Quick Details
-
Cooling Mode:
-
Air Cooling
-
Control Software:
-
EZCAD2
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
HANTENCNC
-
Marking Head Brand:
-
SINO
-
Weight (KG):
-
50 KG
-
Marking Area:
-
110*110mm
-
Core Components:
-
Laser Source
-
Working voltage:
-
0.5KW/AC220V/50Hz(option)
-
Minimum line width:
-
0.01mm
-
Minimum character:
-
0.1mm
-
Cooling system:
-
Air Cooling
-
Lifting pillar:
-
500mm(customize)
-
Laser source:
-
Fiber laser source
-
Laser wavelength:
-
1064nm
-
Output laser power:
-
20w~50W
-
Laser modulation frequency:
-
20kHz~80kHz
Quick Details
-
Working Accuracy:
-
0.01mm
-
Graphic Format Supported:
-
AI, DXF, BMP, Dst, Dwg, LAS, DXP
-
Laser Type:
-
Fiber Laser
-
Cooling Mode:
-
Air Cooling
-
Control Software:
-
EZCAD2
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
HANTENCNC
-
Marking Head Brand:
-
SINO
-
Weight (KG):
-
50 KG
-
Marking Area:
-
110*110mm
-
Core Components:
-
Laser Source
-
Working voltage:
-
0.5KW/AC220V/50Hz(option)
-
Minimum line width:
-
0.01mm
-
Minimum character:
-
0.1mm
-
Cooling system:
-
Air Cooling
-
Lifting pillar:
-
500mm(customize)
-
Laser source:
-
Fiber laser source
-
Laser wavelength:
-
1064nm
-
Output laser power:
-
20w~50W
-
Laser modulation frequency:
-
20kHz~80kHz
Product Description
Features
1. It can process a variety of metal and non-metal materials. Especially for high hardness, high melting point, brittle
materials,marking is more advantageous.
2. It belongs to non-contact processing, does not damage the product, has no tool wear, and has good marking quality.
3. The laser beam is thin, the processing material consumption is small, and the processing heat-affected zone is small.
materials,marking is more advantageous.
2. It belongs to non-contact processing, does not damage the product, has no tool wear, and has good marking quality.
3. The laser beam is thin, the processing material consumption is small, and the processing heat-affected zone is small.
4. High processing efficiency, computer control, easy to realize automation.
Technology Parameter
|
Description
|
Parameter
|
|
Marking Area
|
100*100mm-300*300mm(Option)
|
|
Working voltage
|
0.5KW/AC220V/50Hz(option)
|
|
Lifting pillar
|
500mm(customize)
|
|
Cooling system
|
Air Cooling
|
|
Working environment
|
0~35°C humidity≤90%
|
|
Minimum character
|
0.1mm
|
|
Minimum line width
|
0.01mm
|
|
Repeatability accuracy
|
0.003mm
|
|
Resolution
|
0.001mm
|
|
Marking speed
|
0-7000mm/s
|
|
Laser modulation frequency
|
20kHz~80kHz
|
|
Output laser power
|
20w~50W
|
|
Laser wavelength
|
1064nm
|
|
Laser source
|
MAX/Raycus/JPT laser source
|
|
Warranty
|
2 years for whole machine
|
|
After Warranty Service
|
Video technical support, Online support
|
|
Application
|
Marking on metal, copper, stainless steel, hard plastic, animal ear tags, metal tags, dog tags and so on
|
|
Machine's advantages
|
Easy to use, not need too large space
|
|
Gross weight
|
50kg
|
|
Option
|
65/69/80 rotary axis, cutting table, conveyor belt and other customized parts
|
Sample Display
Customer feedback marking on different material
With rotary axis and cutting table for ring gold sliver marking and engraving
Applicable Material:
Metal: Such as gold, silver, copper, iron, zinc, aluminum, stainless steel and so on.
Hard Plastic: PE, PP, PVC, etc. also include general engineering plastics and special engineering plastics.
It also can mark on some wood
Applicable Industrial:
Electronic components, hardware tool products, electrical products, consumer goods, sensors, auto parts, 3C electronics, handicrafts, precision equipment, gift jewelry, medical equipment, high and low voltage electrical appliances, bathroom industry, battery industry, IT industry and other fields
More Choose
Packaging and Shipping
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
