Quick Details
-
Warranty:
-
12 mounths
-
Place of Origin:
-
Guangdong, China
-
Stainless Caster Wheel Diameter:
-
4/5/6/8 inch
-
Stainless Caster Wheel Width:
-
50 mm
-
Stainless Caster Load height:
-
145/165/192/242 mm
-
Stainless Caster Load Capacity:
-
200/250/280/300 kg
-
Stainless Caster Plate Size:
-
113x100 mm
-
Stainless Caster Hole Distance:
-
84x71 mm
-
Product name:
-
Stainless Caster
Quick Details
-
Material:
-
Stainless steel
-
Type:
-
Plate Casters
-
Model Number:
-
Stainless Casters
-
Warranty:
-
12 mounths
-
Place of Origin:
-
Guangdong, China
-
Stainless Caster Wheel Diameter:
-
4/5/6/8 inch
-
Stainless Caster Wheel Width:
-
50 mm
-
Stainless Caster Load height:
-
145/165/192/242 mm
-
Stainless Caster Load Capacity:
-
200/250/280/300 kg
-
Stainless Caster Plate Size:
-
113x100 mm
-
Stainless Caster Hole Distance:
-
84x71 mm
-
Product name:
-
Stainless Caster
Products Description
|
Specifications For Stainless Steel Casters
|
|
|
|
|
|
|
|
|||||||
|
Size
|
Diameter
|
Width
|
Load Capacity
|
Top Plate size
|
Hole distance
|
Height
|
Hole
size
|
|||||||
|
4 inch
|
4 "
|
2 "
|
660 lbs
|
4" x 4-1/2"
|
2-5/8" x 3-5/8" to 3" x 3"
|
5-5/8 "
|
3/8"
|
|||||||
|
5 inch
|
5 "
|
2
"
|
770
lbs
|
4" x 4-1/2"
|
2-5/8" x 3-5/8" to 3" x 3"
|
6-1/2 "
|
3/8"
|
|||||||
|
6 inch
|
6 "
|
2 "
|
880 lbs
|
4" x 4-1/2"
|
2-5/8" x 3-5/8" to 3" x 3"
|
7-1/2 "
|
3/8"
|
|||||||
|
8 inch
|
8 "
|
2 "
|
990 lbs
|
4" x 4-1/2"
|
2-5/8" x 3-5/8" to 3" x 3"
|
9-1/2 "
|
3/8"
|
|||||||
|
Specifications For Stainless Steel Casters
|
|
|
|
|
|
|
|
|||||||
|
Size
|
Diameter
|
Width
|
Load Capacity
|
Top Plate size
|
Hole distance
|
Height
|
Hole
size
|
|||||||
|
4 inch
|
100 mm
|
50 mm
|
300 kgs
|
113x100 mm
|
84x71 mm
|
145 mm
|
20x11 mm
|
|||||||
|
5 inch
|
125 mm
|
50 mm
|
350 kgs
|
113x100 mm
|
84x71 mm
|
165 mm
|
20x11 mm
|
|||||||
|
6 inch
|
150 mm
|
50 mm
|
400 kgs
|
113x100 mm
|
84x71 mm
|
192 mm
|
20x11 mm
|
|||||||
|
8 inch
|
200 mm
|
50 mm
|
450 kgs
|
113x100 mm
|
84x71 mm
|
242 mm
|
20x11 mm
|
|||||||
