Quick Details
-
Brand Name:
-
SDDTMB
-
Model Number:
-
SDW-ISDB-T-150
-
Frequency Range (MHz):
-
VHF174-260/470-862
-
Gain (dBi):
-
5dbi
-
VSWR::
-
≤2
-
Input Impedance (Ω):
-
75
-
Connector type::
-
F or IEC connector
-
Maximum Power (W):
-
50W
-
Dimensions (mm)::
-
30*120mm
-
Cable Type::
-
RG174
-
Cable length (Meter)::
-
3 (customized)
-
Certification:
-
RoHS
Quick Details
-
Type:
-
Indoor
-
Frequency Range:
-
VHF174-260/470-862
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
SDDTMB
-
Model Number:
-
SDW-ISDB-T-150
-
Frequency Range (MHz):
-
VHF174-260/470-862
-
Gain (dBi):
-
5dbi
-
VSWR::
-
≤2
-
Input Impedance (Ω):
-
75
-
Connector type::
-
F or IEC connector
-
Maximum Power (W):
-
50W
-
Dimensions (mm)::
-
30*120mm
-
Cable Type::
-
RG174
-
Cable length (Meter)::
-
3 (customized)
-
Certification:
-
RoHS
|
Frequency Range (MHz)
|
VHF174-230/UHF470-862
|
|
|
Gain (dBi)
|
5
|
|
|
Horizontal Beamwidth (°)
|
360
|
|
|
VSWR
|
≤2
|
|
|
Input Impedance (Ω)
|
50
|
|
|
Maximum Power (W)
|
75
|
|
|
Power
|
DC5V
|
|
|
Power consumption
|
≤15mA
|
|
|
Mechanical Characteristics
|
|
|
|
Connector type
|
IEC connector
|
|
|
Cable Type
|
RG174
|
|
|
Cable length (Meter)
|
3 (customizable)
|
|
|
Material
|
ABS
|
|
|
Mount way
|
Magnetic base
|
|
|
Dimensions (mm)
|
30*120mm
|
|
|
Weight (g)
|
49
|
|
|
Noise Factor (dBi)
|
≤1.5
|
|
|
Operating Temperature (℃)
|
-40--60°
|
|
|
Relative Humidity
|
Up to 95%
|
|
Q1. How long is your delivery time?
A: In general, if the goods are in stock, it is 1-3 days.But please contact us if the goods are not in stock.
Q2: Can I get samples to test before place an order?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q3: How does your factory do regarding quality control?
A:Quality is a priority. All products have CE/RoHS certificate, and 100%QC inspections before shipment.
Q4: What type of antenna your company have ?
A: We have different frequencies and gains according to different types of antenna.
Gain: 2dBi, 3dBi,5dBi, 7dBi, 9dBi, 11dBi, 12dBi, 16dBi, 25dBi, ect.
Frequency: 315Mhz, 433Mhz, 868Mhz, 900Mhz, 915Mhz, 1575.42mhz, 2.4G,5.8G, RFID, WIFI, GPS, GSM, 3G, 4G, 5G... Outlook: Wall mount,Ceiling mount,Yagi, LPDA, Rubber, Patch, Panel, Magnetic...
Q5: Do you accept OEM&ODM Services?
A:Yes,we do.We can design according to your requirement.Please consult our customer service for details.
A: In general, if the goods are in stock, it is 1-3 days.But please contact us if the goods are not in stock.
Q2: Can I get samples to test before place an order?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q3: How does your factory do regarding quality control?
A:Quality is a priority. All products have CE/RoHS certificate, and 100%QC inspections before shipment.
Q4: What type of antenna your company have ?
A: We have different frequencies and gains according to different types of antenna.
Gain: 2dBi, 3dBi,5dBi, 7dBi, 9dBi, 11dBi, 12dBi, 16dBi, 25dBi, ect.
Frequency: 315Mhz, 433Mhz, 868Mhz, 900Mhz, 915Mhz, 1575.42mhz, 2.4G,5.8G, RFID, WIFI, GPS, GSM, 3G, 4G, 5G... Outlook: Wall mount,Ceiling mount,Yagi, LPDA, Rubber, Patch, Panel, Magnetic...
Q5: Do you accept OEM&ODM Services?
A:Yes,we do.We can design according to your requirement.Please consult our customer service for details.
