Quick Details
-
Weight (KG):
-
2000 KG
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Lianhe
-
Voltage:
-
220V/380V 50HZ, 380V/50Hz (customized)
-
Dimension(L*W*H):
-
Customize
-
Power (kW):
-
15 kW
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Homogenizer speed:
-
2880 r/min
-
Function:
-
Blending, heating and homogenizing
-
Control Type:
-
Button Control
-
Heating Method:
-
Electrical heating(or the steaming heating)
-
Usage:
-
Produce washing series products
-
Motor:
-
ABB /Siemens
Quick Details
-
Barrel Volume (L):
-
2000-5000
-
Max. Loading Volume (L):
-
5000 L
-
Range of Spindle Speed(r.p.m):
-
1 - 65 r.p.m
-
Weight (KG):
-
2000 KG
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Lianhe
-
Voltage:
-
220V/380V 50HZ, 380V/50Hz (customized)
-
Dimension(L*W*H):
-
Customize
-
Power (kW):
-
15 kW
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Homogenizer speed:
-
2880 r/min
-
Function:
-
Blending, heating and homogenizing
-
Control Type:
-
Button Control
-
Heating Method:
-
Electrical heating(or the steaming heating)
-
Usage:
-
Produce washing series products
-
Motor:
-
ABB /Siemens
Product Feature
|
Model
|
Effective
|
Stirrring power and speed
|
|
Homogeneous power and speed
|
|
Heating power
|
|
|||||||
|
|
Capcity
|
KW
|
R/MIN
|
KW
|
R/MIN
|
Electric heating
|
Steam heating
|
|||||||
|
PMC-50
|
50
|
0.75
|
0-65
|
3
|
3600
|
6 KW
|
Steam heating energy conservation and environmental protection, selected according to need
|
|||||||
|
PMC-100
|
100
|
1.5
|
0-65
|
1.5
|
3600
|
12 KW
|
|
|||||||
|
PMC-150
|
150
|
1.5
|
0-65
|
1.5
|
3600
|
12 KW
|
|
|||||||
|
PMC-200
|
200
|
1.5
|
0-65
|
3
|
3600
|
18 KW
|
|
|||||||
|
PMC-300
|
300
|
1.5
|
0-65
|
3
|
3600
|
18 KW
|
|
|||||||
|
PMC-500
|
500
|
2.2
|
0-65
|
4
|
3600
|
27 KW
|
|
|||||||
|
PMC-1000
|
1000
|
4
|
0-65
|
7.5
|
3600
|
36 KW
|
|
|||||||
|
PMC-1500
|
1500
|
4
|
0-65
|
11
|
3600
|
45 KW
|
|
|||||||
|
PMC-2000
|
2000
|
5.5
|
0-65
|
11
|
3600
|
recommed steam heating
|
|
|||||||
|
PMC-3000
|
3000
|
7.5
|
0-55
|
15
|
3600
|
|
|
|||||||
|
PMC-5000
|
5000
|
11
|
0-55
|
22
|
3600
|
|
|
|||||||
|
The parameters for reference ONLY, all the machines can be customized accordingly.
|
|
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|||||||
High speed disperser .might mixing and disperse Viscously. Solid and liquid raw material can dissolve material which is hard to dissolve such as AES, AESA LSA during liquid production which can save energy consumption and shorten production the and shorten production period.
Main adopts stepless timing device which reduce babble occur under low temperature and highviscosity condition less air bubble will be formed to produce liquid washing products.Finished products can be discharged by Disc-valve or suitable to all liquid wash products.
The all-around wall scraping mixing adopts the frequency converter for speed adjustment, so that high quality products of
different processes according to customer requirements.
The diversified high-speed homogenizer can powerfully mix solid and liquid raw materials and can rapidly dissolve many
indissoluble materials such as AES, AESA, LSA,etc.during the liquid detergent production period.
The pot body is welded by imported three-layer stainless steel plate.the tank body and the pipes adopt mirror polishing, which fully conforms to GMP requirements
The all-around wall scraping mixing adopts the frequency converter for speed adjustment, so that high quality products of
different processes according to customer requirements.
The diversified high-speed homogenizer can powerfully mix solid and liquid raw materials and can rapidly dissolve many
indissoluble materials such as AES, AESA, LSA,etc.during the liquid detergent production period.
The pot body is welded by imported three-layer stainless steel plate.the tank body and the pipes adopt mirror polishing, which fully conforms to GMP requirements
According to customer requirement, the tank can heat and cool materials the heating way including steam heating and electric heating.easy to discharge,bottom direct discharge or by transfer pump.
