Quick Details
-
Positioning Accuracy (mm):
-
0.05 mm
-
Travel (X Axis)(mm):
-
1300 mm
-
Travel (Y Axis)(mm):
-
2500 mm
-
Repeatability (X/Y/Z) (mm):
-
0.05 mm
-
Spindle Motor Power(kW):
-
6
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
COSMAC
-
Dimension(L*W*H):
-
3600*2300*2300mm
-
Weight (KG):
-
2500
-
Model:
-
CMC-4S
-
Worktable size:
-
1300*2500mm
-
Control system:
-
Taiwan SYNTEC FC
-
Servo motor:
-
Leadshine 1.5KW
-
Reducer:
-
Japan SHIMPO brand
-
Machine head structure:
-
HQD air cooling spindle 6.0kw*2 pcs+4.5kw*2 pcs
-
worktable:
-
Vacuum worktable 6 zones
-
Positioning:
-
3+2 auto positioning cylinder
-
Vacuum pump:
-
7.5kw water pump
-
VFD:
-
BESTCN brand 7.5kw
Quick Details
-
Working Table Size(mm):
-
1300×2500
-
Machine Type:
-
CNC Router
-
Range of Spindle Speed(r.p.m):
-
0 - 18000 rpm
-
Positioning Accuracy (mm):
-
0.05 mm
-
Travel (X Axis)(mm):
-
1300 mm
-
Travel (Y Axis)(mm):
-
2500 mm
-
Repeatability (X/Y/Z) (mm):
-
0.05 mm
-
Spindle Motor Power(kW):
-
6
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
COSMAC
-
Dimension(L*W*H):
-
3600*2300*2300mm
-
Weight (KG):
-
2500
-
Model:
-
CMC-4S
-
Worktable size:
-
1300*2500mm
-
Control system:
-
Taiwan SYNTEC FC
-
Servo motor:
-
Leadshine 1.5KW
-
Reducer:
-
Japan SHIMPO brand
-
Machine head structure:
-
HQD air cooling spindle 6.0kw*2 pcs+4.5kw*2 pcs
-
worktable:
-
Vacuum worktable 6 zones
-
Positioning:
-
3+2 auto positioning cylinder
-
Vacuum pump:
-
7.5kw water pump
-
VFD:
-
BESTCN brand 7.5kw
Products Description
CNC Router Machine Wood 4 Axis Wood Carving Machine CNC Cutting Machine
Parameter
|
Model
|
CMC-4S
|
|
Worktable size
|
1300*2500mm
|
|
Machine body
|
Thick square tube, aging treatment, five axis metal machining center processing
|
|
Guide rail
|
Taiwan Hongtai straight square rail 25mm
|
|
Control system
|
Taiwan SYNTEC FC
|
|
Servo motor
|
Leadshine 1.5KW
|
|
Reducer
|
Japan SHIMPO brand
|
|
Machine head structure
|
HQD air cooling spindle 6.0kw*2 pcs+4.5kw*2 pcs
|
|
worktable
|
Vacuum worktable 6 zones
|
|
Positioning
|
3+2 auto positioning cylinder
|
|
Pusher
|
Automatic material pushing system, secondary dust removal
|
|
Vacuum pump
|
7.5kw water pump
|
|
VFD
|
BESTCN brand 7.5kw
|
|
Electrical part
|
Delixi electronic components, high flexible shielding cable
|
|
lubrication
|
Electric timing lubrication system
|
|
Control cabinet
|
Integrated control operating system box
|
|
Overall dimension
|
3600*2300*2300mm
|
|
weight
|
2500kg
|
