Quick Details
-
Warranty:
-
30 years, 30 Years Output Power Guarantee
-
Brand Name:
-
Solar home
-
Model Number:
-
BSM450M10-54HNH
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1722*1134*30mm
-
Solar cell:
-
polycrystalline 180*182mm
-
Certificate:
-
TUV/ETL/ISO/CE
-
Connector:
-
Compatible Connector
-
Frame:
-
Anodized Aluminium Alloy
-
Junction Box:
-
IP67 Rated
-
Color:
-
Blue Black
-
OEM Order:
-
Acceptable
-
Front Cover:
-
3.2mm High transmission, low Iron
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
Bifacial, Double-glass, All Black, TOPCON
-
Panel Efficiency:
-
450watt
-
Warranty:
-
30 years, 30 Years Output Power Guarantee
-
Brand Name:
-
Solar home
-
Model Number:
-
BSM450M10-54HNH
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1722*1134*30mm
-
Solar cell:
-
polycrystalline 180*182mm
-
Certificate:
-
TUV/ETL/ISO/CE
-
Connector:
-
Compatible Connector
-
Frame:
-
Anodized Aluminium Alloy
-
Junction Box:
-
IP67 Rated
-
Color:
-
Blue Black
-
OEM Order:
-
Acceptable
-
Front Cover:
-
3.2mm High transmission, low Iron
Products Description
|
SPECIFICATIONS
|
|
|
|
|
||||
|
Module Type
|
BSM445M10-54HNH
|
|
BSM450M10-54HNH
|
BSM565M10-72HPH
|
||||
|
|
STC
|
NMOT
|
STC
|
NMOT
|
||||
|
Maximum Power (Pmax/W)
|
445
|
336
|
450
|
340
|
||||
|
Operating Voltage(Vmp/V)
|
32.44
|
30.14
|
32.63
|
30.30
|
||||
|
Operating Current(Imp/A)
|
13.74
|
11.16
|
13.82
|
11.24
|
||||
|
Open-Circuit Voltage(Voc/V)
|
39.05
|
37.04
|
39.24
|
37.20
|
||||
|
Short-Circuit Current(Isc/A)
|
14.48
|
11.67
|
14.56
|
11.73
|
||||
|
Module Efficiency（%）
|
22.79
|
|
23.04
|
|
||||
|
STC: Irradiance 1000W/m
2
, Cell Temperature 25°C Air Mass AM1.5
|
|
|
|
|
||||
|
|
|
|
|
|||||
Certification
Production& Packing Process
Bluesun Company
Bluesun Solar---is one of the solar power solution leading companies in China.
Specializing in research and development of solar panel, lithium battery and BMS.
Our
Global Exhibition
INTERSOLAR EUROPE
INTERSOLAR MEXICO
SOLAR SOLUTIONS KORTRIJK
THE
FUTURE ENERGY SHOW PHILIPPINES
SOLAR SOLUTIONS INT AMSTERDAM
SOLAR & STORAGE LIVE UK
Projects
Bluesun‘s export volume is as high as 22GW, with projects in more than 185 countries around.
Configuration：
425W Solar Panel EU Stock
Installation site：
Croatia
Installation time：
March
2023
Configuration：
Energy Storage with 700W Double Glass Shingled
Solar Panel
Installation site：
U.K.
Installation time：July 2023
Configuration：
440W Black Frame Shingled Solar Panel
Installation site：
Sweden Gothenburg
Installation time：
September
2023
