 10MΩ

Weight:: About 5.4g

Clearance between shafts:: 0.1-0.2mm

Quick Details

Speed(RPM):: 12000±2000rpm/min

Continuous Current(A):: 150mA

Efficiency:: IE 2

Place of Origin:: Hubei, China

Brand Name:: OEM

Model Number:: JMM17005-K8520V37QF50000L150

Rated Voltage:: 3.7V DC

Operating Voltage:: 2.0 ~ 4.2V DC

Rotation Direction:: CW/CCW

Rated Speed:: 50000 ± 10% rpm

Stall Current:: 5.9A Max

Rated Load:: R2.5*L4.0 Counter -Weight

Starting Voltage:: 0.8V DC

Insulation Resistance:: 10MΩ

Weight:: About 5.4g

Clearance between shafts:: 0.1-0.2mm

Product Description

Drive motor is mainly used in the toy car, intelligent vehicle and other children's toys and electric fans, blowers and other household appliances and industrial supplies, motor model and the species is numerous.

716 hollow cup drive motor

Diameter: 7mm

Body length: 16mm

Shaft length: 5mm

wire length: customized

8520 hollow cup drive motor

Diameter: 8.5mm

Body length: 20mm
Shaft length: 5mm

wirelength: customized

Size Information

Product mechanical parameters Product mechanical parameters

№	Item	Specifications	Remark
1	Model Number	JMM17005-K8520V37QF50000L150
2	Rated Voltage	3.7V DC
3	The use of Voltage range	2~ 4.2V DC
4	Rotation Direction	CW/CCW
5	Rated Current	260mA Max
6	Rated speed	50000 ± 10% rpm	Under the rated voltage motor operates on load
7	Stall Current	5.9A Max
8	Starting Voltage	0.8V DC	In any one position, voltage slowly rises
9	The use of temperature range	-10℃～60℃≤60%RH
10	Terminal Resistance	0.2 ± 5%Ω	Measure between two terminals
11	Insulation Resistance	10MΩ	Ohmmeter, measure between the wires and the shell
12	Appearance	The machine no damage and rusting
13	Weight	About 5.4 g
14	Clearance between shafts	0.10～0.20mm
