Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
MEIDA
-
Voltage:
-
380v 50/60HZ 3phase
-
Power:
-
400kw
-
Dimension(L*W*H):
-
20*4.5*5m
-
Weight:
-
150000 kg
-
Name:
-
tissue Jumbo paper roll making machine waste paper recycle machinery
-
Raw material:
-
waste paper, white or brown cellulose,virgin pulp
-
Output paper:
-
toilet paper, tissue paper, facial tissue paper ,kitchen paper etc
-
Capacity:
-
10-12 tons per day
-
Net paper width:
-
2800mm
-
Output paper weight:
-
13-40g/m2
-
Diameter of dryer:
-
2500mm
-
Working speed:
-
100-150m/min
-
Take area:
-
700m2
-
After-sales Service Provided:
-
Field installation, commissioning and training
Quick Details
-
Production Capacity:
-
150 m/min
-
Product Type:
-
paper napkin machine
-
Processing Type:
-
Pulp molding machine
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
MEIDA
-
Voltage:
-
380v 50/60HZ 3phase
-
Power:
-
400kw
-
Dimension(L*W*H):
-
20*4.5*5m
-
Weight:
-
150000 kg
-
Name:
-
tissue Jumbo paper roll making machine waste paper recycle machinery
-
Raw material:
-
waste paper, white or brown cellulose,virgin pulp
-
Output paper:
-
toilet paper, tissue paper, facial tissue paper ,kitchen paper etc
-
Capacity:
-
10-12 tons per day
-
Net paper width:
-
2800mm
-
Output paper weight:
-
13-40g/m2
-
Diameter of dryer:
-
2500mm
-
Working speed:
-
100-150m/min
-
Take area:
-
700m2
-
After-sales Service Provided:
-
Field installation, commissioning and training
Model 2800 paper make machine
1
Technical parameter:
tissue Jumbo paper roll making machine waste paper recycle machinery price for sale
|
1 |
Raw materials |
waste paper, white or brown cellulose,virgin pulp Raw materials different, whole line price also different |
|
2 |
Output paper |
toilet paper, tissue paper, facial tissue paper ,kitchen paper etc please tell us your final product is Jumboo paper roll or small paper roll ,because different final product need different machines, so whole line price also different |
|
3 |
Capacity |
10-12 tons per day ( we can increase capacity if yours is bigger) |
|
4 |
Net paper width |
2800 mm |
|
5 |
Output paper weight |
13-40g/m2; |
|
6 |
Diameter of dryer |
2500mm ( if capacity bigger, dryer need increase ) |
|
7 |
Working speed |
100-150m/min; |
|
8 |
Take area |
700m2 |
|
9 |
Drive and control |
Alternating current, frequency conversion, section drive |
|
10 |
Machine weight |
150 tons |
|
11 |
Machine size |
20*4.5*5m |
|
12 |
Voltage |
380v 50hz 3phase If need change HZ or voltage, pls inform us in advance |
tissue Jumbo paper roll making machine waste paper recycle machinery price for sale
2 Raw Materails
tissue Jumbo paper roll making machine waste paper recycle machinery price for sale
3 Paper making flowchart for Jumboo Paper Roll ( waste paper recycle)
Note: Different raw materials the pulping system will be different
4 Toilet paper rewinder, paper cutter
Toilet paper rewinder, automatic paper cutter, automatic packaging machine
Toilet paper slitting and rewinding machine
Napkin folding embossing machine
Facial tissue paper folding and embossing machine
tissue toilet paper making machine spare parts
Introduction to Paper Machine Components
Machine Parts-automatic facial tissue paper making machineName: Cylinder Materials: Stainless steel structure for the film, cast iron spokes |
|
Main Parts-automatic facial tissue paper making machine
Name : dryer
Cylinder block material: HT200
|
|
Main Features-automatic facial tissue paper making machine
Name: boiler Materials : used for off steam to the dryer to make paper dry Boiler style : GAS / OIL / COAL 3 style |
1 what is the cost of a whole paper production line ?
|
Raw materials |
All these will influnce the whole line cost. What we can tell you is smallest paper production line need a budget around 40,000-50,000 USD include shipping cost to your factory |
|
Daily capacity |
|
|
Finish paper style |
tissue Jumbo paper roll making machine waste paper recycle machinery price for sale
2 daily cost for a whole paper production line
tissue Jumbo paper roll making machine waste paper recycle machinery price for sale
|
M ake one ton paper need chemical |
40-60 usd ( different raw materials chemical cost different ) |
|
M ake one ton paper need water |
A bout 3-5tons , waster can be recycle |
|
E lectricity consume |
D epends on which model machine you bought |
|
Raw materials cost |
Depends on your local raw materials price |
|
Worker cost |
Depends on your local salary |
tissue Jumbo paper roll making machine waste paper recycle machinery price for sale
3 shipping & install cost
tissue Jumbo paper roll making machine waste paper recycle machinery price for sale
|
S hipping cost |
C ontainer quantity * unit container cost from our factory to your sea port ( container quantity depends on which style machine you bought) |
|
I nstall cost & worker training |
W e sent at least 2 engineer to do install for you H is salary & tickets & living etc under buyer ’ s cost S alary is around 2200 usd/month/person. Install time depends on machine size |
tissue Jumbo paper roll making machine waste paper recycle machinery price for sale
4 before you purchase the machine, we can offer
tissue Jumbo paper roll making machine waste paper recycle machinery price for sale
|
1 details quotation |
N eed buyer offer details ( see above buying guide ) |
|
2 layout drawing |
N eed buyer offer factory size |
|
3 meet with you face to face |
W elcome come our factory , you will see running machine . |
|
4 offer detailed document support |
I f you need ask loan with sale contract , we can provide any document for your need |
|
5 other support |
A ny reasonable requriement from you, all can be acceptaed |
|
6 quanlity control |
100% meet your requriement based on sale contract |
tissue Jumbo paper roll making machine waste paper recycle machinery price for sale
5 after sale service
tissue Jumbo paper roll making machine waste paper recycle machinery price for sale
|
1 warrant time |
12 month |
|
2 spare parts |
Y ou can contact the sales 7*24hours if u need any spare parts |
|
3business expand |
I f u need increase your present machine style, we will offer further support by offer technical drawing etc . |
|
4 shipping document |
A ll needed shipping document will provide to you in time for your safty custom clearance |
6 Dear customer, welcome come to zhengzhou for a face to face discuss
