Quick Details
-
Bottle Volume(ml):
-
2000 ml
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
LANGGE
-
Year:
-
2019
-
Voltage:
-
Customer
-
Dimension(L*W*H):
-
1.70.6*1.38m
-
Weight (KG):
-
6000 KG
-
After-sales Service Provided:
-
Overseas service center available, Video technical support, Online support
-
Max.container volume:
-
2L
-
Max. neck diameter:
-
45mm
-
Max. container diameter:
-
130mm
-
Max.container height::
-
340mm
-
Mould Thickness:
-
100-180mm
-
Mould Stroke:
-
170mm
-
Heat Lamp Amount:
-
28pcs
-
Max. heating power:
-
22.4kw
-
Power of Main Blower:
-
23kw
-
Blow Moulding Type:
-
Stretch Blow Moulding
-
Local Service Location:
-
Philippines
-
After Warranty Service:
-
Video technical support, Online support
-
Certification:
-
ISO9001
-
Marketing Type:
-
New Product 2021
Quick Details
-
Neck Diameter(mm):
-
45 mm
-
Max.Bottle Diameter(mm):
-
115 mm
-
Max.Bottle Height(mm):
-
330 mm
-
Bottle Volume(ml):
-
2000 ml
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
LANGGE
-
Year:
-
2019
-
Voltage:
-
Customer
-
Dimension(L*W*H):
-
1.70.6*1.38m
-
Weight (KG):
-
6000 KG
-
After-sales Service Provided:
-
Overseas service center available, Video technical support, Online support
-
Max.container volume:
-
2L
-
Max. neck diameter:
-
45mm
-
Max. container diameter:
-
130mm
-
Max.container height::
-
340mm
-
Mould Thickness:
-
100-180mm
-
Mould Stroke:
-
170mm
-
Heat Lamp Amount:
-
28pcs
-
Max. heating power:
-
22.4kw
-
Power of Main Blower:
-
23kw
-
Blow Moulding Type:
-
Stretch Blow Moulding
-
Local Service Location:
-
Philippines
-
After Warranty Service:
-
Video technical support, Online support
-
Certification:
-
ISO9001
-
Marketing Type:
-
New Product 2021
Product Description
|
ITEM
|
UNIT
|
LGB-4-700
|
|
Theoretical Output
|
pcs/h
|
2500
|
|
Max. container volume
|
L
|
0.7
|
|
Max. neck diameter
|
mm
|
45
|
|
Max.container diameter
|
mm
|
80
|
|
Max. container height
|
mm
|
370
|
|
Mould Thickness
|
mm
|
180
|
|
Mould Stroke
|
mm
|
170
|
|
Max. heating power
|
kw
|
5
|
|
Power of Main Blower
|
kw
|
5.5
|
|
Actual power consuming
|
kw
|
4
|
|
Working preesure
|
Mpa
|
0.8
|
|
Low pressure consuming
|
Ltr/min
|
600
|
|
Blowing pressure
|
Mpa
|
3
|
|
High pressure consuming
|
mm
|
1800
|
|
Measurement of Main Blower
|
mm
|
1730*800*1850
|
|
Weight of preheater
|
mm
|
880*520*1650
|
|
Weight of Main blower
|
kg
|
1200
|
Detailed Images
blow process
Certifications
Our Service
Packing & Delivery
