Quick Details
-
Application:
-
Warehouse
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
SF
-
Model Number:
-
Expandable Container house
-
Material:
-
eps panel with galvanized steel
-
Transport and load:
-
40HQ Container
-
Use:
-
Dwelling
-
Installation:
-
95% ready made
-
Floor:
-
Cement-fibre Board+PVC Floor
-
Window:
-
PVC Sliding Window / Aluminum
-
Name:
-
expandable cabin
-
Wall:
-
75mm Sandwich Panel
-
Size:
-
20ft
-
loading capacity:
-
2 sets in 1 40ft HC container
Quick Details
-
Warranty:
-
NONE
-
After-sale Service:
-
Online technical support
-
Project Solution Capability:
-
graphic design, 3D model design, total solution for projects, Cross Categories Consolidation, Others
-
Application:
-
Warehouse
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
SF
-
Model Number:
-
Expandable Container house
-
Material:
-
eps panel with galvanized steel
-
Transport and load:
-
40HQ Container
-
Use:
-
Dwelling
-
Installation:
-
95% ready made
-
Floor:
-
Cement-fibre Board+PVC Floor
-
Window:
-
PVC Sliding Window / Aluminum
-
Name:
-
expandable cabin
-
Wall:
-
75mm Sandwich Panel
-
Size:
-
20ft
-
loading capacity:
-
2 sets in 1 40ft HC container
|
20FT Basic Characteristics
|
External dimension (mm) |
W6320*L5900*H2480 ( Side 2270 ) |
|
In ternal dimension (mm) |
W6160*L5560*H2240 ( Side 2150 ) |
|
|
Folded state (mm) |
W2200*L5900*H2480 |
|
|
Total mass (kg) |
2500 |
|
|
30FT Basic Characteristics
|
External dimension (mm) |
W6360*L9000*H2480 ( Side 2180 ) |
|
In ternal dimension (mm) |
W6200*L8660*H2240 ( Side 2060 ) |
|
|
Folded state (mm) |
W2200*L9000*H2480 |
|
|
Total mass (kg) |
3750 |
|
|
40FT Basic Characteristics
|
External dimension (mm) |
W6240*L11800*H2480 ( Side2180 ) |
|
In ternal dimension (mm) |
W6080*L11540*H2200 ( Side2060 ) |
|
|
Folded state (mm) |
W2200*L11800*H2480 |
|
|
Total mass (kg) |
4400 |
|
|
Smaller Fold Size
|
External dimension (mm) |
W4820*L5900*H2480 ( Side2270 ) |
|
In ternal dimension (mm) |
W4660*L5560*H2240 ( Side2150 ) |
|
|
Folded state (mm) |
W700*L5900*H2480 |
|
|
Total mass (kg) |
1850 |
|
|
Usage |
Office, Dormitory, Shop, Bar, Emergency Room, Disaster Relief Room |
|
|
Advantages |
1. Low cost
, the cost of a container is much lower than traditional building, which is more suitable for individual small-scale operations or temporary houses.
6. Conforms to Australian standards |
|
