- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
RUNTX
-
Fork Length:
-
1070MM
-
Fork Width:
-
122MM
-
Overall Dimensions:
-
2400*1150MM
-
Weight (KG):
-
3400 kg
-
Type:
-
Electric Forklift
-
Capacity:
-
1t 2t 3t 5t
-
Color:
-
Customer Demanded
-
Mast:
-
2 Stage/3 Stage
-
Operator type:
-
Sit-down
-
Tire:
-
Solid Tires Optional
-
Transmission:
-
Automatic Electronic Transmission
-
Packing:
-
8 Set/ 40GP
-
Power:
-
AC-Drive
Quick Details
-
Min. Lifting Height:
-
2010MM
-
Warranty:
-
1 Year
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
RUNTX
-
Fork Length:
-
1070MM
-
Fork Width:
-
122MM
-
Overall Dimensions:
-
2400*1150MM
-
Weight (KG):
-
3400 kg
-
Type:
-
Electric Forklift
-
Capacity:
-
1t 2t 3t 5t
-
Color:
-
Customer Demanded
-
Mast:
-
2 Stage/3 Stage
-
Operator type:
-
Sit-down
-
Tire:
-
Solid Tires Optional
-
Transmission:
-
Automatic Electronic Transmission
-
Packing:
-
8 Set/ 40GP
-
Power:
-
AC-Drive
Products Description



Model
|
|
|
CPCD
|
|
|
|
|
|||||
|
|
|
30
|
35
|
40
|
45
|
50
|
|||||
Power Type
|
|
|
Diesel
|
Diesel
|
|
|
|
|||||
Rated Capacity
|
|
kg
|
3000
|
3500
|
4000
|
4500
|
5000
|
|||||
Load Centre
|
|
mm
|
500
|
500
|
500
|
500
|
500
|
|||||
Lift Height
|
|
mm
|
3000
|
3000
|
|
|
|
|||||
Fork Size
|
L x W x T
|
mm
|
1070x125x45
|
|
1070X150X50
|
|
|
|||||
Mast Tilt Angle
|
F/R
|
Deg
|
6/12
|
6/12
|
|
|
|
|||||
Front Overhang(wheel centre to fork face)
|
|
mm
|
480
|
485
|
579
|
579
|
579
|
|||||
Ground Clearance(bottom of mast)
|
|
mm
|
140
|
140
|
170
|
170
|
170
|
|||||
Overall Dimension
|
Forklift length(without fork)
|
mm
|
2730
|
2775
|
3260
|
3260
|
3260
|
|||||
|
Overall width
|
mm
|
1225
|
1225
|
1460
|
1460
|
1460
|
|||||
|
Mast Lowered height
|
mm
|
2115
|
2115
|
2270
|
2270
|
2270
|
|||||
|
Mast Extended Height(with backrest)
|
mm
|
4150
|
4150
|
4165
|
4165
|
4165
|
|||||
|
Overhead Guard Height
|
mm
|
2090
|
2090
|
2340
|
|
|
|||||
Turning Radius(outside)
|
|
mm
|
2440
|
2480
|
2910
|
|
|
|||||
Speed
|
Travel(empty load)
|
km/h
|
20
|
20
|
25
|
25
|
25
|
|||||
|
Lifting(full load)
|
mm/s
|
510
|
440
|
420
|
400
|
380
|
|||||
Max Gradeability
|
|
%
|
20
|
20
|
20
|
20
|
20
|
|||||
Tire
|
Front
|
mm
|
28x9-15-12PR
|
|
300-15-18PR
|
|
|
|||||
|
Rear
|
mm
|
6.50-10-10PR
|
|
7.00-12-12PR
|
|
|
|||||
Wheelbase
|
|
mm
|
1700
|
1700
|
2100
|
|
|
|||||
Service Weight
|
|
kg
|
4300
|
4500
|
6480
|
6680
|
6980
|
|||||
Battery
|
Voltage/Capacity
|
V/Ah
|
12/80
|
12/80
|
(12/80)X2
|
|
|
|||||
Engine
|
Model
|
|
C240
|
4JG2
|
S4S
|
6BG1
|
|
|||||
|
Manufacture
|
|
ISUZU
|
ISUZU
|
Mit
|
ISUZU
|
|
|||||
|
Rated output/r.p.m.
|
kw
|
35.4/2500
|
46/2450
|
35.4/2250
|
82.4/2000
|
|
|||||
|
Rated torque/r.p.m.
|
N.m
|
137.7/1800
|
184.7/1600-1800
|
35.5/2250
|
82.4/200
|
|
|||||
|
No.of Cylinder
|
|
4
|
4
|
4
|
6
|
6
|
|||||
|
Bore x Store
|
mm
|
86x102
|
95.4X107
|
94X120
|
105X124
|
|
|||||
|
Displacement
|
cc
|
2369
|
3059
|
3331
|
6494
|
6494
|
|||||
|
Fuel Tank Capacity
|
L
|
60
|
60
|
70
|
130
|
130
|
|||||
Transmission
|
Type
|
|
Hydraulic
|
|
Hydraulic
|
|
|
|||||
|
Stage FWD/RVS
|
|
1/1
|
1/1
|
2/1
|
2/1
|
2/1
|

Details
1. High-quality manganese steel, strong toughness and high safety factor
2. Electrophoresis-automotive grade painting process
3. Integral forming overhead guard, strong and durable, large arched structure, high pressure resistance, strong safety
4. Integrated injection molding instrument panel, humanized design, with USB charging port
5. With LED headlights, beautiful and practical, energy-saving more than 80%
6. High-frequency MOSFET integrated controller ensures smooth and precise walking and lifting control,excellent speed regulation
performance, good matching performance of motor electronic control, regenerative braking,reverse braking, slope anti-slide and
other functions, safe and reliable.
2. Electrophoresis-automotive grade painting process
3. Integral forming overhead guard, strong and durable, large arched structure, high pressure resistance, strong safety
4. Integrated injection molding instrument panel, humanized design, with USB charging port
5. With LED headlights, beautiful and practical, energy-saving more than 80%
6. High-frequency MOSFET integrated controller ensures smooth and precise walking and lifting control,excellent speed regulation
performance, good matching performance of motor electronic control, regenerative braking,reverse braking, slope anti-slide and
other functions, safe and reliable.
Attachmen
Packaging and Shipping
Production Workshop
