Quick Details
-
Brand Name:
-
LTMG
-
Fork Length:
-
1070mm
-
Fork Width:
-
125
-
Overall Dimensions:
-
2705*1225*2075
-
Weight (KG):
-
4500 kg
-
Engine:
-
Isuzu C240 / mitsubishi /Chinese engine
-
Free size:
-
1070X125X45mm
-
Load Center:
-
500mm
-
Free lift:
-
150mm
-
Tire:
-
Pneumatic Tire or solid is optional
-
Product Name:
-
carretilla elevadora Japanese engine 3 ton 5 ton forklift truck
-
Cab with A/C:
-
Optional
-
Wheelbase:
-
1700mm
-
Transmission type:
-
hydraulic ( automatic )
Quick Details
-
Min. Lifting Height:
-
0
-
Warranty:
-
1 Year
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
LTMG
-
Fork Length:
-
1070mm
-
Fork Width:
-
125
-
Overall Dimensions:
-
2705*1225*2075
-
Weight (KG):
-
4500 kg
-
Engine:
-
Isuzu C240 / mitsubishi /Chinese engine
-
Free size:
-
1070X125X45mm
-
Load Center:
-
500mm
-
Free lift:
-
150mm
-
Tire:
-
Pneumatic Tire or solid is optional
-
Product Name:
-
carretilla elevadora Japanese engine 3 ton 5 ton forklift truck
-
Cab with A/C:
-
Optional
-
Wheelbase:
-
1700mm
-
Transmission type:
-
hydraulic ( automatic )
3 ton forklift Standard Configuration heli forklift,hangcha forklift,zoomlion forklift,doosan forklift,teu forklift,hecha forklift,forklift toyota new, vna forklift,hyder forklift, ep electric forklift 2.5 ton,samcy best selling 3 ton diesel forklift,komatsu forklift,forklift
1. Equipped with Japanese engine, the emission conforms to the current European and American standards;
2. The core components such as gearbox and drive axle have low failure rate and reliable quality;
3. Adopt cast steering axle, good performance, high reliability and long life;
4. The hoisting system is equipped with a buffer function as standard, the goods fall smoothly and the operation is safer;
5. Equipped with LED energy-saving lamps, high brightness, low energy consumption and long life;
6. The main structural parts of the vehicle have high safety factor and strong bearing capacity
7. The gantry channel steel, oil cylinder and chain are optimally arranged, and the front view is wide;
,toyota forklift,TCM forklift,dalian forklift,jac forklift,
japanese forklift,anhui heli forklift,XCMG forklift,hyundai forklift,lonking forklift,sany forklift,linde forklift
|
Model
|
|
FD30
|
FD35
|
FD40
|
FD50
|
|
|
Load Centre
|
|
500mm
|
500mm
|
500mm
|
600mm
|
|
|
Load capacity
|
|
3000kg
|
3500kg
|
4000kg
|
5000kg
|
|
|
Mast
|
|
2-stage-mast
|
2-stage-mast
|
2-stage-mast
|
2-stage-mast
|
|
|
Fork size
|
|
1070×125×45
|
1070×125×50
|
1070×125×50
|
1070×150×50
|
|
|
Engine
|
|
ISUZU
|
ISUZU
|
YANMAR
|
ISUZU
|
|
|
Tire
|
Front
|
28×9-15-12PR
|
28×9-15-12PR
|
250-15-16PR
|
300-15-18PR
|
|
|
|
Rear
|
6.50-10-10PR
|
6.50-10-10PR
|
6.50-10-10PR
|
7.00-12-12PR
|
|
|
Length to face of fork
|
|
2730mm
|
2775mm
|
2890mm
|
3260mm
|
|
|
Overall Width
|
|
1225mm
|
1225mm
|
1410mm
|
1460mm
|
|
|
Overhead Guard Height
|
|
2090mm
|
2090mm
|
2120mm
|
2340mm
|
|
As a manufacturer, LTMG industrial is committed to offer not only diesel forklifts with high quality and performance and competitive price, but also in-time delivery and comprehensive 7/24 after-sale services.
2. What is the product range of our factory?
LTMG industrial is a large-scale machinery manufacturing enterprise primarily specializes in supplying loaders, forklift trucks, excavator and related attachments. We can also customize non-standard products according to customer's
requirements.
3. What payment terms can we accept?
Normally 30% deposit is required in advance, 70% balance shall be settled before shipment. And 100% irrevocable L/C at sight with the terms we agreed can also be accepted.
4. What Certificates do we have?
All products meet with the ISO9001 Quality System and have acquired CE certificate. EPA approval will be available if needed.
5.How about our delivery time?
Usually it will take 15 to 30 days after receiving your deposit. About standard products, we always have in stock and can deliver immediately. But customized products will take more time, depending on the requirements of your order.
6. Can we provide OEM service?
LTMG industrial can provide customized products according to customers' requirements, both OEM and ODM are acceptable.
