Items
|
BSM12K-B
|
BSM15K-B
|
BSM17K-B
|
BSM20K-B
|
||||
|
DC Input
|
|
|
|
|
||||
|
Max. PV input voltage
|
1000Vdc
|
|
|
|
||||
|
Rated PV voltage
|
600Vdc
|
|
|
|
||||
|
Max. PV input current
|
44A(4×11A)
|
|
|
|
||||
|
No. of MPPTs
|
2
|
|
|
|
||||
|
No.of PV strings per MPPT
|
2/2
|
|
|
|
||||
|
MPPT voltage range
|
200Vdc ~950Vdc
|
|
|
|
||||
|
Starting voltage
|
200Vdc
|
|
|
|
||||
|
AC Output
|
|
|
|
|
||||
|
Rated AC output power
|
12kW
|
15kW
|
17kW
|
20kW
|
||||
|
Max. output power
|
13.2kVA
|
16.5kVA
|
18.7kVA
|
22kVA
|
||||
|
Rated AC output voltage
|
380/400/415Vac
|
|
|
|
||||
|
Rated output current
|
17.4A
|
21.7A
|
24.6A
|
29.0A
|
||||
|
Max. output current
|
19.1A
|
23.9A
|
27.1A
|
31.9A
|
||||
|
Rated grid frequency
|
50/60Hz
|
|
|
|
||||
|
Grid frequency range
|
45~55Hz/55~65Hz
|
|
|
|
||||
|
Power factor
|
>0.99 full load
|
|
|
|
||||
|
Adjustable power factor
|
0.8 (leading) ~ 0.8 (lagging)
|
|
|
|
||||
|
THDi
|
<3% (rated power)
|
|
|
|
||||
|
Efficiency
|
|
|
|
|
||||
|
Max. efficiency
|
98.50%
|
|
98.60%
|
|
||||
|
European efficiency
|
98.00%
|
|
98.30%
|
|
||||
|
General
|
|
|
|
|
||||
|
Dimensions (W×H×D)
|
480×420×180mm
|
|
|
|
||||
|
Weight
|
25kg
|
|
|
|
||||
|
IP grade
|
IP65
|
|
|
|
||||
|
Noise level
|
≤25 dB
|
|
|
|
||||
|
Self-consumption at night
|
<1W
|
|
|
|
||||
|
Cooling type
|
Intelligent forced air cooling
|
|
|
|
||||
|
Altitude
|
4000m (>3000m derating )
|
|
|
|
||||
|
Operating temperature
|
-25ºC~+60ºC(>45ºC derating)
|
|
|
|
||||
|
Relative humidity
|
0~95% (Non-condensation)
|
|
|
|
||||
|
Display
|
LCD+LED
|
|
|
|
||||
|
Communication
|
RS485/WiFi/GPRS/DRM(Australia)
|
|
|
|
||||
|
AC terminal
|
OT Terminal
|
|
|
|
||||
|
Installation method
|
Wall-mounted
|
|
|
|
||||
|
Standard
|
EN62109-1, EN62109-2 NB/T32004, AS3100, AS4777, EN 61000-6-2, EN 61000-6-3, IEC 62116,IEC 61727,IEC 60068-2-1,IEC 60068-2-2,IEC
60068-2-14,IEC 60068-2-30 |
|
|
|
||||
|
By sea
|
Delivery from Shanghai or Ningbo seaport
|
|
|
|
|||
|
By air
|
Departure from Shanghai Pudong Airport
|
|
|
|
|||
|
By express
|
By TNT/DHL
|
|
|
|
|||
|
Payment Term
|
T/T
|
EXW
|
30% T/T in advance, paid the balance before shipment
|
||
|
|
|
FOB
|
|
||
|
|
|
CFR(C&F)
|
30% T/T in advance, paid the balance against copy of B/L
|
||
|
|
|
CIF
|
|
||
|
|
L/C
|
L/C amount above 50,000 usd, we can accept L/C at sight
|
|
||
|
|
Paypal
|
Amount lower than 5000usd
|
|
||
|
|
West Union
|
|
|
||
|
Delivery Time
|
7~10days after receiving payment for one container
|
|
|
||
We welcome use Trade Assurance, you'll enjoy:
100% product quality protection
100% on-time shipment protection
100% payment protection for your covered amount
