YuanMech Tire Machine 14-26" Automatic Heavy Duty Alloy Rim Protection Tire Changer Machine for Truck

FOB Reference Price: Get Latest Price

≥1 Pieces

US $2160

≥10 Pieces

US $2080

≥20 Pieces

US $1960

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Place of Origin:: Liaoning, China

Brand Name:: YuanMech

Model Number:: TC826

Warranty:: 14 Months

Brand:: YuanMech

Type:: Automatic

HYDRAULIC PUMP MOTOR:: 1.5 kW

Rim diameter:: 14 - 26"

Maximum tire diameter:: 1600 mm

Maximum tire weight:: 500 kg

Maximum tire width:: 780mm

Hydraulic oil pressure:: 130 bar

Weight:: 570kg

Power of the gearbox motor:: 1.5 kW

Quick Details

Motor Power:: 1.5kw/1.5kw

Operating Pressure:: 130 bar

Power Supply:: 220v/380v

Place of Origin:: Liaoning, China

Brand Name:: YuanMech

Model Number:: TC826

Warranty:: 14 Months

Brand:: YuanMech

Type:: Automatic

HYDRAULIC PUMP MOTOR:: 1.5 kW

Rim diameter:: 14 - 26"

Maximum tire diameter:: 1600 mm

Maximum tire weight:: 500 kg

Maximum tire width:: 780mm

Hydraulic oil pressure:: 130 bar

Weight:: 570kg

Power of the gearbox motor:: 1.5 kW

Product Overview

The YuanMech Truck Tire Changing Machine is built to the highest industry standards,benefiting from advanced quality control system, strong history of technological development and unparalleled industry experience.

This machine is a heavy duty, electro-hydraulic tire changer for truck and bus wheels with 14”-26” rim diameter. This is a
high-quality, economically priced machine, and designed with small-to-medium transport operations in mind.

It allows for safe and simple tire changing, is available in single or three phase options and is suitable for both steel and
alloy rims.

FEATURES AT A GLANCE

* Economical electro-hydraulic tire changer for trucks, buses and tractors
* Simple design; efficient and easy to use
* Super-duty electric motor and hydraulic drive for superior torque and powerful wheel clamping.
* Self-centering hydraulic clamping chuck

* The special design of the clamping jaw can guarantee the fix of the rim

* Spreader-type jaws ensure secure clamping of rims

* Quick-positioning and lock mount/demount arm

* Hydraulic sliding carriage positions tool head for bead breaking, mounting and demounting
* Single piece frame for maximum strength and rigidity
* Portable remote console for safe machine operation and control

* Suitable for use on alloy wheels

* Full range of accessories, spares and consumables available

* The tool head and bead breaking disk can rotate to make it convenient to adjust the position to dismount/mount the tire

* The tool arm with the two position of adjustment can execute the appropriate adjustment when dismount/mount different size of tires

* The design of electrical cabinet complies with the CE certificate standard

PRODUCT SPECIFICATIONS

No	Item	Data
1	Brand	YuanMech
2	Type	Automatic
3	Use	Truck/Bus
4	Rim diameter	14 - 26"
5	Maximum tire diameter	1600 mm
6	Maximum tire weight	500 kg
7	Maximum tire width	780 mm
8	Hydraulic oil pressure	130 bar
9	Noise	75 dB
10	Power of the gearbox motor	1.5 kW
11	Power consumption of the hydraulic motor unit	1.5 kW
12	Number of speeds	One-speed
13	Control voltage	24 V
14	Weight	570 kg
15	Machine dimensions (W x D x H)	2100 x 1650 x 930 mm
