Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Anto
-
Model Number:
-
AB93U-512B
-
Feature:
-
4X 2.8-12mm (Vari-Focal AF)
-
Certification:
-
ce FCC RoHS
-
Chispset:
-
SSC30KQ+SC500AI
-
Effective Pixels:
-
5MP/8MP
-
Focal Length:
-
3.6mm
-
face detection:
-
Support
-
APP:
-
UYC
-
IR Distance:
-
40M
-
Night vision:
-
Starlight Color
Quick Details
-
Special Features:
-
Human Motion Tracking, NIGHT VISION, Motion Detection, People Counting, Two-way Audio, Intrusion Detection, Support Micro SD, up to 256 GB, 4X 2.8-12mm (Vari-Focal AF)
-
Function:
-
Waterproof / Weatherproof, NIGHT VISION, Two-way Audio, RESET
-
Customized support:
-
Online technical support, Customized logo, OEM, ODM, Software reengineering
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Anto
-
Model Number:
-
AB93U-512B
-
Feature:
-
4X 2.8-12mm (Vari-Focal AF)
-
Certification:
-
ce FCC RoHS
-
Chispset:
-
SSC30KQ+SC500AI
-
Effective Pixels:
-
5MP/8MP
-
Focal Length:
-
3.6mm
-
face detection:
-
Support
-
APP:
-
UYC
-
IR Distance:
-
40M
-
Night vision:
-
Starlight Color
Products Description
|
Platform solution
|
|
|
|
DSP
|
Dual Core A7 1.2GHz
|
|
|
sensor
|
5MP back-illuminated C MOS 1 /2.7” target area
|
|
|
Focal Length
|
4X 2.8-12mm
|
|
|
intelligent
|
|
|
|
face detection
|
support
|
|
|
Simultaneous detection and capture
|
4
|
|
|
face capture
|
Support face detection and capture;
|
|
|
|
Support to capture face pictures and display them on the web client;
|
|
|
|
Support matching face NVR intelligent display, capture record storage and retrieval fast playback video;
|
|
|
|
Supports supporting face recognition NVR, realizes pre-capture and post-comparison, intelligent display; capture record storage,
comparison video storage and retrieval and quick playback video . |
|
|
image video
|
|
|
|
smart coding
|
Support basic mode and advanced mode to reduce storage usage
|
|
|
video processing
|
H.264, H.265 video encoding;
|
|
|
|
Support three streams
|
|
|
format
|
2880*1620@25, 2560*1440@25, 2304*1296@25, 1920*1080@25, 1920*1080@30
|
|
|
resolution
|
Main stream: 2880*1620 (default), 2560*1440, 2304*1296, 1080P, 720 P
|
|
|
|
Secondary stream: 720P, D1 (default), 640*360, 2CIF, CIF
|
|
|
|
Three streams: D1, 640*360, 2CIF, CIF (default)
|
|
|
OSD
|
Support time OSD , custom OSD , etc., up to 8 lines
|
|
|
privacy cover
|
Support, up to 4
|
|
|
area enhancement
|
Support, up to 8
|
|
|
wide dynamic range
|
Support optical wide dynamic range
|
|
|
noise reduction
|
Support 2D , 3D noise reduction
|
|
|
shutter
|
Support automatic/manual mode
|
|
|
|
Support low smear mode
|
|
|
|
Support indoor 50/60Hz shutter mode, suppress power frequency flicker
|
|
|
scene mode
|
Support transparent (default), bright, standard three scene mode selection, adjust image style preference
|
|
|
software
|
|
|
|
Business functions
|
Support web configuration
|
|
|
|
Support OSD configuration , image configuration and other services
|
|
|
|
Support multiple platform SDK development kits, available for secondary development
|
|
|
|
Support high-definition audio and video synchronous preview, two-way voice intercom
|
|
|
|
Support motion detection, linkage APP to realize mobile phone push alarm
|
|
|
Light control
|
soft photosensitive light control,
|
|
|
client
|
Support mobile APP video preview (IOS, Android), upgrade, alarm sound upload and other functions
|
|
|
|
Support local management of IPC by PC client, realize multi-channel IPC live broadcast, local hard disk storage, etc.
|
|
|
custom made
|
Support personalized customized model, Logo, default parameters, IPC default language
|
|
|
audio
|
|
|
|
audio processing
|
Support G.711u, G.711a codec standard
|
|
|
|
Support noise suppression
|
|
|
Audio output
|
Maximum support for 64kbps transmission
|
|
|
network
|
|
|
|
IP acquisition method
|
Full Netcom (enabled by default), DHCP, PPPoE, static IP address
|
|
|
protocol
|
Support PPPoE, IPv4, IPV 6 , TCP, UDP, DHCP, RTP, RTSP, DNS, DDNS , NTP, port mapping and other network protocols;
|
|
|
compatibility
|
Support ONVIF standard protocol, realize the video preview and recording of docking mainstream brand NVR and PC client, etc.
|
|
|
|
Support the GB / T 28181 national standard protocol, and can be connected to the national standard platform.
|
|
|
Interface Features
|
|
|
|
network status light
|
Support
|
|
|
Reset
|
Support
|
|
|
audio port
|
Support 1- way MIC / Line input, 1-way audio output,
|
|
|
Network Interface
|
Support 10M/100M adaptive network port
|
|
|
Fill light interface
|
dual light boards
|
|
|
General
|
|
|
|
weight
|
Net weight about 0.4kg
|
|
|
working environment
|
-30 °C ~ 60°C (-22 ° F~140 ° F)
|
|
|
size
|
Product size 173*70*70mm， Packing size 194*102*98mm
|
|
|
power supply
|
DC12V /1A
|
|
|
POE
|
IEEE802.3af
|
|
|
Protection Level
|
IP66 standard
|
|
|
|
TVS lightning protection, surge protection and voltage transient protection
|
|
