Quick Details
-
Range of Spindle Speed(r.p.m):
-
50 - 2250 r.p.m
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
KY
-
Model Number:
-
KY25V / KY25LV
-
Table Travel (mm):
-
480mm
-
Year:
-
2021
-
Voltage:
-
220v/380v
-
Dimension(L*W*H):
-
870*550*860mm
-
Weight (KG):
-
115
-
CNC or Not:
-
Normal
-
Product name:
-
Drill Mill Lathe
-
Spindle taper:
-
MT2
-
Drilling capacity:
-
25mm
-
Sleeve travel:
-
50mm
-
Load of table:
-
55kg
-
T-slot:
-
12mm
-
Face milling capacity:
-
63 mm
-
End milling capacity:
-
20mm
-
Power(W):
-
0.75KW
Quick Details
-
Table Travel (X) (mm):
-
480
-
Table Travel (Y) (mm):
-
175
-
Table Travel (Z) (mm):
-
380
-
Range of Spindle Speed(r.p.m):
-
50 - 2250 r.p.m
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
KY
-
Model Number:
-
KY25V / KY25LV
-
Table Travel (mm):
-
480mm
-
Year:
-
2021
-
Voltage:
-
220v/380v
-
Dimension(L*W*H):
-
870*550*860mm
-
Weight (KG):
-
115
-
CNC or Not:
-
Normal
-
Product name:
-
Drill Mill Lathe
-
Spindle taper:
-
MT2
-
Drilling capacity:
-
25mm
-
Sleeve travel:
-
50mm
-
Load of table:
-
55kg
-
T-slot:
-
12mm
-
Face milling capacity:
-
63 mm
-
End milling capacity:
-
20mm
-
Power(W):
-
0.75KW
Product Description
|
Specification
|
|
|
||
|
Model No.
|
KY25V
|
KY25LV
|
||
|
Drilling capacity
|
25mm
|
25mm
|
||
|
Face milling capacity
|
63mm
|
63mm
|
||
|
End milling capacity
|
20mm
|
20mm
|
||
|
Spindle taper
|
MT2
|
MT2
|
||
|
Sleeve travel
|
50mm
|
50mm
|
||
|
Low speed stage
|
50-1125 rpm
|
50-1125 rpm
|
||
|
High speed stage
|
100-2250 rpm
|
100-2250 rpm
|
||
|
Head rotation
|
±90°
|
±90°
|
||
|
Table size
|
500x180 mm
|
700x180 mm
|
||
|
X-axis travel
|
280mm
|
480mm
|
||
|
Y-axis travel
|
175mm
|
175mm
|
||
|
Z-axis travel
|
380mm
|
380mm
|
||
|
T-slot
|
12mm
|
12mm
|
||
|
Load of table
|
55kg
|
55kg
|
||
|
Motor
|
750w
|
750w
|
||
|
Packing size
|
670x550x860mm
|
870x550x860mm
|
||
|
Net weight
|
103kg
|
115kg
|
||
|
Standard Accessories
|
|
|
|
Speed display
|
1 set
|
|
|
Depth ruler
|
1 set
|
|
|
Working lamp
|
1 set
|
|
|
Drill chuck 3-16mm
|
1 set
|
|
|
Arbor MT2/B16, M10
|
1 set
|
|
|
Drawbar MT2/M10
|
1 set
|
|
|
Operation tools
|
1 set
|
|
|
Optional Accessories
|
|
Stand & chip tray
|
|
Keyless drill chuck 3-16mm
|
|
ER32/6pcs collet chuck (6-20mm)
|
|
3-way angle vise/75mm
|
|
Milling vise
|
|
End mill 7pcs (4-16mm)
|
|
58pcs of clamping kits/M10*11.7mm
|
|
X-axis Power feed
|
|
Digital readout
|
Features
1.Compact, economical mini ertical drilling/mlling machine.
2.Variable speed enables to oprerate easily.
3.Spindle is supported by high precision taper roller bearing.
4.Gear head provides greater torque.
5.Mill head may be tilted 90 degree
6.Adjustable taper gibs.
Packing & Delivery
Warehouse to film
Related Products
Drill Mill Lathe
Our Company
Since establishing, after years of effort, we, which is Kaiyun Machinery have grown into a professional supplier of Metalworking and woodworking machinery in China, with more than 50 domestic qualified factories as our long-term and OEM partners. Outstanding technical engineers & strict inspector ensure us turn out high quality products because they all know this is the absolutely vital that the quality is the basic of products. Our all products are exported to the worldwide markets, especially in America and Europe market.
Our Service
You can enjoy the best after service when you purchase our any product. Our technician takes serious to the every quality information feedback of our products each time, and would reply it as soon as possible. We will keep trying our best to guarantee your satisfaction, and to assure the product we send to you will meet the high quality and durable standards. If you are interested in our products or have special requirements, pls feel free to contact us without delay. Then we, Sale Dept. will give you a satisfying reply within 24 hours!
