* Diesel engine 190F
* 100% copper wire alternator
* Silent canopy, portable model
*6.5KW output
* Four wheels ensure easy moving
* Electric start with 30AH battery
- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
MAXTORQ
-
Model Number:
-
MTG7500SE
-
Speed:
-
3000/3600RMP Optional
-
Weight:
-
155KG
-
Product Name:
-
5.5kW Portable Generator Diesel
-
Generator fuel tank:
-
8-24hours Fuel Tank
-
Alternator:
-
Brush alternator
-
Generator Type:
-
Silent(super Silent)or Open Generator Diesel
-
Generator Engine:
-
OHV 4-Stroke
-
Controller:
-
Smartgen/Deepsea
-
Generator Cylinder:
-
2L, 4L, 6L, 12V
-
Color:
-
Customers' Requirement
-
Options:
-
Automatic Transfer Switch
-
Phase:
-
1 Phase/3 Phase
-
Certification:
-
CE/ISO
Quick Details
-
Rated Voltage:
-
220/380V-230V/400V-440V-480V optional
-
Rated Current:
-
Depends on voltage
-
Frequency:
-
50/60HZ Optional
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
MAXTORQ
-
Model Number:
-
MTG7500SE
-
Speed:
-
3000/3600RMP Optional
-
Weight:
-
155KG
-
Product Name:
-
5.5kW Portable Generator Diesel
-
Generator fuel tank:
-
8-24hours Fuel Tank
-
Alternator:
-
Brush alternator
-
Generator Type:
-
Silent(super Silent)or Open Generator Diesel
-
Generator Engine:
-
OHV 4-Stroke
-
Controller:
-
Smartgen/Deepsea
-
Generator Cylinder:
-
2L, 4L, 6L, 12V
-
Color:
-
Customers' Requirement
-
Options:
-
Automatic Transfer Switch
-
Phase:
-
1 Phase/3 Phase
-
Certification:
-
CE/ISO
* Diesel engine 190F
* 100% copper wire alternator
* Silent canopy, portable model
*6.5KW output
* Four wheels ensure easy moving
* Electric start with 30AH battery
Specification
|
GENERATOR
|
Model
|
MTG7500SE
|
|
|
|
|
Frequency(HZ)
|
50
|
60
|
|
|
|
Max. output(kw)
|
5.5
|
6
|
|
|
|
Rated output(kw)
|
6
|
6.5
|
|
|
|
Rated. AC voltage(v)
|
120, 220, 230, 240
|
|
|
|
|
Power factor(cosΦ )
|
cosΦ =1
|
|
|
|
|
DC output (v)
|
12V/8.3A
|
|
|
|
|
Phase
|
Single phase
|
|
|
|
|
Alternator type
|
self-excited, 2-pole, single phase alternator
|
|
|
|
|
Starting system
|
Electric
|
|
|
|
|
Operating noise level(at 7m)
|
68~72
|
|
|
|
|
Fuel tank capacity(L)
|
16
|
|
|
|
|
Continues work(hr)
|
8.5
|
7.8
|
|
|
|
Model
|
190F
|
|
|
|
ENGINE
|
Engine type
|
Single-cylinder, vertical, 4-stroke air-cooled diesel engine
|
|
|
|
|
Bore× stroke(mm)
|
86× 72
|
|
|
|
|
Fuel
|
0# or -10# light diesel fuel
|
|
|
|
|
Lubrication oil volume(L)
|
1.65
|
|
|
|
|
Combustion system
|
Direct lnjection
|
|
|
|
|
Voltmeter
|
yes
|
|
|
|
|
AC Output Socket
|
2
|
|
|
|
|
AC circuit breaker
|
yes
|
|
|
|
|
Oil warning light
|
yes
|
|
|
|
|
Oil alert
|
yes
|
|
|
|
|
DC circuit breaker
|
optional
|
|
|
|
|
Calculagraph
|
optional
|
|
|
|
|
Big Wheel
|
optional
|
|
|
|
|
Three phase voltage
|
optional
|
|
|
|
|
Current meter
|
optional
|
|
|
|
|
ATS
|
optional
|
|
|
|
|
Remote control
|
optional
|
|
|
|
|
Welding
|
optional
|
|
|
|
|
Dimension(L× W× H)(mm)
|
920× 530× 680
|
|
|
|
|
Gorss weight(kg)
|
155
|
|
|
|
|
20FT
|
72
|
|
|
Products Description
Products Details
High quality engine brand
Sail battery
Fuel filter
Fuel filler
Engine maintenance entrance
Exhaust Muffler
Ventilation hole
Standard panel
Three in one digital display meter
Single phase panel with controller
220~230V 50HZ
120~240V 60HZ
Three phase panel with controller
220/380V 50HZ
127-220V 60HZ
Smartgen Controller
Mebay Controller
Recommend Products
|
MTG6500SE
|
MTG5500SE
|
MTG10000SE
|
Packing&Delivery
FAQ
Q1. Can I have a sample order?
A: Yes, it's ok for testing.
Q2. What about the lead time?
A: Samples arrived often need 3-5 days.
Q3. Do you have any MOQ (minimum order quality)limit?
A: Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A: We often ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping is also optional.
Q5. How to proceed an order?
A: Initially, let us know your requirements or application. Besides, We quote according to your requirements or our suggestions.
Thirdly, customers confirms the samples and places deposit for formal order. Finally, We arrange the production.
Q6: Do you offer guarantee for the products?
A: Yes, we offer one-year warranty for our products.
Q7: Is there instruction installation?
A: Yes, each product comes with instruction installation in the package.
If you have more questions, just contact us soon
A: Yes, it's ok for testing.
Q2. What about the lead time?
A: Samples arrived often need 3-5 days.
Q3. Do you have any MOQ (minimum order quality)limit?
A: Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A: We often ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping is also optional.
Q5. How to proceed an order?
A: Initially, let us know your requirements or application. Besides, We quote according to your requirements or our suggestions.
Thirdly, customers confirms the samples and places deposit for formal order. Finally, We arrange the production.
Q6: Do you offer guarantee for the products?
A: Yes, we offer one-year warranty for our products.
Q7: Is there instruction installation?
A: Yes, each product comes with instruction installation in the package.
If you have more questions, just contact us soon
